Cooper Crouse-Hinds EDS225 EDS Pushbutton Control Station

Overview

The Cooper Crouse-Hinds EDS225 is a two-gang, two-circuit explosionproof pushbutton control station built in rugged Feraloy iron alloy for the most demanding Class I, Class II, and Class III hazardous-area applications. Part of the long-running EDS/EDSX metallic control station family from Eaton’s Crouse-Hinds series, the EDS225 provides two independent pushbutton positions in a single dead-end enclosure, giving control engineers a compact way to mount multiple start/stop, jog, or interlock functions at one field location without stacking separate single-gang stations.

As the official authorized partner and exclusive regional representative for Cooper Crouse-Hinds, Seven Star LLC proudly supplies the EDS225 pushbutton control station to refineries, offshore platforms, and heavy industrial plants across Oman and the wider GCC. Every unit is genuine Crouse-Hinds product with full manufacturer traceability, and our technical team supports specification, sizing, and compliant installation of metallic hazardous-area control stations throughout the Sultanate of Oman.

Operating Principle

The Cooper Crouse-Hinds EDS225’s two pushbutton positions are each factory sealed within the cast Feraloy body, so no external conduit seal is required at the device itself, simplifying installation while preserving the flame-tight integrity mandated for Class I and II locations. Depressing either button actuates its associated momentary contact set, sending a control signal to the connected magnetic starter, contactor, relay, or PLC input; releasing the button returns the contact to its normal state. The dead-end, two-circuit universal design means the enclosure terminates the conduit run rather than passing it through, which is typical for stations mounted at the end of a control run near a motor or skid.

On the Cooper Crouse-Hinds EDS225, close-tolerance machining of the mating flanges, journaled shafts, and bearings for the front-operated pushbuttons produces the flame-tight joint integrity required to contain an internal ignition event without propagating it to the surrounding atmosphere. This mechanical design, unchanged in principle since the EDS family’s introduction, remains one of the most field-proven approaches to hazardous-area pushbutton control available today.

Engineering Design of the Cooper Crouse-Hinds EDS225

The Cooper Crouse-Hinds EDS225 enclosure is cast from Feraloy iron alloy and measures approximately 7.19 in deep, 5.81 in wide, and 6.03 in high, weighing roughly 16 lb – a substantial, field-durable package intended for permanent mounting on structural steel, pedestals, or equipment skids. Each of the two device positions accepts a standard front-operated pushbutton with red STOP / green START button colour convention, and the dead-end body style terminates a single 3/4 in conduit entry rather than allowing feed-through wiring.

On the Cooper Crouse-Hinds EDS225, neoprene covers behind the front-operated buttons prevent dirt accumulation and water ingress around the operating shafts, while lockout provisions on the STOP position accept a standard 1/4 in hasp padlock for lockout-tagout procedures. The EDS225 is rated NEMA 3, 7, and 9 and certified for Class I Divisions 1 and 2, Class II Divisions 1 and 2, and Class III hazardous locations – among the broadest classification coverage available in the Crouse-Hinds pushbutton station catalog.

Key Features

The Cooper Crouse-Hinds EDS225 delivers robust two-gang pushbutton control for the harshest hazardous-area duty:

• Two-gang, two-circuit dead-end body accommodates two independent pushbutton functions in a single station.
• Feraloy iron alloy body construction with electro-galvanized and aluminum acrylic painted finish for corrosion resistance.
• Factory-sealed pushbutton positions eliminate the need for external conduit sealing fittings at the device.
• Rated for Class I Div 1 & 2, Class II Div 1 & 2, and Class III hazardous locations – broad classification coverage.
• 600 VAC rating suitable for direct interface with magnetic starters, contactors, and control relays.
• Neoprene shaft covers and lockout-ready STOP button support safe lockout-tagout procedures.
• 3/4 in threaded conduit hub with dead-end (non-feed-through) body style for terminal mounting.
• NEMA 3, 7, and 9 rating for outdoor, washdown, and dusty industrial environments.

Industrial Applications

The Cooper Crouse-Hinds EDS225 pushbutton control station is specified throughout heavy industrial and hazardous process facilities: refinery process units, offshore and onshore oil and gas production, chemical and petrochemical plants, gasoline bulk loading terminals, and grain elevator or grain processing operations requiring robust Class II dust-ignitionproof control stations. Its two-gang configuration is frequently used at motor control points requiring both a local start/stop function and a secondary jog or reset pushbutton in one enclosure.

As the officially authorized partner for Cooper Crouse-Hinds, Seven Star LLC distributes the EDS225 to EPC contractors, panel builders, and plant maintenance teams across Muscat, Sohar, and the Salalah free zone, supporting both new-build hazardous-area control networks and shutdown/turnaround replacement programs. Our regional stock holding and direct manufacturer relationship help shorten lead times compared with sourcing individually from overseas distributors, with full datasheet and certification support available for Oman and GCC regulatory submissions.

Technical Specifications

Key specifications for the Cooper Crouse-Hinds EDS225 pushbutton control station, model Cooper Crouse-Hinds EDS225,:

Note on product imagery: this listing is illustrated using the closely related single-gang EDSC215 feed-through station photo, the closest genuinely documented reference image available for the EDS/EDSX family; the two-gang EDS225 dead-end body differs in gang count and conduit configuration. Please confirm exact configuration with our sales team when placing an order.

Call To Action

Seven Star LLC stocks and supplies the Cooper Crouse-Hinds EDS225 pushbutton control station for immediate quotation and regional delivery across Oman and the GCC. As the authorized partner for Cooper Crouse-Hinds in Oman and the GCC, we support formal RFQ submissions, provide regional warehouse stock to minimize project lead times, and offer full technical datasheets for download on request. Contact our instrumentation and hazardous-area electrical division today for pricing, lead time, and compliance documentation for your EDS225 requirement.
