JUMO DELOS T 902940 Temperature Switch with Display and Analog Output

Name: JUMO DELOS T 902940 Temperature Switch | Seven Star LLC
Brand: JUMO
SKU: DELOS T

Description

A Pt1000 temperature switch with display, PNP outputs and analog signal

The JUMO DELOS T (type 902940) is a highly precise electronic temperature switch made of a protection tube with built-in sensor, a process connection and an attached housing with an LCD display. Depending on the version it works from -50 to +150 degC, -50 to +260 degC or -50 to +500 degC. Output variants are one PNP switching output, two PNP switching outputs, or one PNP switching output plus an analog output of 4 to 20 mA, 0 to 20 mA or 0 to 10 V (or reversed), linearized with temperature. JUMO lists food and pharmaceutical, CIP/SIP plants, mechanical and plant engineering, and air conditioning and refrigeration as applications.

The measuring element is a Pt1000 in four-wire circuit, class A as standard or class AA. A positively lit amber LCD with two groups of four characters and status indication for K1 and K2 shows the value in degC or degF, and the display housing can be swivelled by +/-160 degrees after installation and mirrored by 180 degrees in software. Operation is by a rotary encoder under the sealing screw or by the setup program.

Technical specifications

Parameter	Specification
Basic types	902940/10 -50 to +150 degC; /30 extension tube, to +260 degC; /40 adaption system for thermowell 902812/10, to +260 degC; /50 up to +500 degC with M12 plug for RTD probes
Operating temperature codes	370: -50 to +150 degC; 386: -50 to +260 degC; 408: -50 to +500 degC
Sensor	1 x Pt1000, 4-wire, class A (0.15 + 0.002\|t\|) or AA (0.10 + 0.0017\|t\|)
Whole-device tolerance	0.60 K at 100 degC; 0.75 K at 150 degC; 1.00 K at 200 degC; 1.60 K at 450 degC
Response time in water 0.4 m/s	t0.5 = 3 s; t0.9 = 8 s
Switching outputs	1 or 2 PNP, N/C or N/O, window or hysteresis; on-state voltage drop max. 2 V; up to 250 mA; short-circuit proof; over 10 million cycles
Analog output	4 to 20 mA, 0 to 20 mA or 0 to 10 V, scalable, 3-wire; fault levels 3.4/22 mA, 0/22 mA or 0/10.7 V configurable
Supply	DC 12 to 30 V (24 V nominal); 14 to 30 V for 0-10 V; up to 45 mA without load
Display	Positively lit LCD, amber, 2 x 4 digits, degC/degF, status K1/K2
Switching delay / attenuation	0.00 to 99.99 s
Protection tube	Stainless steel 316 L (1.4404/1.4435) or 316 Ti (1.4751); diameter 3 or 6 mm; electropolished Ra 0.8 um or less
Insertion length EL	50 to 1000 mm
Process connections	G 1/4, G 3/8, G 1/2, M12-M20, 1/2-14 NPT, union nut, compression, CIP conical seal, DIN 11851, clamp, weld, VARIVENT, PEKA
Electrical connection	M12 x 1, 4-pole, A-coded, IEC 60947-5-2; IP67 when plugged in
Ambient (display case)	-25 to +75 degC; storage -40 to +85 degC; 100 % humidity incl. condensation
Vibration / shock	10 g, 10 to 2000 Hz; 50 g for 11 ms and 100 g for 1 ms (stated for /10, /30, /40 at 100 mm)

Selecting the DELOS T version, output and fitting

The order code uses ten blocks: basic type – version – operating temperature – measuring insert – tolerance class – output – tube diameter – insertion length – process connection / extra code. Version 8 is the standard with default settings and 9 is a customer-specific configuration written in plain text. Measuring insert 1013 is the Pt1000 in four-wire circuit. Tolerance class 2 is class A (standard) and 3 is AA; class 0 applies to the /50 type, which uses an external probe.

Output code	Description
470	1 x PNP switching output
471	2 x PNP switching outputs
475	1 x PNP and 1 x analog 4 to 20 mA, configurable
476	1 x PNP and 1 x analog 0 to 20 mA, configurable
477	1 x PNP and 1 x analog 0 to 10 V, configurable

Process connections range from threaded G 1/4, G 3/8, G 1/2 and metric M12 to M20 fittings to hygienic DIN 11851 dairy fittings (DN 10, 25, 32), DIN 32676 clamps (DN 10/20 to DN 50 and 2.5 inch), ball weld sockets, VARIVENT DN 15/10 to DN 50/40, weld sleeves and JUMO PEKA. Extra code 310 steps the 6 mm tube down to 3.8 mm and 810 adds a welding socket for connection 380.

Setting, wiring and where a local switch with display helps

Wire the supply and outputs through the M12 plug according to the installation instructions; the datasheet states that the connection diagram gives only preliminary information. Switching point, release point, window or hysteresis function, switching delay and analog scaling are set with the rotary encoder or the setup program, and the output behaviour outside the scaling range is defined: 4 to 20 mA falls linearly to 3.8 mA and rises to 20.5 mA, and 0 to 10 V rises to 10.2 V. An overcurrent on a switching output shows Err3 (K1) or Err4 (K2) on the display.

With ambient temperatures of -50 degC the function is restricted, which is irrelevant in the Gulf, but the opposite concern applies: keep the display case within +75 degC, and use the extension-tube types on hot lines so the electronics stay inside the rating. Typical jobs include pasteurizer and CIP return monitoring, chiller and cooling-water limits, boiler and heat-exchanger protection, and local temperature indication with a PLC signal on process skids.

Documents and quotation

The JUMO data sheet 902940 is attached for download. Seven Star LLC supplies JUMO temperature switches from Muscat; list the version, temperature code, output, tube, length and fitting and we will quote. Related items are under https://omansevenstar.com/product-category/sensors-transmitters/temperature/.

Datasheets & Documents

Datasheet JUMO data sheet 902940 (DELOS T electronic temperature switch) Download
