AUMA SAEx Explosion-Proof Multi-Turn Actuator (ATEX)
Overview: Certified Safety for Hazardous-Area Valve Automation
The AUMA SAEx Explosion-Proof Multi-Turn Actuator is an electric valve actuator purpose-built for installation in potentially explosive atmospheres, where constructive measures prevent the occurrence of ignition sparks or hot surfaces that could trigger an explosion. Rising and non-rising stem valves – globe valves, gate valves, and similar multi-turn valve types – are automated by the SAEx range across refineries, chemical plants, and offshore facilities where ATEX, IECEx, or equivalent hazardous-area certification is mandatory for any electrical equipment installed in the classified zone.
As a trusted supplier of AUMA valve actuators, Seven Star LLC sources and supplies the SAEx explosion-proof multi-turn actuator to refineries, gas processing plants, and petrochemical facilities across Oman and the wider GCC. Because hazardous-area certification is non-negotiable for compliant plant operation, Seven Star LLC helps engineering and procurement teams specify and source the correct SAEx configuration for their classified zone requirements.
Working Principle: Explosion-Protected Electromechanical Actuation
The SAEx actuator drives a multi-turn valve stem through a three-phase AC motor coupled to a gear train, converting electrical rotary motion into the torque and turning force needed to open or close the valve. Integral limit and torque sensing monitor the actuator’s output continuously, stopping the drive at the correct end-of-travel position or when a preset torque threshold is reached – protecting the valve seat from over-torquing while ensuring reliable, repeatable full-open and full-closed positioning.
What distinguishes the SAEx from a standard multi-turn actuator is its explosion-protected construction: motor windings, switch compartments, and terminal areas are housed within flameproof or increased-safety enclosures certified to prevent internal ignition sources from propagating to the surrounding atmosphere, even in the event of an internal fault. This certification is performed in close collaboration with national and international certification bodies, and the actuator carries the corresponding ATEX, IECEx, or regional hazardous-area approval markings appropriate to the installation’s classified zone and gas group.
Engineering Design of the SAEx Actuator
The SAEx range is built with high enclosure protection (commonly IP68) and high-quality corrosion protection, supporting reliable operation across wide ambient temperature ranges typical of outdoor and offshore installations. A handwheel is fitted for manual operation, allowing valve positioning during commissioning, maintenance, or power outage without disturbing the actuator’s explosion-protected housing integrity.
The actuator supports a broad configuration range, with output torque spanning roughly 10 Nm up to 16,000 Nm and output speeds from 4 rpm to 180 rpm depending on model size, giving specifiers flexibility to match the actuator to valves ranging from small control lines to large main isolation valves. Options include intermediate position switches, tandem-version switch arrangements, remote position transmitters, and magnetic limit and torque sensing for enhanced diagnostics and integration with plant control systems.
Key Features
The AUMA SAEx Explosion-Proof Multi-Turn Actuator delivers certified hazardous-area valve automation without compromising on functionality. Key characteristics include:
- Explosion-proof construction certified for installation in classified hazardous areas.
- Integral limit and torque sensing for precise, repeatable valve positioning and seat protection.
- Three-phase AC motor options with handwheel for manual operation.
- High enclosure protection (up to IP68) and high-quality corrosion protection for harsh environments.
- Output torque range from approximately 10 Nm to 16,000 Nm across the model range.
- Optional intermediate position switches, tandem switches, remote position transmitters, and magnetic limit/torque sensing.
- Wide ambient temperature range suited to outdoor, offshore, and extreme-climate installations.
Industrial Applications
The SAEx actuator is deployed wherever multi-turn valves must be automated within a classified hazardous area, including refinery process units, tank farms, offshore platforms, gas processing facilities, and chemical plants handling flammable liquids or gases. Its explosion-proof certification makes it a mandatory specification choice rather than optional upgrade in these environments, and its robust enclosure protection supports long-term reliable operation in the corrosive, temperature-extreme conditions common to Gulf-region oil and gas infrastructure.
Seven Star LLC supports refinery engineering teams, EPC contractors, and plant maintenance departments across Oman, Muscat, Sohar, and the broader GCC region with sourcing of AUMA explosion-proof actuators, helping projects meet hazardous-area compliance requirements without compromising valve automation performance.
Certification Markings and Zone Suitability
AUMA publishes explicit hazardous-area markings for the AUMA SAEx range rather than a generic statement of compliance, and those markings are what a plant authority actually checks against the area classification drawing. For gas atmospheres the ATEX marking is II 2G Ex db eb IIC (IIB) T4 (T3) Gb, and the equivalent IECEx marking is Ex db eb IIC (IIB) T4 (T3) Gb. For combustible dust the marking is II 2D Ex tb IIIC T130 °C (T190 °C) Db. North American approvals are held to FM Class I Div 1 Groups (B), C, D T4 (T3C) and Class II Div 1 Groups E, F, G T4 (T3C).
