MEDC BG Manual Call Point – BGEB4B6B1DDCF7R (Ex de, ATEX)

Overview

The MEDC BGEB4B6B1DDCF7R is an explosion-proof break-glass manual alarm call point from the MEDC BG manual call point range, part of the Eaton Crouse-Hinds series. It is used to raise fire or emergency alarms by hand in hazardous areas, both onshore and offshore. The enclosure is corrosion-free glass reinforced polyester. The break glass is covered by a membrane that protects the operator from glass fragments, so no hammer is needed to operate it.

According to the Eaton BG ordering code, the part number breaks down as follows:

• BG: model
• EB: ATEX/CENELEC Ex de certification
• 4B6B: two M20 entries, in positions 4 and 6
• 1: glass label reading “Fire Break glass – press here”
• D: DC voltage
• D: double changeover switch
• C and F: series resistor and earth continuity options
• 7: seven 2.5 mm2 terminals
• R: red finish

Key Features

• ATEX Ex de certified GRP enclosure, rated IP66 and IP67
• Membrane-covered break glass, so no hammer is required
• Double changeover switch for alarm loop and monitoring connections
• Series resistor fitted for panel line monitoring
• Earth continuity plate for use with metal cable glands
• Captive cover screws and a key-operated test facility
• BG range certified to SIL 2 (IEC 61508)

Technical Specifications

Applications

• Manual fire alarm initiation on escape routes and at process area exits in refineries, gas plants and terminals
• Offshore platforms and marine installations
• Emergency alarm activation in Zone 1 and Zone 2 gas areas, and Zone 21 and Zone 22 dust areas
• Supervised fire and gas loops where the panel uses resistors to monitor the line

MEDC BG BGEB4B6B1DDCF7R Ordering Code and Options

Using the Eaton ordering table, BGEB4B6B1DDCF7R breaks down as follows. BG is the model. EB is ATEX/CENELEC Ex de certification. 4B6B gives the cable entries: B means M20 and the digits are the entry positions, so there are M20 entries at positions 4 and 6, both on the bottom face. Label code 1 is the glass label with fire break-glass wording. The first D is the DC voltage version and the second D is a double changeover switch. Option C is a series resistor and option F is earth continuity for metal glands. 7 means seven 2.5 mm² terminals and R is the standard red finish.

Because resistors are fitted, the ambient range narrows from -40 to +70 °C (switch only) to -25 to +50 °C. Resistor versions are offered up to 24 V only and the resistor is rated 24 V DC, 0.05 A, with a minimum value of 100 Ω for BGE units. The resistor value is not encoded in the part number and has to be specified with the order. The 250 V AC switch rating applies to switch-only versions and is not usable on this resistor-fitted DC configuration.

MEDC BG Selection Notes

Other variants in the same range change only the relevant code. Certification can be IECEx Ex de (EJ), Ex ia (IB, IJ), UL (UL, UW) or uncertified weatherproof (WN); UL versions use 1/2 inch NPT entries. Options include an LED indicator (A), lift flap (B), EOL resistor (D), diode (E), combined series and EOL resistors (S), a plastic deformable element in place of the glass (P) and a break-glass hammer (H). Finishes other than red are natural black, blue, yellow, grey and yellow/black stripes.

Why Seven Star LLC

Seven Star LLC supplies MEDC hazardous-area alarm equipment to industrial and EPC customers across Oman and the GCC. Call points are safety-critical, so before quoting we decode the full order code and check the certification, resistor values, switch arrangement and entries against your loop design or the existing nameplate.

Also available: MEDC LD15 Ex LED Beacon

Request a Quote for MEDC BG Manual Call Point – BGEB4B6B1DDCF7R (Ex de, ATEX)

Submit a formal inquiry through our RFQ page with the part number BGEB4B6B1DDCF7R, the quantity, the required series resistor value, the loop voltage and any label wording. Our engineers will verify the MEDC BG manual call point configuration for your site and provide a complete quotation.
