Tri Tool 214B BEVELMASTER Pipe Beveler

Name: Tri Tool 214B BEVELMASTER Pipe Beveler | Seven Star LLC
Brand: Tri Tool
SKU: 214B

The Tri Tool 214B BEVELMASTER covers the 4 in to 14 in band that dominates plant piping and fabrication shops. It is an ID-mounted portable lathe that bevels, faces and counterbores pipe ends, with an in-line feed knob at the rear and a pneumatic motor at a right angle to the lathe head. At roughly 36.3 kg (80 lb) and fitted with a carrying handle, it can still be handled by one operator.

Mid-range lathe for 4 in to 14 in pipe

Tri Tool rates the 214B for 4 in pipe from schedule 5 through 160 and for 5 in through 14 in pipe in all schedules. On tubing it bevels walls up to 33.4 mm (1.32 in) with a maximum OD of 355.6 mm (14.00 in) and a minimum ID of 87.4 mm (3.44 in). Heavier walls are possible when the bore stays above 3.44 in and the OD below 14 in, and counterboring covers IDs from 87.4 to 330.2 mm.

The standard system includes the 214B sub-assembly, two aluminium tool holders and one steel tool holder, mandrel assembly, air motor, wrench kit, carrying case and operator’s manual. All tools needed to run it are supplied except the tool bits.

Technical specifications

Parameter	Specification
Manufacturer / model	Tri Tool / 214B (Air) BEVELMASTER
Pipe range	4 in Sch 5–160; 5–14 in all schedules
Maximum wall thickness	33.4 mm (1.32 in) for standard schedules in range
Counterbore ID range	87.4–330.2 mm (3.44–13.75 in)
Rotating diameter	389.9 mm (15.35 in)
Weight	36.3 kg (80 lb)
Cutting head speed	20 rpm max.; 10 rpm at max. HP; 5–22 rpm functional range
Pneumatic motor	310 rpm free speed; 155 rpm at max. HP; gear-driven final drive
Air requirement	40 L/s (85 cfm) at 621 kPa (90 psi), through an FRL
Feed	2.1 mm (0.083 in) per turn of the in-line handle; 50.8 mm (2.00 in) max. travel
Other drives	115 V and 230 V electric and hydraulic versions available
Envelope drawing	77-1717

Low head speed, high torque

Compared with the 208B, the 214B turns its head much more slowly, about 5 rpm at 14 in and 16 rpm at 4 in for 200 surface inches per minute, which keeps cutting speed sensible on the larger diameters and heavier walls. Mild and chrome steels to Rc 35, stainless steel, copper-nickel and aluminium are cut without limitation other than size and wall; high-temperature alloys such as Inconel may need special procedures.

Accessories listed by Tri Tool are a flange facer kit, elbow mandrel kit and pointer, dial indicator kit, miter mandrel kit, sleeve mandrel kit, ID tracking module kit and the Air Caddy FRL. Separate specifications exist for the hydraulic and heavy-duty electric 214B versions.

When choosing between neighbouring models, compare the bore you must clamp in as well as the OD: the 214B needs a minimum ID of 3.44 in, so very heavy-wall 4 in pipe may call for a smaller lathe. Tool bits are profile specific, so list each weld-end detail (J-bevel, compound bevel, land and counterbore) when ordering.

Documents and quotation

The Tri Tool 214B Air technical specification is attached. Other end-prep machines are listed under Pipe Cutting & Bevelling Machines.

Please include pipe sizes and schedules, material, weld-end profile, preferred drive (air, electric or hydraulic) and accessories when you request a quotation.
