LS Electric XGB XBC-DR32H Compact PLC

Overview

The LS Electric XBC-DR32H is a compact main unit from the XGB series, LS Electric’s micro-PLC platform built to deliver maximum control performance in a minimal DIN-rail footprint. This compact-type CPU integrates 16 DC digital inputs and 16 relay outputs directly on the main unit, giving machine builders a self-contained 32-point controller that can stand alone or expand with up to seven additional I/O and special-function modules for larger 254-point systems. The XGB series is widely specified across the GCC for packaging lines, water treatment skids, and building automation panels that need dependable PLC logic without the cost or panel space of a modular rack-based system.

Backed by manufacturer datasheet documentation, Seven Star LLC proudly supplies the XGB XBC-DR32H compact PLC to industrial and manufacturing facilities across the Sultanate of Oman and the wider GCC. Panel builders and OEM machine integrators in Muscat, Sohar, and Salalah rely on the XGB platform for its combination of fast processing, built-in Ethernet communication, and the familiar XG5000 programming environment, which shortens commissioning time on new equipment while remaining compatible with LS Electric’s established engineering base in the region.

Operating Principle

At the heart of the LS Electric XBC-DR32H is a high-performance microprocessor executing IEC 61131-3 program logic at up to 83 nanoseconds per basic instruction step, allowing the controller to scan digital and analog I/O, execute ladder or structured text logic, and update outputs within a single deterministic cycle. The compact CPU integrates its 16 DC inputs and 16 relay outputs directly into the main unit housing, eliminating the wiring and configuration overhead of separate I/O racks for smaller machines, while an internal expansion bus allows up to seven additional digital, analog, or special-function modules to be added when the application grows beyond the onboard 32 points.

Communication is handled through built-in RS-232C and RS-485 serial ports for Modbus RTU and LS Electric’s proprietary Cnet protocol, supplemented on Ethernet-equipped variants by a 10/100 Mbps port supporting Modbus TCP/IP for integration with SCADA systems, HMI panels, and higher-level plant networks. Programming is performed in LS Electric’s XG5000 software using ladder diagram or structured text, and the CPU includes onboard high-speed counter inputs and position control functions capable of handling up to six axes for basic motion applications. The practical result is a controller that consolidates logic control, motion handling, and network connectivity into a single compact unit, reducing panel space and simplifying spare-parts stocking for OEMs standardizing on one PLC family.

Engineering Design of the LS Electric XBC-DR32H

The XGB XBC-DR32H is housed in LS Electric’s compact plastic enclosure engineered for 35 mm DIN-rail mounting, with a footprint of roughly 1.63 inches wide by 3.54 inches high, making it one of the smallest full-featured PLCs available for panels where space is at a premium. The front face carries status LEDs for power, run, and error conditions along with individual input and output indicator LEDs, giving technicians immediate visual feedback during commissioning and troubleshooting without connecting a laptop. Removable terminal blocks simplify field wiring and allow the CPU to be replaced quickly in the event of a fault, minimizing production downtime.

Power is supplied via an integrated AC100–240 V input on the DR-series variants, removing the need for a separate 24 V DC supply for the CPU itself, while relay outputs on the DR32H provide robust switching for contactors, solenoids, and indicator lamps without additional interposing relays for many applications. An onboard real-time clock supports time-stamped data logging and scheduled control sequences, and built-in self-diagnostic routines continuously monitor CPU health, I/O status, and communication link integrity, flagging faults to the XG5000 software or connected HMI for rapid root-cause identification.

Key Features

The LS Electric XBC-DR32H compact PLC is specified across machine and process control projects for the following reasons, and OEMs comparing compact controllers regularly select the LS Electric XBC-DR32H for these traits:

• The LS Electric XBC-DR32H compact main unit integrates 16 DC inputs and 16 relay outputs, delivering a complete 32-point controller in a minimal DIN-rail footprint.
• On the LS Electric XBC-DR32H, high-speed 83 ns/step processing handles demanding logic, high-speed counting, and up to six axes of position control.
• The LS Electric XBC-DR32H expansion capability supports up to seven additional I/O and special-function modules for systems up to 284 I/O points.
• On the LS Electric XBC-DR32H, built-in RS-232C/RS-485 serial ports and optional Ethernet enable Modbus RTU and Modbus TCP/IP connectivity out of the box.
• XG5000 programming software supports ladder diagram and structured text per IEC 61131-3 for familiar, standards-based development.
• Integrated AC100–240 V power input removes the need for a separate DC supply dedicated to the CPU.
• Onboard real-time clock enables time-stamped logging and scheduled sequences without external hardware.
• Built-in self-diagnostics continuously monitor CPU, I/O, and communication health for fast fault identification.

Industrial Applications

The XGB XBC-DR32H compact PLC – and the LS Electric XBC-DR32H specifically – is deployed across packaging machinery, water and wastewater treatment skids, HVAC and building automation panels, and small-to-mid-sized process skids where a full modular PLC rack would be oversized. Its compact footprint and relay outputs make it a natural fit for OEM machine builders retrofitting older relay-logic control panels, while its Modbus TCP/IP connectivity allows integration into existing SCADA architectures on district cooling plants and utility pumping stations without a protocol gateway.

Working closely with plant engineers in the region, Seven Star LLC distributes the XGB XBC-DR32H compact PLC to system integrators, panel builders, and end users throughout Oman and the GCC, supporting projects in the Sohar and Salalah free zones as well as facilities across Muscat, Duqm, and the wider Gulf region. Technical support with selection gives machine OEMs and maintenance teams a local contact for replacement CPUs, expansion modules, and application engineering assistance, with availability and lead time confirmed at quotation.

Technical Specifications

The table below summarizes the core specifications of the LS Electric XBC-DR32H as supplied by Seven Star LLC.

Request a Quote for LS Electric XGB XBC-DR32H Compact PLC

Machine builders and system integrators across Oman and the GCC can request a formal RFQ for the LS Electric XBC-DR32H compact PLC directly from Seven Star LLC. With fast quotation turnaround and technical support, Seven Star LLC supplies on request, provides the full technical datasheet on request, and connects buyers with our automation division for programming support and panel integration guidance. Contact Seven Star LLC today to confirm lead times and pricing for the XGB XBC-DR32H compact PLC.
