JUMO LOGOSCREEN 601 Paperless Recorder with Touchscreen

Name: JUMO LOGOSCREEN 601 Paperless Recorder | Seven Star LLC
Brand: JUMO
SKU: LOGOSCREEN 601

Description

Touch-screen paperless recorder for process and furnace data

The JUMO LOGOSCREEN 601 (type 706521) is a paperless recorder with a 5.7 inch resistive TFT touch screen (640 x 480 pixels, 65 536 colours) and an icon-based operating concept. It is scalable: the base unit with no measuring inputs records 24 process values received through an interface, while option slots add up to six universal analog inputs, two analog outputs, 12 digital inputs and 12 individually switchable digital inputs/outputs, and a changeover relay is standard.

Up to six customer-specific process screens, each with up to 100 objects, can be built, and batch-related information can be attached for batch processes. A version with FDA-compliant data recording meets 21 CFR Part 11 requirements, and an AMS2750 / CQI-9 extra code supports heat-treatment documentation. A structured-text extra code allows individual measuring and recording applications.

Technical specifications

Parameter	Specification
Data sheet type	706521
Display	5.7 inch (14.5 cm) TFT colour, 640 x 480 pixels, resistive touch screen
Inputs (options 1 and 2)	Each 3 analog inputs, 6 digital inputs, 1 analog output; up to 6 inputs, 125 ms sampling
Option 3	12 digital inputs/outputs, including 2 high-speed counting inputs up to 12.5 kHz
Inputs via interface	24 analog, 24 digital and 14 external texts (10 batch, 4 event)
Thermocouples	L, J, U, T, K, E, N, S, R, B, C, D, A1 and Platinel II; typically 0.1 % (0.15 % for S, R, B)
RTD / resistance	Pt100 and others in 2-, 3- and 4-wire circuit; resistance and potentiometer inputs
Interfaces	Ethernet 10/100, USB host, USB device, RS232/RS485 (Modbus or barcode scanner); PROFINET IO device optional
Supply	AC 110-240 V +10/-15 % or AC/DC 20-30 V, 48-63 Hz
Front and cutout	Panel cut-out 138 x 138 mm (+1.0), panel thickness 2 to 8 mm, mounting depth 120.9 mm
Protection	Front IP66, rear IP20 (carrying case version IP20)
Weight	Max. 1.65 kg without terminal cover
Approval as printed	cULus E201387 (UL 61010-1, 3rd ed.) for built-in versions without extra code 970

Configuration and order code

The code runs from type 706521 through the software package (0 none, 1 with setup program, PCA3000 evaluation software, communication software and Audit Trail Manager), the language (8 default German/English), options 1 to 3 (1 analog/digital, 4 twelve digital I/O), the supply (23 or 25) and four groups of extra codes. Extra code 1 offers 260 (math and logic, 6 channels each) and 221 (structured text), extra code 2 offers 887 (manipulation detection with digital certificate) and 888 (FDA 21 CFR Part 11 with digital certificate), and extra code 3 offers 163 (PROFINET IO) and 879 (AMS2750 / CQI-9).

Extra code 970 adds a compact universal carrying case. The data sheet notes that subsequent expansion of option slots is only possible at JUMO, and that the device is a permanently installed field device.

What to plan before ordering

Recording time depends on the chosen cycle: the data sheet shows about 42 days at 125 ms, about 8 months at 1 s and about 41 months at 5 s per channel under its stated conditions. Plan the number of channels and the cycle together with the storage method (USB flash drive, Ethernet or software).

For heat treatment, select the AMS2750 / CQI-9 extra code and state thermocouple types and calibration points when ordering a calibration certificate. For regulated pharmaceutical use, choose the FDA code and the Audit Trail Manager software package.

Documents and quotation

Use the request form to ask for this model with your exact code. The attached JUMO LOGOSCREEN 601 data sheet 706521 (EN) lists all variants and options, and the input options, extra codes and supply voltage should be confirmed before the order is released. Other products of this kind can be found in Controllers & Data Acquisition.

Datasheets & Documents

Datasheet JUMO LOGOSCREEN 601 data sheet 706521 (EN) Download
