JUMO mTRON T Central Processing Unit

Name: JUMO mTRON T Central Processing Unit – Datasheet & Quote
Brand: JUMO

Description

Overview

JUMO mTRON T is a central processing unit that forms the heart of a scalable measuring, control, and automation system, mapping the process image of up to 30 connected input and output modules from a single compact CPU. Combining an integrated web server, an IEC 61131-3 PLC (CODESYS V3.5), 9 program generators, and tamper-proof data recording that satisfies AMS 2750 and CQI-9 requirements, the JUMO mTRON T scales from a simple measuring and control application into a complete plant automation solution.

Backed by manufacturer datasheet documentation, Seven Star LLC proudly supplies the JUMO mTRON T central processing unit to industrial automation, heat treatment, and process control customers across Oman and the wider GCC. Every unit supplied through Seven Star LLC comes with manufacturer documentation and access to local technical support – supporting facility engineers and procurement teams in Muscat, Sohar, and Salalah who specify the JUMO mTRON T.

Working Principle

The JUMO mTRON T central processing unit maintains a process map for up to 30 plug-and-play input and output modules, cyclically processing interface data at a fixed 125 ms timeframe. All configuration and parameter data for the entire system is stored within the base units, meaning individual input or output modules can be swapped without reconfiguring the whole system – a true plug-and-play architecture that minimizes downtime during maintenance or module replacement. The CPU communicates over superordinated interfaces including Ethernet with an integrated web server, USB device connectivity, and an RJ45 system bus, giving operators and engineering teams remote visibility into process values without dedicated SCADA software.

For control applications beyond simple monitoring, the JUMO mTRON T incorporates a full PLC engine compliant with IEC 61131-3 using CODESYS V3.5, alongside an OPC-DA server for integration with plant-level data historians and HMI software. Nine independent program generators and a dedicated math and logic module allow complex sequencing, batch control, and calculation tasks to run directly on the CPU, while 64 configurable limit value monitoring functions provide continuous process safety and quality oversight without requiring an external PLC.

Engineering Design of the JUMO mTRON T

The JUMO mTRON T is housed in a robust metal case designed for DIN rail mounting inside a control cabinet, measuring 135 mm x 101 mm x 67.1 mm (without connection elements) and carrying IP20 protection per DIN EN 60529. The CPU draws a maximum of 350 mA at DC 19.2 V to power modules installed in the same row, and operates across an ambient temperature range of -20°C to +55°C, with UL and DNV approvals supporting deployment in marine and industrial applications requiring third-party certification.

Communication options include two optional fieldbus interfaces alongside the standard USB, Ethernet, and RJ45 system bus connections, allowing the mTRON T to integrate with PROFIBUS-DP or Modbus-based plant architectures via appropriate GSD files and DP master configuration. Battery-buffered RAM and a real-time clock preserve process data and timestamps through power interruptions, and fast wiring of operating voltage and system bus is achieved simply by plugging modules together in sequence, without dedicated wiring for each module’s power and data connections.

Key Features

The JUMO mTRON T combines scalable I/O mapping with genuine PLC-grade control capability that makes it a flexible foundation for measuring, control, and automation systems of any size.

Process mapping for up to 30 plug-and-play input and output modules from a single central processing unit.
An integrated web server provides remote access to process values without dedicated SCADA infrastructure.
A full PLC engine per IEC 61131-3 (CODESYS V3.5) supports complex, standards-based control programming.
An OPC-DA server enables direct integration with plant historians and third-party HMI/SCADA software.
9 program generators and a math and logic module support sequencing, batch control, and calculation tasks.
64 configurable limit value monitoring functions provide continuous process safety and quality oversight.
Tamper-proof data recording satisfies AMS 2750 and CQI-9 requirements for heat treatment quality systems.
Battery-buffered RAM and a real-time clock preserve process data and timestamps through power interruptions.

Industrial Applications

The JUMO mTRON T is deployed across heat treatment and furnace control, food and beverage processing, composting and waste management, and general industrial automation wherever a scalable measuring and control platform with certified data integrity is required. Typical duties include AMS 2750/CQI-9 compliant heat treatment recording, multi-zone process control, and decentralized measurement and automation architectures built from modular I/O.

Working closely with plant engineers in the region, Seven Star LLC distributes the JUMO mTRON T to industrial automation integrators, heat treatment facilities, and process plants throughout Oman and the GCC. The CPU is a strong fit for automation retrofits and new-build control systems across the Sohar and Salalah industrial zones, as well as for food, beverage, and general manufacturing facilities across Muscat that require a scalable, standards-compliant automation platform.

Technical Specifications

The table below summarizes the core specifications of the JUMO mTRON T central processing unit as supplied by Seven Star LLC.

Parameter	Specification
Model	JUMO mTRON T (705001)
I/O Capacity	Up to 30 input/output modules
PLC Standard	IEC 61131-3 (CODESYS V3.5)
Limit Value Monitoring	64 configurable functions
Program Generators	9
Interfaces	USB device, Ethernet (web server), RJ45 system bus, 2 optional fieldbuses
Housing	Metal case, DIN rail mounting
Dimensions (W x H x D)	135 x 101 x 67.1 mm (without connectors)
Protection Type	IP20 (DIN EN 60529)
Ambient Temperature	-20°C to +55°C
Approvals	UL, DNV; AMS 2750, CQI-9 compliant recording

Request a Quote for JUMO mTRON T Central Processing Unit

Seven Star LLC supports the full procurement cycle for the JUMO mTRON T central processing unit, from formal RFQ submission to confirmation of availability and lead time, technical datasheet delivery, and direct consultation with our instrumentation division on I/O module selection, PLC programming, and fieldbus integration for your automation system. With fast quotation turnaround and technical support, we supply every JUMO mTRON T CPU with manufacturer documentation and local technical support. Contact Seven Star LLC today to request a quotation or discuss your automation system requirements.