The bracketed alternatives are not decoration. A gas group IIC unit covers hydrogen and acetylene atmospheres and therefore also covers IIB and IIA, while a IIB-marked variant does not; and a T4 temperature class guarantees a maximum surface temperature of 135 °C against the T3 figure of 200 °C. Specifying a unit whose gas group or temperature class sits below the classified zone requirement is the most common compliance failure on retrofit actuator projects, and it is the reason Seven Star LLC asks for the hazardous area classification, gas group, and temperature class alongside the valve data before quoting an SAEx actuator for a site in Oman.
Duty Classification, Self-Locking, and Functional Safety
Within AUMA’s naming convention the SAEx designation denotes multi-turn actuators for open-close duty, while the closely related SAREx designation denotes the modulating-duty version built for continuous positioning service. The distinction is a matter of duty rating and starts per hour rather than of explosion protection, and choosing the open-close SAEx for a control loop — or paying for a modulating SAREx on an isolation valve — is an avoidable specification error. Where a valve is stroked occasionally to a fully open or fully closed position, the SAEx is the correct and more economical selection.
Two further selection points follow from the mechanical design. AUMA notes that self-locking behaviour applies at output speeds up to 90 rpm at 50 Hz, corresponding to 108 rpm at 60 Hz; above those speeds the drive train is not self-locking and the valve position must be held by other means, which matters for rising-stem gate valves that must stay put on loss of power. Motor options extend beyond the standard three-phase AC to single-phase AC and DC variants where site power dictates, and selected configurations are certified for functional safety up to SIL 2, allowing the actuator to be credited within a safety instrumented function rather than only within the basic process control system.
Technical Specifications
The table below summarizes the core specifications of the AUMA SAEx Explosion-Proof Multi-Turn Actuator as supplied by Seven Star LLC.
| Parameter | Specification |
|---|---|
| Model | AUMA SAEx Series |
| Type | Electric, explosion-proof, multi-turn actuator |
| Movement | Multi-turn |
| Motor | Three-phase AC standard; 1-phase AC and DC motor options |
| Manual Operation | Handwheel |
| Protection Class | Up to IP68 |
| Torque Range | Approx. 10 Nm to 16,000 Nm |
| Rotational Speed | 4 rpm to 180 rpm |
| Explosion Protection | ATEX / IECEx / regional hazardous-area certification |
| Typical Valve Types | Globe valves, gate valves, and other multi-turn valve types |
Request a Quote for AUMA SAEx Explosion-Proof Multi-Turn Actuator (ATEX)
Seven Star LLC supplies the AUMA SAEx explosion-proof multi-turn actuator with full manufacturer documentation and regional technical support. Contact our instrumentation and valve automation division for a formal RFQ, to confirm the correct actuator size and certification for your classified zone, or to obtain the complete technical datasheet for project specification. Seven Star LLC ensures every unit shipped across Oman and the GCC is genuine, correctly configured, and backed by local engineering support.
Related Products
- Datasheet AUMA SAEx 07.2 - SAEx 16.2 Datasheet Download
AUMA actuator and gearbox types
SA multi-turn actuators handle open-close duty on gate and globe valves, and SAR is the modulating version; the listing includes the SA 07.2, SA 10.2 and SA 25.1. SAEx and SAREx are the explosion-proof equivalents. Part-turn duty on ball and butterfly valves is covered by SQ and the modulating SQR, or by an SA actuator combined with a GS part-turn gearbox. LE linear thrust units convert multi-turn output to thrust, and GHT multi-turn gearboxes extend the torque range up to 120,000 Nm. PROFOX is the compact actuator line. Special items include the seawater-resistant SGM and SGMR part-turn actuators with bronze housings, the SVC and SVCR globe valve actuators and the FQM fail-safe unit. Integral controls come as AM or AC versions.Where AUMA electric actuators are used
AUMA actuators are found in water, power, oil and gas, marine and general industry. In practice that means isolation and control valves in water treatment and pumping stations, power plant steam and cooling systems, tank farms and pipelines, and sluice gates and dampers.Ordering AUMA actuators and parts: what we need
For a replacement send photos of the actuator, motor and controls nameplates: type, order number, serial number and wiring diagram number. For a new actuator we need:- valve type, required torque or thrust, and turns or stroke
- valve mounting flange and stem or shaft details
- output speed, duty (open-close or modulating)
- supply voltage and frequency, control signals or fieldbus
- enclosure protection, ambient temperature, Ex requirement
