Bosch Rexroth R901278781 4WE10F5X/EG24N9K4/M Directional Spool Valve Supplied by Seven Star LLC

Hydraulic Valves & Components

Hydraulic valves direct, stop and limit the flow of oil in power units, presses, winches and machine tools. This category has just opened and lists one product so far: the Duplomatic DS3 solenoid directional control valve with the ISO 4401-03 mounting interface. Seven Star LLC supplies hydraulic valves and components to maintenance teams and workshops in Oman. The range is growing, and other directional, pressure and flow control valves can be sourced on request against a manufacturer part number.
Read more about Hydraulic Valves & Components
Show sidebar
Duplomatic DS3 Solenoid Directional Control Valve ISO 4401-03 Supplied by Seven Star LLC

Duplomatic DS3 Solenoid Directional Control Valve ISO 4401-03

Duplomatic

Category guide

About Hydraulic Valves & Components

1 product 1 brand

Hydraulic valves direct, stop and limit the flow of oil in power units, presses, winches and machine tools. This category has just opened and lists one product so far: the Duplomatic DS3 solenoid directional control valve with the ISO 4401-03 mounting interface. Seven Star LLC supplies hydraulic valves and components to maintenance teams and workshops in Oman.

The range is growing, and other directional, pressure and flow control valves can be sourced on request against a manufacturer part number.

Solenoid directional control valves and the ISO 4401 interface

A directional control valve uses a sliding spool to connect the pump, tank and two working ports in different combinations, which starts, stops and reverses a cylinder or hydraulic motor. In a solenoid operated valve the spool is shifted by one or two coils and returned by springs. ISO 4401 standardizes the port pattern on the mounting face. Size 03, also called NG6 or CETOP 3, is the smallest common size, and valves of this size from different manufacturers share the same bolt and port layout, so they fit the same subplate or manifold.

Details needed to identify a hydraulic valve

The full ordering code on the nameplate is the most reliable reference. It defines the spool type, the center position, spring arrangement, coil voltage, connector and seal material. If the code is unreadable, send the interface size, the spool symbol from the circuit diagram, the coil voltage, AC or DC, the maximum pressure and the fluid. We check the code against the manufacturer documentation for customers across the GCC.

What to include in your inquiry

These details let us quote the right item the first time.

  • Valve type and size (DN / NPS)
  • Pressure class and end connection
  • Body and trim material
  • Fluid, flow rate, inlet and outlet pressure, temperature
  • Actuator type and fail position
  • Accessories: positioner, limit switches, solenoid

Missing some of them? Send what you have. A nameplate photo or an old part number is enough to start.

Brands in Hydraulic Valves & Components

All brands →

Related categories

Request a Quote for Hydraulic Valves & Components

Looking for a specific model, part number or brand in Hydraulic Valves & Components? Send us your requirements and quantities. Seven Star LLC sources genuine industrial equipment for customers across Oman and the GCC and replies with a formal quotation.
  • Genuine OEM products
  • Supply across Oman & the GCC
  • Formal quotation from our sales team
Request a Quote

Free, no-obligation quotation · takes about 1 minute

Other enquiries: [email protected] · WhatsApp

Frequently Asked Questions

What does ISO 4401-03 mean on a hydraulic valve?
ISO 4401 defines the mounting surfaces for hydraulic directional valves: the position of the P, T, A and B ports and the fixing bolt holes. Size 03 is also known as NG6 or CETOP 3. A valve built to this size bolts onto any subplate or manifold with the same pattern, whatever the make, although flow capacity and pressure limits must still be compared.
Can a directional valve from one manufacturer replace a valve from another?
Mechanically yes, when both follow the same ISO 4401 size. Functionally you must match the spool symbol, including what the ports do in the center position, the spring or detent arrangement, coil voltage and connector type, and seal material for the fluid. Compare the flow and pressure performance limits on the two datasheets, because they differ between spool types.
What is the spool center position and why does it matter?
On a three-position valve the spool rests in the center when neither coil is energized. The center configuration decides what the system does then: a closed center blocks all ports and holds the load, an open center lets pump flow return to tank, and a float center connects both working ports to tank. Choosing the wrong one changes how the machine behaves at rest.
Should I choose AC or DC solenoids on a hydraulic valve?
DC solenoids switch more softly and tolerate a spool that sticks, since their current does not depend on plunger position. AC solenoids switch faster but can overheat if the spool fails to complete its stroke. Many valves use DC coils with a rectifier built into the connector for AC supplies. Always match the coil voltage and type to the control circuit of the machine.
What information do you need to quote a hydraulic directional valve?
Send the complete ordering code from the nameplate. If it is damaged, provide the interface size, the spool symbol, single or double solenoid, coil voltage and connector type, seal material, maximum working pressure and the hydraulic fluid. A photo of the valve and of the circuit diagram symbol helps. We check the details against the manufacturer documentation before we quote.
