Brand: Weldotherm
Weldotherm 200224 60 V Ceramic Pad Heater
Description
Flexible resistance mats for preheat and PWHT
The Weldotherm 200224 is a 60 V ceramic pad heater measuring 255 x 215 mm with 10 x 10 ceramic beads. Like every element in the Weldotherm 60 V range, it draws 45 A and delivers 2.7 kW. The mat is built from 96% aluminium oxide ceramic beads threaded on NiCr 80/20 heating wire, so it bends around pipe, flanges and nozzles and transfers heat by direct contact.
Ceramic pad heaters are the standard heating element for resistance preheating and post-weld heat treatment of circumferential pipe welds, flange and branch connections and for area heating on plate and vessels. They are connected to a heat treatment unit with 60 V outputs.
Technical specifications
| Parameter | Specification |
|---|---|
| Manufacturer / order number | Weldotherm / 200224 |
| Dimensions (W x H) | 255 x 215 mm |
| Ceramic beads | 10 x 10 |
| Connected load | 60 V AC / 45 A / 2.7 kW |
| Bead material | aluminium oxide ceramic, 96% |
| Heating wire | NiCr 80/20 |
| Application limit | max. 1,050 °C |
| Connectors | DINSE plugs standard; CAMLOCK on request |
Other 60 V sizes
All 60 V pads have the same 2.7 kW rating; the shape changes with the bead layout. A selection from the Weldotherm list:
| Order no. | W x H (mm) | Beads |
|---|---|---|
| 200200 | 52 x 1,042 | 2 x 50 |
| 200206 | 75 x 715 | 3 x 34 |
| 200209 | 100 x 525 | 4 x 25 |
| 200212 | 125 x 420 | 5 x 20 |
| 200215 | 150 x 335 | 6 x 16 |
| 200220 | 206 x 255 | 8 x 12 |
| 200224 | 255 x 215 | 10 x 10 |
| 200230 | 330 x 150 | 13 x 7 |
| 200240 | 480 x 105 | 19 x 5 |
| 200247 | 610 x 63 | 24 x 3 |
| 200259 | 863 x 63 | 33 x 3 |
The full list runs from 200200 to 200259. Long narrow pads wrap small-bore pipe; square pads suit flat areas and large diameters.
Selecting pads for a joint
The heated band width and the number of pads around the circumference follow the applicable PWHT code and the pipe diameter; each pad is connected to one output of the heat treatment unit and controlled by a thermocouple under or near it. Insulation over the pads reduces heat loss and improves uniformity. A 30 V range in matching sizes is available for 30 V outputs.
Documents and quotation
The Weldotherm 60 V ceramic pad heater datasheet is attached; heat treatment units are in Induction Heating & Preheating. For a quotation, list the order numbers and quantities, or the pipe diameter and band width so suitable sizes can be proposed.
Datasheets & Documents
- Datasheet Weldotherm Ceramic Pad Heater 60 V datasheet (rev. 04-2025) Download
Reviews (0)
About brand
WELDOTHERM Gesellschaft für Wärmetechnik mbH, based in Essen, Germany, manufactures equipment for the controlled heat treatment of welds and has worked in this field for more than 40 years. Its range covers resistance and induction heat treatment units, heating elements and related measuring equipment for site and workshop use. Seven Star LLC is an independent supplier in Muscat that lists the WR 10,5 inverter unit and sources Weldotherm equipment for preheating and post-weld heat treatment.
Weldotherm heat treatment units
The resistance range runs from the WR 10,5 inverter to the multi-channel STANDARD EUROPA and VAS series, the VAS offering up to 12 control circuits at 30 V and 60 V. The VAI series uses induction, generating heat in the material itself. Weldotherm also supplies the heating elements used with these units.
Ordering Weldotherm equipment: what we need
State the unit type, the number of control channels, the site mains voltage and the voltage class of the heating elements you already use. For heating elements, give the type, voltage and dimensions. We check the configuration against Weldotherm datasheets and provide them on request.
Related products
Frequently Asked Questions
What is the rating of the Weldotherm 200224 pad?
60 V AC, 45 A, 2.7 kW.
What size is the 200224 ceramic pad heater?
255 x 215 mm with 10 x 10 ceramic beads.
What is the maximum temperature for Weldotherm ceramic pads?
Application limit 1,050 °C.
Which connector does the 200224 use?
DINSE plugs as standard; CAMLOCK on request.
Are there 30 V versions?
Yes. Weldotherm offers a separate 30 V ceramic pad heater range.
