Turck CMVT-QR20 Vibration & Temperature Sensor
Overview
The Turck CMVT-QR20 is a compact condition monitoring sensor that continuously measures vibration and temperature on rotating machinery, giving maintenance teams the early warning needed to prevent unplanned downtime. Detecting acceleration and velocity across three axes with an RMS measuring range up to 16 g and a temperature range of -40°C to +85°C, the CMVT-QR20 transmits process data via IO-Link and/or simple switching outputs, making it equally suited to new IIoT-enabled installations and retrofits onto existing PLC-based systems.
With fast quotation turnaround and technical support, Seven Star LLC proudly supplies the CMVT-QR20 vibration and temperature sensor to rotating equipment reliability teams and maintenance departments across Oman and the wider GCC. Every sensor shipped from our Muscat-based instrumentation division includes full factory documentation, and our technical team supports IO-Link master selection, threshold configuration, and installation for clients throughout the Sultanate of Oman.
Turck CMVT-QR20 Operating Principle
The Turck CMVT-QR20 uses an internal MEMS accelerometer sampling at 6.6 kHz to capture raw vibration data across all three spatial axes simultaneously, then computes RMS acceleration (up to 16 g) and RMS velocity (up to 320 mm/s at 78 Hz) values on board before transmitting the processed results. A co-located temperature sensor monitors housing temperature across -40°C to +85°C, giving a combined mechanical and thermal health signature for the monitored asset from a single compact device. Both vibration and temperature values, along with warning and alarm status, are transmitted over the standardized IO-Link protocol to a compatible master or gateway.
Because the alarm and warning thresholds are freely parameterizable through IO-Link, plant reliability engineers can tailor trip points to the specific ISO 10816-3 vibration severity zone applicable to each machine class, rather than relying on a fixed factory setting. In SIO mode, the sensor also outputs simple PNP/NPN switching signals for direct wiring into existing relay logic or PLC digital inputs where a full IO-Link infrastructure is not yet in place, allowing a phased migration toward condition-based maintenance without replacing existing control wiring.
Engineering Design of the Turck CMVT-QR20
The Turck CMVT-QR20 is housed in a rectangular, chemical-resistant Ultem plastic enclosure measuring 71.6 x 62.6 x 20 mm, engineered for direct bolt-on or magnetic mounting to motor housings, pump casings, gearboxes, and compressor frames. A single M12 x 1 male connector provides both power and IO-Link communication through a standard 4-pin cable, simplifying installation and reducing the wiring footprint compared to traditional vibration monitoring systems that require separate signal conditioning modules.
The sensor is rated IP68 and IP69K, withstanding both continuous submersion and high-pressure washdown, and is qualified to 200 g shock resistance and 20 g vibration resistance across 5 hours per axis, ensuring the monitoring device itself survives the same harsh conditions as the machinery it protects. Two status LEDs provide local visual indication of power and switching state, and an optional magnetic mounting kit (MAGKIT-M5) allows tool-free installation and relocation during commissioning or troubleshooting without drilling additional mounting holes.
Key Features
The Turck CMVT-QR20 vibration and temperature sensor equips rotating equipment reliability programs with a rugged, IO-Link-ready condition monitoring platform, and the Turck CMVT-QR20 is built for continuous duty:
- Measures RMS acceleration up to 16 g and RMS velocity up to 320 mm/s across three axes simultaneously.
- Monitors housing temperature from -40°C to +85°C alongside vibration data from a single compact sensor.
- Transmits process values and diagnostic status via standardized IO-Link, with SIO-mode PNP/NPN switching outputs for legacy wiring.
- Supports freely parameterizable warning and alarm thresholds tailored to ISO 10816-3 machine severity zones.
- Is rated IP68/IP69K for continuous submersion and high-pressure washdown durability.
- Withstands 200 g shock and 20 g vibration resistance, ensuring reliable operation on the same machinery it monitors.
- Connects via a single M12 x 1 4-pin connector for combined power and data, minimizing installation wiring.
- Offers a magnetic mounting accessory for tool-free installation and relocation during commissioning.
Industrial Applications
The Turck CMVT-QR20 is widely deployed for predictive maintenance on pumps, electric motors, compressors, and engines across oil and gas production facilities, power generation plants, and manufacturing lines. Its washdown-rated IP69K housing also makes it suitable for food, beverage, and water treatment facilities where equipment is regularly cleaned with high-pressure spray, extending condition monitoring coverage into hygienic and district cooling plant environments common across the region.
With engineering support in Muscat, Seven Star LLC supplies the CMVT-QR20 vibration and temperature sensor to reliability engineering teams, RO desalination operators, and industrial plants across Muscat, the Sohar and Salalah economic zones, and neighboring GCC markets. Our IO-Link integration support means clients receive Turck hardware with manufacturer documentation and local technical assistance.
Technical Specifications
Key specifications for the Turck CMVT-QR20 vibration and temperature sensor, including the Turck CMVT-QR20 IO-Link communication parameters, are summarized below.
| Parameter | Specification |
|---|---|
| Model | CMVT-QR20-IOLX3-H1141 |
| Sampling rate | 6.6 kHz |
| RMS acceleration range | 16 g, resolution 0.01 g |
| RMS velocity range | 0–320 mm/s @ 78 Hz, resolution 0.01 mm/s |
| Temperature range | -40°C to +85°C |
| Communication | IO-Link (COM3, 230.4 kBaud) / SIO PNP-NPN |
| Operating voltage | 18–30 VDC (IO-Link); 10–30 VDC (SIO) |
| Housing material | Plastic, Ultem, rectangular QR20 |
| Protection rating | IP68 / IP69K |
| Electrical connection | M12 x 1, 4-pin male connector |
| Shock / vibration resistance | 200 g shock; 20 g, 5 h/axis vibration |
Also available: Turck BI5-M18-AP6X-H1141 Inductive Proximity Sensor
Request a Quote for Turck CMVT-QR20 Vibration & Temperature Sensor
Seven Star LLC supports formal RFQ submissions, confirms availability and lead time at quotation, and provides full technical datasheets for the Turck CMVT-QR20 vibration and temperature sensor on request. Contact our instrumentation division to confirm IO-Link master compatibility and mounting accessories for your application.
Related Products
- Datasheet Turck CMVT-QR20 Vibration & Temperature Sensor Datasheet Download
Turck sensors listed here
In BI5-M18-AP6X-H1141, BI is a flush-mountable inductive sensor, 5 is the rated switching distance in millimeters and M18 is the threaded barrel. AP6X is a three-wire DC output, PNP normally open, and H1141 is the M12 connector. The CMVT-QR20 is a small rectangular sensor that measures vibration on three axes together with temperature and reports both over IO-Link for condition monitoring.Ordering Turck sensors: what we need
Send the full type code and the ID number printed on the sensor or its bag label. If the label is lost, give the housing size, flush or non-flush mounting, output type, supply voltage and connection.Browse Turck products by category: Vibration, Sensors & Transmitters.
