Pepperl+Fuchs PS1000-A6-24.20 Power Supply 24 VDC 20 A

Name: Pepperl+Fuchs PS1000-A6-24.20 Power Supply 24VDC 20A
Brand: Pepperl+Fuchs

Description

Product Overview

The Pepperl+Fuchs PS1000-A6-24.20 power supply is a primary switched mode unit designed for DIN rail mounting in industrial control cabinets. It provides a stable 24 V DC output at 20 A, delivering 480 W of power for field devices, controllers, actuators and sensors.

This power supply is certified for installation in Zone 2 and Division 2 hazardous areas, making it suitable for powering instrumentation and automation equipment in potentially explosive atmospheres. The unit features a compact 48 mm housing width, high efficiency and full protection functions including short circuit and overload protection.

Key Features

24 V DC output, 20 A, 480 W power supply
DIN rail mounting, compact 48 mm housing width
Certified for Zone 2 / Division 2 hazardous areas
Primary switched mode design with high efficiency
Short circuit, overload and overvoltage protection
LED status indication and adjustable output
Wide input voltage range for global use

Technical Specifications

Model	PS1000-A6-24.20
Output	24 V DC, 20 A (480 W)
Input	wide range AC/DC input
Mounting	DIN rail
Width	48 mm compact housing
Certification	Zone 2 / Div 2 hazardous area
Protection	short circuit, overload, overvoltage

Applications

The PS1000-A6-24.20 is used to power automation systems, field instruments, safety systems and communication equipment in oil and gas, chemical, pharmaceutical and industrial plants, including installations in Zone 2/Div 2 classified areas.

Ordering and Selection

When selecting the PS1000-A6-24.20 power supply, confirm the output voltage, current and hazardous area classification, because each PS1000 power supply is built for a specific installation duty. The PS1000-A6-24.20 provides 24 V DC at 20 A for Zone 2 and Division 2 areas, and the selected PS1000-A6-24.20 must be matched to the connected load. Our team can help you confirm that the PS1000-A6-24.20 you select is correct for your cabinet.

Maintenance and Support

The Pepperl+Fuchs PS1000-A6-24.20 power supply requires no routine maintenance, and the input and output connections should be checked periodically. Genuine spares and accessories for the Pepperl+Fuchs PS1000-A6-24.20 are available through Seven Star LLC. Contact our team for assistance with the Pepperl+Fuchs PS1000-A6-24.20, and we will confirm availability and delivery for your project.

Industry Applications and Custom Support

The Pepperl+Fuchs PS1000-A6-24.20 power supply is trusted by operations and maintenance teams across industrial plants in Oman, the GCC and the wider Middle East region. Our customers select the PS1000 power supply for reliability, genuine quality and dependable supply. Seven Star LLC provides custom support including technical selection, quotation and after-sales assistance, and we regularly supply this power supply as part of preventive maintenance programs and shutdown packages. Whether you need a single unit or a complete set for a project, our team supports procurement and inspection.

The PS1000-A6-24.20 power supply converts the AC mains to the stabilised 24 VDC output with the 20 A capacity, and the unit provides the primary switched mode technology with the protection for the industrial control circuits.

The power supply is designed for the continuous duty of the control cabinet, and the output protection covers the overcurrent and the short circuit conditions.

The Pepperl+Fuchs power supply is used for the 24 VDC supply of the field instruments and the control devices, and the PS1000 series provides the standard mounting for the control cabinet.

The input range covers the 230 VAC mains, and the output terminals accept the standard wiring.

The Pepperl+Fuchs PS1000-A6-24.20 power supply is the 24 VDC unit of the PS1000 range, and its 20 A output feeds the field devices and the control circuits of the plant.

The Pepperl+Fuchs PS1000-A6-24.20 power supply is selected for the marshalling cabinet, and the PS1000 power supply is wired to the 24 VDC bus.

Why Seven Star LLC?

Seven Star LLC supplies genuine Pepperl+Fuchs power supplies and automation components to customers in Oman and the GCC. We verify model numbers and certifications, ensuring the correct unit for your installation.

Our engineers help you verify the exact model and revision before ordering, avoiding costly mismatches.

Sizing the Supply for the Cabinet

Add up the steady-state current of every 24 V DC consumer on the bus, then allow for the inrush current of devices such as solenoids, relays and DC-powered instruments at start-up. Leaving margin between the connected load and the 20 A rating keeps the unit cooler and leaves room for future additions. Where a loss of 24 V would stop a process, consider two supplies with a redundancy module so that one unit can fail or be replaced without interrupting the load.

