Honeywell VersaFlow Coriolis Mass Flow Meter
Overview
The Honeywell VersaFlow Coriolis Mass Flow Meter is engineered to deliver precise mass flow, volumetric flow, density, temperature, and concentration measurement across a wide range of process industries. Available in four sensor variants – Coriolis 100, Coriolis 200, Coriolis 1000, and Coriolis 6000 – the VersaFlow platform addresses everything from small laboratory-scale line sizes to large custody-transfer-grade pipelines, with both bent-tube and straight-tube designs available to suit application complexity.
Seven Star LLC supplies the Honeywell VersaFlow Coriolis Mass Flow Meter as an experienced supply partner to process industries across Oman and the GCC, including oil and gas, petrochemical, and utility operators requiring accurate, direct mass flow measurement. Every meter sourced through Seven Star LLC comes with manufacturer documentation and applications engineering support for installations in Muscat, Sohar, and Salalah.
Measurement and Operating Principle
VersaFlow Coriolis sensors directly measure mass flow rate, product density, and product temperature by exploiting the Coriolis effect induced in vibrating measuring tubes as fluid passes through them, delivering accuracy better than 0.2% of reading plus zero stability on liquid and gas service. Because mass flow is measured directly rather than inferred, VersaFlow Coriolis meters are unaffected by changes in fluid density, viscosity, or pressure that would otherwise require compensation with other flow technologies.
Each sensor pairs with the TWC9400 converter, available in compact or remote mounting and in explosion-proof or non-explosion-proof configurations, with HART or Modbus digital communication. When combined with the TWC9400 converter, VersaFlow Coriolis meters additionally support Entrained Gas Measurement (EGM), maintaining measurement integrity even when process fluids contain gas bubbles or two-phase flow conditions.
Engineering Design of the Honeywell VersaFlow Coriolis
Straight measuring tubes are available in Hastelloy, titanium, or stainless steel construction depending on the sensor model and process fluid compatibility requirements, giving specifiers flexibility to match tube material against corrosive or high-purity process media. Temperature ranges vary by model: Coriolis 100 covers -40°C to +130°C, Coriolis 1000 spans -40°C to +150°C in titanium or 0°C to +100°C in stainless steel, Coriolis 200 covers -45°C to +130°C, and the extended-range Coriolis 6000 operates from -200°C to +400°C for cryogenic and high-temperature service.
Maximum flow rate capacity scales with sensor size: up to 170,000 kg/h for the Coriolis 100, up to 420,000 kg/h for the Coriolis 200, and up to 550,000 kg/h for the larger Coriolis 6000, giving engineers a single measurement technology platform that scales from small chemical dosing lines to large custody-transfer pipelines across Oman’s process facilities.
Key Features
- Direct mass flow, density, and temperature measurement via the Coriolis effect
- Accuracy better than 0.2% of reading plus zero stability
- Four sensor variants (100, 200, 1000, 6000) covering small to large line sizes
- Straight-tube and bent-tube designs in Hastelloy, titanium, or stainless steel
- Extended temperature range down to -200°C on the Coriolis 6000 variant
- TWC9400 converter with HART and Modbus digital communication
- Entrained Gas Measurement (EGM) capability with TWC9400 converter
- Maximum flow rate capacity up to 550,000 kg/h depending on sensor size
Industrial Applications
The VersaFlow Coriolis Mass Flow Meter is applied across Oman’s oil and gas, chemical, and petrochemical sectors for custody transfer, batch dosing, blending, and mass balance applications where direct, density-independent mass flow measurement is essential for accurate accounting and process control. The extended temperature range of the Coriolis 6000 variant makes it particularly suited to cryogenic LNG and high-temperature process fluid applications common in Sohar’s industrial complex.
As a trusted supplier of Honeywell products, Seven Star LLC helps ensure VersaFlow Coriolis meters deployed across Muscat, Sohar, and Salalah are correctly sized for the target application and supplied with manufacturer documentation and technical support. This genuine relationship gives Omani process operators confidence in both instrument accuracy and long-term measurement reliability for custody transfer and process accounting duties.
