Brand: ABB

ABB CP-E 24/5.0 Power Supply 24 V DC 5 A 120 W

Name: ABB CP-E 24/5.0 Power Supply 24 V 5 A | Seven Star LLC
Brand: ABB
SKU: CP-E 24/5.0

Description

CP-E 24/5.0: 120 W supply with parallel and redundancy options

CP-E 24/5.0 delivers 24 V DC at 5 A, 120 W, from a 115 or 230 V AC supply selected automatically, or from 210 to 375 V DC. It is the mid-size CP-E model: 63.2 mm wide, with two voltage input ranges that suit AC or DC feeds, and a solid-state signalling contact for output voltage OK.

ABB highlights a typical efficiency of 86 percent, free convection cooling and operation from -35 to +70 C. The output voltage is adjustable from 22.5 to 28.5 V DC with a front potentiometer.

Technical specifications

Parameter	Specification
Type designation / order code	CP-E 24/5.0 / 1SVR427034R0000
Device type	Primary switch-mode DIN-rail power supply, single-phase input, 24 V DC output
Input voltage range	115/230 V AC auto select; 90-132 V and 180-264 V AC; 210-375 V DC; 47-63 Hz
Input current / consumption	2.8 A at 115 V AC; 1.4 A at 230 V AC; typical 140 W
Inrush current / hold-up	24 A at 115 V and 48 A at 230 V (max 5 ms) / min 25 ms and 30 ms
Internal input fuse / PFC	3.15 A slow-acting / passive, 0.7
Output	24 V DC, adjustable 22.5-28.5 V DC, 120 W, 5 A up to 60 C; derate 2.5 %/C to 70 C
Output characteristics	U/I curve; ripple 50 mV; start max. 1 s; capacitive load up to 3500 uF
Signalling	13-14 solid-state contact (60 V DC, 0.3 A) active above 75 % output; green and red LEDs
Efficiency / dissipation	Typical 86 % / 20 W
Parallel / series	Up to 3 units in parallel (0.1-0.9 Ir); 2 in series; CP-A RU redundancy unit 1SVR427071R0000
Connections	Rigid 0.2-6 mm2; flexible with ferrule 0.2-4 mm2; torque 1 Nm input, 0.62 Nm output
Ambient temperature	Operation -35…+70 C; storage -40…+85 C
Dimensions / weight	63.2 x 123.6 x 123.6 mm (W x H x D); 1 kg per data sheet (0.882 kg e-catalogue)
Mounting / protection	DIN rail TH35-7.5 or TH35-15; horizontal; 25 mm clearance; IP20; class I
Standards (as printed)	IEC/EN 60950-1, 61000-6-2, 61000-6-3, EN 50581; UL 508; UL 60950; ANSI/ISA-12.12

Parallel operation and the signalling contact

A sliding switch selects single or parallel operation, and up to three units can be paralleled to increase power. The redundancy unit CP-A RU (1SVR427071R0000) decouples two supplies. The contact 13-14 closes when the output exceeds 75 percent of the set value and is rated 60 V DC, 0.3 A.

Buffering time is at least 30 ms at 230 V, thanks to two large capacitors, so short mains dips are ridden through. Inrush at 230 V is 48 A for up to 5 ms.

Loading and wiring notes

The data sheet specifies derating of 2.5 percent per degree between 60 and 70 C and a minimum clearance of 25 mm around the unit. Capacitive loads up to 3500 uF can be started. Typical power dissipation is 20 W.

The protective earth conductor must be connected and a disconnecting device provided in the supply line. The secondary side is electrically isolated (SELV) and can be earthed at L+ or L- (PELV) by the user.

Documents and quotation

The linked file is ABB CP-E 24/5.0 power supply data sheet 2CDC114060D0201. Seven Star LLC supplies the CP-E 24/5.0 on request from Muscat; availability and lead time are given in the quotation. More electrical and power products are in the Power Modules category, and the ABB CR-M024DC4L interface relay is a typical 24 V DC load.

Confirm before ordering: mains input range at site, the total 24 V DC load including inrush, ambient temperature in the cabinet and whether a redundancy unit is wanted.
