Brand: Promotech
Promotech PRO-2 PB Compact Pipe Beveller
Description
A narrow pipe beveller for boiler tubes and tight spaces
The Promotech PRO-2 PB is a compact portable machine that faces and bevels the ends of small-bore pipes and tubes in carbon steel, stainless steel, aluminium alloys and copper-nickel. It locks inside the bore on a self-centring expandable mandrel and cuts with a single tool bit, leaving a machined weld preparation without heat input.
Its housing is only 48 mm wide, which is the main reason it is chosen for boiler water walls, tube panels and other places where tubes run close together. A wet multi-disc friction clutch protects the gearing if the tool jams in the cut.
Technical specifications
| Parameter | Specification |
|---|---|
| Manufacturer / model | Promotech / PRO-2 PB |
| Standard pipe range | 19.5 mm ID to 48 mm OD (0.77–1.89 in) |
| With small mandrel set ZST-0731-03-00-00-0 | 15.5 mm ID to 29 mm OD, max. wall 3.5 mm |
| With extension set ZST-0731-02-00-00-0 | 38 mm ID to 60.3 mm OD |
| Maximum wall thickness | 8 mm (0.32 in) |
| Pneumatic version | 800 W; 105 rpm nominal; 0.6 MPa (87 psi); 1,600 l/min (56.5 CFM); CEJN 410 coupling |
| Electric version | 1,100 W; 1~ 220–240 V, 50–60 Hz; 10–134 rpm (gear 1), 30–377 rpm (gear 2) |
| Battery version | 18 V DC; 10–60 rpm (gear 1), 30–205 rpm (gear 2) |
| Weight with motor | 7.6 kg (air); 7.4 kg (electric); 6.5 kg including battery |
| Housing width | 48 mm |
Choosing drive, mandrel and tool bits
The standard set is supplied without a motor, so the drive is selected separately: pneumatic motor NPD-0472-03-00-00-0 with its adapter and driver, electric motor SLN-000238 (230 V) with driver ZBI-0567-26-00-00-0, or the brushless battery drive WRT-000024 with 4.0, 5.5 or 10.0 Ah packs and an air-cooled charger. The air version suits plants with a reliable compressed-air supply; the battery version removes hoses and cables where the machine has to be carried along a tube wall.
The standard mandrel covers 19.5–38 mm ID and comes with four sets of spreaders and expansion sleeves. Tool bits are ordered by profile: 0° facing bits (short and long), and 30°, 37.5° and 45° bevelling bits, each in a steel version (NOZ-000071 to NOZ-000075) and a TiAlN-coated stainless version (NOZ-000078 to NOZ-000082).
Shipping set and related machines
The PRO-2 PB is delivered in a plastic box with the standard mandrel, tool bit holder, handle, a set of tools, a tool box, a coolant container with nozzle and the operator's manual. Tool bits and the drive are added to the order. For pipes up to 114 mm OD the larger Promotech PRO-5 PB follows the same ID-clamping principle.
Documents and quotation
The Promotech PRO-2 PB product sheet, with accessory and tool bit codes, is attached to this page. More end-preparation equipment is listed under Pipe Cutting & Bevelling Machines.
For a quotation, give the tube ID, OD and wall thickness, the material, the bevel profile and the preferred drive (air, 230 V or battery).
Datasheets & Documents
- Datasheet Promotech PRO-2 PB product sheet (EN, rev. 25.02) Download
Reviews (0)
About brand
Promotech is a Polish manufacturer of portable machine tools for the metal industry, delivering machinery since 1987 from its own design and production facility in Poland. Its range covers magnetic drilling machines, plate and pipe bevelling machines, welding and cutting tractors and welding automation. Seven Star LLC, an independent supplier in Muscat, lists the Promotech PRO-5 PB portable pipe beveller and sources Promotech machines for fabrication and maintenance teams.
Promotech product groups
The catalogue is organised into drilling and punching machines, plate and pipe bevellers, welding and cutting tractors with their tracks and accessories, welding and cutting automation, and wire feeder booms. Several machines can also be run from the Cordless Alliance System (CAS) battery platform. The PRO-5 PB listed here is an ID-clamping pipe beveller for small-bore pipe and tube, offered with electric, pneumatic or battery drive.Ordering Promotech machines: what we need
Give the exact model, the drive you want and, for electric machines, the site voltage. For bevellers, add the pipe inside and outside diameters, the wall thickness, the material and the bevel profile, because mandrels, spindle discs and tool bits depend on them. For spare parts, send the Promotech part number or a nameplate photo.
Related products
Frequently Asked Questions
What pipe sizes does the Promotech PRO-2 PB cover?
19.5 mm ID to 48 mm OD as standard; 15.5–29 mm and 38–60.3 mm with optional sets.
How wide is the PRO-2 PB housing?
48 mm, which suits closely spaced boiler tubes.
Which drives are available for the PRO-2 PB?
Pneumatic 800 W, electric 1,100 W at 220–240 V, or an 18 V battery drive.
What is the maximum wall thickness for the PRO-2 PB?
8 mm on the standard range and 3.5 mm with the small mandrel set.
Is a motor included in the PRO-2 PB standard set?
No. The motor or battery drive and tool bits are ordered separately.