Technical Specifications
| Model | Honeywell VersaFlow Coriolis (100 / 200 / 1000 / 6000) |
|---|---|
| Measurement Principle | Coriolis effect – direct mass flow measurement |
| Accuracy | Better than 0.2% of reading + zero stability (liquid/gas) |
| Tube Material | Hastelloy, titanium, or stainless steel |
| Temperature Range | -200°C to +400°C (model dependent) |
| Maximum Flow Rate | Up to 550,000 kg/h (model dependent) |
| Converter | TWC9400 (compact or remote, Ex/non-Ex) |
| Communication | HART, Modbus |
| Special Capability | Entrained Gas Measurement (EGM) with TWC9400 |
Why Choose Seven Star LLC for Honeywell VersaFlow Coriolis Flow Meters
Coriolis mass flow measurement only delivers its accuracy advantage when sensor size, wetted material, and pressure rating are matched to the real flow range and process fluid, since an oversized sensor loses turndown accuracy at low flow while an undersized one creates unnecessary pressure drop across the line. Seven Star LLC works with your process engineers to confirm the correct VersaFlow sensor size and material configuration for your application before order confirmation, drawing on our trusted Honeywell suppliership across Oman and the wider GCC. We also support custody transfer and mass-balance applications across Muscat, Sohar, and Salalah with calibration certificate planning, so measurement points remain defensible for both internal accounting and regulatory reporting purposes, and we advise on remote versus integral transmitter mounting where vibration or thermal exposure at the sensor location makes that choice matter.
Contact Seven Star LLC today to request a quotation for the Honeywell VersaFlow Coriolis Mass Flow Meter with correctly sized sensor selection and expert technical support for mass flow measurement projects across Oman and the GCC.
Related Products
- Yokogawa ADMAG AXG Magnetic Flowmeter
- ABB-Thermal mass flowmeter SensyMaster FMT400
- ABB-Orifice carrier assembly with integral manifold FPD175
- pFlow E5 Ultrasonic Energy/BTU Meter
- pFlow E3RO Ultrasonic Thermal Energy Meter
- ABB-Glass tube variable area flowmeter Purgemaster FGM6100
- Titan Enterprises OG3 Oval Gear Flow Meter
- Datasheet Honeywell VersaFlow Coriolis Mass Flow Meter Datasheet Download
Honeywell product families on this page
Open path infrared detection is represented by the Searchline Excel and the newer Searchline Excel Plus. Point detection includes the Sensepoint XCD in flammable and toxic versions, for example the SPXCDALMG1 hydrogen detector, the Sensepoint XRL and the XNX universal transmitter. The FS24X Plus is a triple infrared flame detector. Replacement cells such as the SR-X2V oxygen sensor and the SR-W-MP75C MICROpeL combustible sensor are also listed. Process instruments include SmartLine STG700 and STG800 gauge pressure transmitters, the STR82D remote seal transmitter and the VersaFlow Coriolis mass flow meter. Recorder consumables such as chart pens are also sourced.Where Honeywell detectors and transmitters are used
Gas and flame detectors guard wellheads, compressor stations, tank farms, loading bays, process units and utility buildings, and report to the fire and gas system. Open path units watch plant boundaries and long pipe racks. SmartLine transmitters and VersaFlow meters measure pressure and flow in refining, gas processing, chemicals and power.Ordering Honeywell gas detection parts: what we need
Send the full part number from the label, such as SPXCDALMG1 or 02104-N-XSSA, and the serial number. For gas detectors state the target gas and measuring span, housing material, cable entry thread, output (4-20 mA, relays, Modbus) and the approval required. For replacement sensors name the detector model they go into. For SmartLine transmitters send the complete model selection string.Browse Honeywell products by category: Fire & Gas Detector, Vibration, Flowmeters, Pressure Instrumentation, Temperature Instrumentation.