Reviews

There are no reviews yet.

How would you rate this product?

About brand

JUMO is the German maker of temperature sensors, process controllers, pressure transmitters and liquid analysis instruments. Moritz Kurt Juchheim founded it in Fulda in 1948 as M. K. Juchheim KG, making glass thermometers with six employees. The name JUMO comes from the founder's name. It is still a family company headquartered in Fulda, and the parent company has been called JUMO GmbH & Co. KG since 2003.

Seven Star LLC is an independent supplier in Muscat. We list JUMO RTD and thermocouple probes, thermowells, transmitters, controllers, recorders and water analysis instruments, and supply them to process plants, OEMs, HVAC contractors and water utilities in Oman and the GCC by type number.

JUMO company profile

Established	1948, Fulda, Germany, by Moritz Kurt Juchheim
First products	Glass and contact thermometers; platinum glass sensors from 1966
Ownership	Family-owned; renamed JUMO GmbH & Co. KG in 2003
Product families	RTD and thermocouple probes, thermowells, temperature and pressure transmitters, controllers and thermostats, safety temperature limiters, paperless recorders, liquid analysis and flow and level instruments

Milestones

1948: Moritz Kurt Juchheim founds M. K. Juchheim KG in Fulda, making glass thermometers with six employees.
1966: Platinum glass temperature sensors are added.
2003: The parent company is renamed JUMO GmbH & Co. KG.

JUMO products we list

Family	Models	Typical use
RTD and thermocouple probes	902020, 902030, 902050, 902120, 902006 2xPt100, PROCESStemp, mineral-insulated RTD, 901020 thermocouple, 901210, 902810 hygienic, 902550 surface, 902520 HVAC, MarineTemp	Temperature measurement in pipes, vessels, machines, HVAC and food plants
Thermowells and inserts	909710 thermowells, 909740 measuring inserts	Protecting sensors and replacing them without opening the process
Temperature transmitters	dTRANS T01, T03, T04, T05, T06 SIL, T07 HART, T09, T1000 IO-Link, DELOS T switch	Converting sensor signals to 4-20 mA, HART or IO-Link
Pressure and level	dTRANS p20, p30, p31 hygienic, p33 Ex, p02 DELTA, MIDAS S05, MIDAS DP10, DELOS S02, MAERA S25, NESOS R20	Pressure in process, hydraulic and OEM systems; tank and well level
Controllers, limiters and recorders	DICON touch, IMAGO 500, dTRON 316, iTRON, cTRON, diraTRON 104, eTRON T, safetyM STB/STW, safetyM TB/TW, LOGOSCREEN 601, mTRON T	Furnace, oven and process control, over-temperature protection and recording
Liquid analysis and flow	AQUIS touch S, AQUIS touch P, AQUIS 500 pH, AQUIS 500 CR, dTRANS pH 02, pH electrode, digiLine DO, ecoLine NTU, flowTRANS MAG H20, flowTRANS US W01	pH, conductivity, oxygen and turbidity in water treatment; liquid flow

Choosing a temperature sensor starts with the range and accuracy. A Pt100 RTD is accurate and stable from about -200 to 600 °C and is the usual choice in process plants. A thermocouple (type K or J, for example) covers much higher temperatures and responds faster but is less accurate. The wiring also matters: a 3-wire or 4-wire Pt100 connection cancels the resistance of the cable, while a 2-wire connection adds an error that grows with cable length. That is why a head-mounted transmitter is often fitted close to the sensor.

Where JUMO products are used

In Oman and the GCC, JUMO sensors and controllers are used in oil and gas and chemical plants, food and beverage production, plastics and metal heat treatment, HVAC and district cooling, water and wastewater treatment, swimming pools and marine applications.

Ordering JUMO products: what we need

Send the JUMO type number and the full order code from the label (for example 902020/10-...). For probes, add the sensor type (Pt100, Pt1000, type K or J), the number of wires, the insertion length and diameter, and the process connection. For controllers, add the input, outputs and supply voltage.

Facts checked against JUMO's company history, October 2026.

Browse JUMO products by category: Temperature Instrumentation, Pressure Instrumentation, Liquid Analysis Sensors, Controllers & Data Acquisition, Level Transmitter.

FAQ

Questions about the JUMO mTRON T Central Processing Unit

Answers from our engineering team on installation, compatibility and integration.

01How many input and output modules can the JUMO mTRON T support?

The JUMO mTRON T central processing unit maintains a process map for up to 30 input and output modules, which can be replaced on a plug-and-play basis since configuration and parameter data is stored in the base units rather than the individual modules.

02Does the JUMO mTRON T include PLC functionality?

Yes. The mTRON T incorporates a full PLC engine compliant with IEC 61131-3 using CODESYS V3.5, along with an OPC-DA server for integration with plant historians and HMI/SCADA software, and 9 program generators for individual control tasks.

03Is the JUMO mTRON T suitable for AMS 2750 or CQI-9 compliant heat treatment recording?

Yes. The mTRON T provides tamper-proof data recording that satisfies both AMS 2750 and CQI-9 requirements, making it suitable for heat treatment quality control and traceability applications.

04How is the JUMO mTRON T accessed remotely?

The central processing unit has an integrated web server accessible over its Ethernet interface, allowing operators and engineering staff to view current process values without dedicated SCADA software.
