Schneider Electric TM3DI16 Modicon Digital Input Module

Name: Schneider Electric TM3DI16 I/O Module – Datasheet & Quote
Brand: Schneider Electric

Description

Overview

The Schneider Electric TM3DI16 is a 16-channel digital input expansion module for the Modicon TM3 range, extending the I/O count of Modicon M221, M241, and M251 controllers without requiring a separate rack or backplane. It gives panel builders a compact, cost-effective way to add discrete sensing points as machine designs grow beyond the controller’s onboard I/O.

With fast quotation turnaround and technical support, Seven Star LLC proudly supplies the Schneider Electric TM3DI16 across the Sultanate of Oman and the wider GCC. Every unit is supplied with manufacturer documentation and local technical backing, giving procurement teams in Muscat, Sohar, and Salalah a formal quotation and support with selection. Seven Star LLC has a dedicated instrumentation and controls division that provides technical support with selection and specification for the Schneider Electric TM3DI16 and the wider Schneider Electric portfolio.

Operating Principle

The TM3DI16 reads sixteen discrete field signals – from limit switches, proximity sensors, pushbuttons, and relay contacts – and converts each into a digital status bit that is transferred to the host controller over the internal TM3 bus on every scan cycle. Optically isolated input circuitry protects the controller’s backplane electronics from field-side voltage transients and wiring faults.

Because the module clips directly onto the Modicon base controller or an adjacent TM3 module, no separate power supply, addressing, or network configuration is required; the host automatically recognizes the module and maps its channels into the controller’s I/O table at power-up. Diagnostic LEDs on the module face mirror each channel’s live state, letting technicians verify field wiring without a programming laptop.

Engineering Design of the Schneider Electric TM3DI16

The Schneider Electric TM3DI16 is housed in a compact DIN-rail-mount enclosure that clips directly to the side of a Modicon M221, M241, or M251 base unit, extending the control assembly horizontally with no additional wiring for power or data. Removable spring or screw terminal blocks allow field wiring to be pre-assembled and swapped without disturbing the module itself.

Each of the sixteen channels is individually fused and optically isolated, with per-channel status LEDs on the front face for at-a-glance diagnostics during commissioning and troubleshooting. The module’s keyed backplane connector prevents incorrect installation and ensures reliable data transfer to the host controller.

Key Features

The Schneider Electric TM3DI16 is engineered to deliver dependable performance in demanding industrial and commercial environments. Key features include:

Sixteen optically isolated digital input channels for reliable field signal acquisition.
Direct clip-on mounting to Modicon M221, M241, and M251 controllers with no separate backplane.
Automatic recognition and I/O table mapping at power-up with no manual addressing.
Per-channel status LEDs for fast on-site diagnostics during commissioning and troubleshooting.
Removable terminal blocks for pre-wired panel assembly and simplified module replacement.
Compact DIN-rail footprint that keeps panel dimensions to a minimum.
Wide input voltage compatibility for standard 24VDC sensor and switch wiring.
Robust industrial rating suited to the temperature and vibration conditions of GCC plant environments.

Applications

The Schneider Electric TM3DI16 is used wherever a Modicon-based machine or skid needs additional discrete input capacity beyond the controller’s embedded I/O, such as conveyor position sensing, valve and pump status monitoring, and safety interlock wiring. It is a common line item on panel builds supplied to water treatment, food processing, and utility facilities across Oman and the GCC.

With engineering support in Muscat, Seven Star LLC distributes the Schneider Electric TM3DI16 to system integrators, panel builders, and EPC contractors throughout Oman and the GCC, supporting district cooling plants, desalination facilities, oil and gas installations, commercial towers, hospitality developments, and the Sohar and Salalah economic zones. Local availability shortens lead times against direct import, and Seven Star LLC’s engineering team assists with product selection, coordination with the wider Schneider Electric ecosystem, and post-installation support so operators in the region are never left waiting on a factory response from overseas.

Technical Specifications

The table below summarizes the key technical specifications of the Schneider Electric TM3DI16 for engineering reference and system design.

Parameter	Specification
Model	TM3DI16
Type	Digital input expansion module
Channels	16 digital inputs
Isolation	Optically isolated per channel
Compatibility	Modicon M221 / M241 / M251
Mounting	35mm DIN rail, clip-on to base controller
Supply Voltage	24VDC
Diagnostics	Per-channel status LEDs

Why Choose Seven Star LLC

Seven Star LLC supplies the Schneider Electric TM3DI16 and the broader Schneider Electric catalogue to industrial, commercial and utility customers across Oman and the GCC.Seven Star LLC supplies this item on request with the manufacturer documentation, and availability and lead time are confirmed at quotation.

Get a Quote

To request a formal quotation for the Schneider Electric TM3DI16, contact the Seven Star LLC instrumentation and controls division directly. Seven Star LLC supplies on request across Oman and the GCC, offers downloadable technical datasheets for engineering review, and provides pre-sales application support for panel builders and end users alike. Seven Star LLC supplies the Schneider Electric TM3DI16 with technical documentation and responsive local support – reach out today to confirm availability, lead time, and pricing for your project.
