Brand: Promotech
Promotech RAIL TITAN 2 Modular Rail Welding Tractor
Description
A modular rail carriage for welding, cutting and gouging
The Promotech RAIL TITAN 2 is a rack-and-pinion tractor that runs on rigid, semi-flexible, Hi-Flex or ring tracks and can be configured for TIG and MIG/MAG welding, oxy-fuel or plasma cutting and gouging on flat or curved plate, tube and pipe. Its signal connections are designed for HF immunity, so it can carry a TIG torch, and its built-in linear oscillator produces straight, triangle, trapezoid and square weld paths.
Tracks fixed with magnetic units hold it on carbon steel; a vacuum track system with pump and vacuum units fixes it on stainless steel and aluminium. Because the drive is rack-and-pinion rather than friction, it works in all positions, including vertical and overhead.
Technical specifications
| Parameter | Specification |
|---|---|
| Manufacturer / model | Promotech / RAIL TITAN 2 |
| Supply voltage / power | 1~ 100–240 V, 50–60 Hz / 120 W |
| Welding positions (EN ISO 6947 / AWS) | PA/1F/1G, PB/2F, PC/2G, PD/4F, PE/4G, PF/3G, PG/3G; PG/3F on request |
| Track fixing on round workpieces | ring tracks 200 mm–3 m OD; Hi-Flex min. 1.5 m OD or 3.4 m ID; semi-flex min. 10 m OD |
| Torch types | MIG/MAG, TIG, oxy-fuel, plasma; MIG/MAG torch 16–22 mm |
| Min. thickness for magnetic clamping | 5 mm |
| Pulling force | 400 N horizontal; 315 N vertical |
| Travel speed | 0–250 cm/min (0–98 in/min) horizontal and vertical |
| Oscillation | linear; width 0.1–11.8 cm; speed 10–200 cm/min; dwell 0–5 s at centre and ends; max. 100 N |
| Weight incl. standard accessories | 13 kg (29 lb) |
| Order number | WOZ-0813-10-20-00-0 |
Weld paths and operator controls
Trapezoid mode keeps the tractor moving during dwell, square mode moves it only during dwell, triangle mode moves it only while weaving and straight mode switches oscillation off. Adjustments are made from a remote pendant with three rotary function knobs, so the welder does not need to lift the helmet, and a mirror switch reverses left-right torch correction depending on which side of the joint the operator stands. Stitch paths can be programmed.
An optional seam-tracking attachment CZJ-0654-05-00-00-0 with motorised vertical slide OSK-0654-04-00-00-0 corrects torch position horizontally and vertically, with or without oscillation, using interchangeable sensor tips.
Track selection
Rigid 2 m tracks suit straight seams and running off the workpiece edge; semi-flexible 2 m tracks bend to a 5 m radius without permanent deformation; Hi-Flex tracks wrap vessels from 1.5 m OD; ring tracks fit pipes from 200 mm to 3 m OD and can be supported on bolts, magnets or plastic feet. Magnetic, heat-resistant, pivoting and spacing-adjustable units mount the tracks. The standard set includes the pendant, three signal cables, power cord, 6.5 m arc-ignition cable, 300 mm rod and rack, clamping block, torch holder, cable anchor and contact block.
Documents and quotation
The Promotech RAIL TITAN 2 product sheet is available on this page; see also Welding Robots & Automation.
For a quotation, describe the workpiece diameter or shape, material, process (TIG, MIG/MAG or cutting), track length and whether seam tracking is needed.
Datasheets & Documents
- Datasheet Promotech RAIL TITAN 2 product sheet (EN, rev. 26.02) Download
Reviews (0)
About brand
Promotech is a Polish manufacturer of portable machine tools for the metal industry, delivering machinery since 1987 from its own design and production facility in Poland. Its range covers magnetic drilling machines, plate and pipe bevelling machines, welding and cutting tractors and welding automation. Seven Star LLC, an independent supplier in Muscat, lists the Promotech PRO-5 PB portable pipe beveller and sources Promotech machines for fabrication and maintenance teams.
Promotech product groups
The catalogue is organised into drilling and punching machines, plate and pipe bevellers, welding and cutting tractors with their tracks and accessories, welding and cutting automation, and wire feeder booms. Several machines can also be run from the Cordless Alliance System (CAS) battery platform. The PRO-5 PB listed here is an ID-clamping pipe beveller for small-bore pipe and tube, offered with electric, pneumatic or battery drive.
Ordering Promotech machines: what we need
Give the exact model, the drive you want and, for electric machines, the site voltage. For bevellers, add the pipe inside and outside diameters, the wall thickness, the material and the bevel profile, because mandrels, spindle discs and tool bits depend on them. For spare parts, send the Promotech part number or a nameplate photo.
Related products
Frequently Asked Questions
Can the RAIL TITAN 2 be used for TIG welding?
Yes. Its signal sockets are HF resistant and it accepts TIG, MIG/MAG, oxy-fuel and plasma torches.
What oscillation does the RAIL TITAN 2 provide?
Linear oscillation 0.1–11.8 cm wide at 10–200 cm/min, with 0–5 s dwell, in four weld path modes.
Can the RAIL TITAN 2 work on stainless steel or aluminium?
Yes, using the vacuum track system with pump and vacuum units.
What pipe sizes do the RAIL TITAN 2 ring tracks fit?
Ring tracks cover 200 mm to 3 m outside diameter.
What is the RAIL TITAN 2 order number?
WOZ-0813-10-20-00-0 for the tractor with standard accessories.
