JUMO ZELOS C01 LS Capacitive Level Switch

Name: JUMO ZELOS C01 LS Capacitive Level Switch | Seven Star LLC
Brand: JUMO
SKU: ZELOS C01 LS

Description

A compact capacitive point level switch with IO-Link and a colour status display

The JUMO ZELOS C01 LS (type 408401) detects the point level of solid and liquid media for overfill and dry-run protection, and can also detect media in separation and cleaning processes. A PEEK-tipped capacitive probe sits in a 60 g stainless-steel body, and the colour status ring follows NAMUR NE107, IO-Link or customer-specific colours. It runs in IO-Link mode or in standard IO mode with two outputs (PNP, NPN or push-pull), and the datasheet lists CIP/SIP suitability, up to 60 bar process pressure, and approvals including shipbuilding, WHG overfill protection, EHEDG/3A hygienic connections and intrinsically safe Ex i versions. Railway use to EN 50155 vibration category 1B is listed among the areas of application.

Technical specifications

Parameter	Specification
Type	408401 JUMO ZELOS C01 LS, capacitive level switch
Basic type extension	000 none; 062 shipbuilding; 065 hygienic; 262 WHG; 263 WHG + Ex i; 265 WHG + Ex i + hygienic; 362 Ex i; 365 Ex i + hygienic; 662 shipbuilding + Ex i
Output codes	447 digital push-pull; 458 IO-Link plus digital output; 469 NPN; 470 PNP
Ex markings	ATEX II 1 G Ex ia IIC T4 Ga; II 1/3 D Ex ta/tc IIIC T200 145 °C Da/Dc; IECEx Ex ia IIC T4 Ga (submitted)
Supply	24 V DC SELV; 9.6 to 36 V (PNP, NPN, push-pull); 18 to 30 V (IO-Link); 9.6 to 30 V (Ex i)
Power consumption	Idle 0.45 W; IO-Link 0.6 W (7 W with switching output); 15 W with two switching outputs loaded
Switching outputs	Up to 200 mA each, drop 1 V max., short-circuit proof, hysteresis or window, delay 0.3 to 60 s, PWM 50 to 1000 ms
Accuracy	Hysteresis and repeatability ±1 mm; filter 0 to 100 s; switch-on delay under 2 s
IO-Link	Device V 1.1, COM3 230.4 kBaud, cycle time 0.7 ms or more; Common, Smart Sensor and Firmware Update profiles
Process temperature	-40 to +115 °C standard (CIP/SIP 135 °C for under 1 h/day); -40 to +200 °C with sliding connection
Process pressure	-1 to +60 bar
Ambient and storage	Ambient (M12 plug) -40 to +85 °C; storage -40 to +80 °C; altitude up to 5300 m
Protection	IP67, IP68 (10 m, 240 h with suitable cable), IP69
Process connections	105 G 3/4; 133 M24 x 1.5; 360 sliding G 1/2 100 mm; 361 sliding G 1/2 250 mm; 387 G 1/2 with PEEK seal; 997 JUMO PEKA hygienic
Materials	PEEK wetted part, FKM/FPM, 316L (sliding connection), housing 304; Ra 0.8 µm; 60 g with G 1/2
Vibration and shock	EN 50155 category 1B; 4 g at 25 to 100 Hz; shock 3 g vertical, 5 g other axes for 30 ms

Ordering and stock versions

The code is 408401/ extension – electrical connection – process connection – output – medium temperature / extra code. The only electrical connection is the M12 plug (036). Temperature code 500 is -40 to +115 °C and 487 is -40 to +200 °C, the latter used with the sliding connection. Extra codes are 061 (UL), 374 (3.1 material certificate, not with connections 360 or 631), 634 (TAG) and 881 (drinking-water approval). The datasheet example is 408401/000-036-387-470-500/061. Stock versions are 408401/000-036-387-458-500/061 (00771685), 408401/000-036-387-470-500/061 (00778470), 408401/062-036-387-470-500/061 shipbuilding (00771699), 408401/065 hygienic with IO-Link (00771693) or PNP (00771694) and 408401/362-036-387-470-500/061 Ex i (00771696). Accessories include a magnetic teach pen (00736330), welding sockets, hygienic T-pieces with PEKA or G 1/2 connection, a VARIVENT adapter and M12 cables.

Fitting it to the application

A capacitive switch reacts to the dielectric difference between air and medium, so conductive liquids, oils and many powders can be handled, and the wet test or teach function lets the installer set the switch point with the real medium. The sliding connection (G 1/2, 100 or 250 mm) allows adjustment of the switching height. For hot-region plants typical placements are overfill protection on fuel and chemical day tanks, pump dry-run protection on water skids, and low-level alarms on hygienic dairy and beverage lines. The product also lists drinking-water approval as an option. For float-type switches see the NESOS R20 LT and browse the level instrumentation category for transmitters and probes.

When requesting a quotation, state the medium, its dielectric behaviour, the temperature and pressure range, and the process connection. Choose the output code: push-pull, NPN, PNP or IO-Link with a digital output. Special extensions cover shipbuilding, hygienic installation, WHG overfill protection and Ex i, and the sliding process connection allows media up to 200 °C. The switching point can be set with hysteresis or window functions and a delay from 0.3 to 60 s, so describe foaming or splashing tanks. The supply is 9.6 to 36 V DC for standard outputs and 9.6 to 30 V for the Ex i version.

The probe is a capacitive level switch for tanks and vessels. IO-Link parameterisation allows the switching point and delays to be set for the actual medium, which helps when buildup or foam forms on the sensor tip during operation.

Documents and quotation

The hosted document is JUMO data sheet 408401 (16 pages, English). Approvals depend on version; consult the certificates and the special conditions for safe use before installing in hazardous areas. Seven Star LLC is an independent supplier in Muscat; send the code and medium for a quotation.