Power Supply Installation and Commissioning

Mount the unit on the DIN rail in the orientation recommended by the manufacturer, with clear space above and below for convection cooling. Use ferrules on stranded conductors, size the output wiring for the full current, and fit the upstream protection device specified in the instructions. In Zone 2 or Division 2 locations, follow the installation conditions of the hazardous-area certificate for the enclosure and wiring. Before connecting the load, check the output voltage with a meter and adjust it if required, then verify the status indication under load.

Troubleshooting

No output – check the input supply and upstream protection, then disconnect the load to rule out a short circuit
Output dropping under load – overload from inrush or too many consumers; review the load calculation
Unit running hot – blocked ventilation space or high cabinet temperature
Low voltage at remote devices – voltage drop in long or undersized cables

Use in Oman and the GCC

Cabinet temperatures in the region can rise well above the outdoor ambient in summer, so derating and ventilation deserve attention when a Pepperl+Fuchs PS1000-A6-24.20 power supply is installed in outdoor marshalling or RTU cabinets. Seven Star LLC can confirm the exact model and certificates for your installation before dispatch.

Also available: Pepperl+Fuchs R2000 2-D LiDAR Laser Scanner

Request a Quote for Pepperl+Fuchs PS1000-A6-24.20 Power Supply 24 VDC 20 A

For the Pepperl+Fuchs PS1000 or any related control and instrumentation requirement, contact the Seven Star LLC team. Submit a formal inquiry through our RFQ page with your configuration and application details, and our specialists will respond with a detailed commercial proposal and the official Pepperl+Fuchs documentation.

Reviews

There are no reviews yet.

How would you rate this product?

About brand

Two specialties define Pepperl+Fuchs, founded in 1945 and headquartered in Mannheim, Germany: industrial sensors for automation, and interface and protection equipment for hazardous areas. Many control cabinets in process plants contain rows of its isolators.

Seven Star LLC lists Pepperl+Fuchs sensors, isolated barriers, power supplies and hazardous-area mobile devices, and supplies them to instrument and automation teams in Oman by exact model designation.

Pepperl+Fuchs product families on this page

On the interface side there are two systems. The K-System mounts on DIN rail and is represented here by the KFD2-UT2-Ex2 universal temperature converter. The H-System plugs into termination boards and is represented by the HiD2030 SMART transmitter power supply with HART. The PS1000-A6-24.20 is a 24 VDC, 20 A power supply for cabinets. Sensors listed include the NJ2-12GK-SN NAMUR inductive sensor, the R101 retro-reflective photoelectric sensor and the R2000 2-D LiDAR scanner. For field staff there are the Tab-Ex 05 DZ1 tablet for Zone 1/21 areas and the Smart-Ex 03 DZ2 smartphone for Zone 2/22 and Division 2 areas.

Where Pepperl+Fuchs equipment is used

Isolated barriers sit between field instruments in Zone 0 or Zone 1 and the DCS or safety system in refineries, gas plants and chemical works. NAMUR sensors report valve position and machine states in classified areas. Photoelectric sensors and LiDAR scanners work in conveying, packaging, warehousing and vehicle guidance. Ex-rated tablets and phones are carried on operator rounds and maintenance jobs.

Ordering Pepperl+Fuchs parts: what we need

Send the complete model designation as printed on the device, including every suffix; a single letter can change the supply voltage or the output type. Add the part number if the label shows one. For barriers, tell us the field device and signal type, the number of channels and whether the safety loop needs a SIL-assessed module. For mobile devices, state the zone or division and the regional radio version.

Browse Pepperl+Fuchs products by category: Sensors & Transmitters, Industrial Computer, Isolator & Barrier, Power Modules.

Frequently Asked Questions

What is the Pepperl+Fuchs PS1000-A6-24.20?

It is a DIN rail power supply providing 24 V DC at 20 A (480 W) for industrial applications.

Is this power supply certified for hazardous areas?

Yes, it is certified for installation in Zone 2 and Division 2 hazardous areas.

What protection functions does it have?

The unit provides short circuit, overload and overvoltage protection.

What is the housing width?

The compact housing is 48 mm wide for space saving DIN rail mounting.

What details should I include in my inquiry for the Pepperl+Fuchs PS1000-A6-24.20 power supply?

Send the part number, your system details and the required quantity through the RFQ page. Seven Star LLC confirms the exact configuration, the matching accessories and the commercial terms for your project.
