Schneider Electric EasyPact EZC MCCB EZC100/EZC250
Overview
Schneider Electric EasyPact EZC is an economical moulded case circuit breaker (MCCB) range spanning the EZC100 and EZC250 frame sizes, delivering rated currents from 15A up to 250A with fixed thermal-magnetic settings for straightforward, dependable protection where full digital trip-unit sophistication is not required. Designed as a simple, universal solution for commercial buildings and light industrial installations, the Schneider Electric EasyPact EZC keeps panel design fast and cost-effective while still meeting IEC 60947-2 performance standards, making it a practical choice for budget-conscious projects that still demand genuine Schneider Electric reliability.
With fast quotation turnaround and technical support, Seven Star LLC proudly supplies the Schneider Electric EasyPact EZC range to contractors, panel builders, and facility managers across Oman and the GCC. Supplied on request, the EZC100 and EZC250 are widely deployed in distribution boards serving retail buildings, residential towers, and small-to-medium industrial workshops throughout Muscat, Sohar, and Salalah, where dependable fixed-setting protection matters more than advanced digital metering.
Operating Principle of the Schneider Electric EasyPact EZC
The Schneider Electric EasyPact EZC uses a fixed thermal-magnetic trip mechanism: a calibrated bimetallic strip provides time-delayed protection against sustained overload currents, deflecting and releasing the trip latch once the rated thermal threshold is exceeded, while an integrated magnetic trip element responds instantaneously to short-circuit-level currents by driving the contacts open within milliseconds. Because the settings are factory-fixed rather than field-adjustable, installation and commissioning are simplified – there is no need to calibrate long-time, short-time, or instantaneous pickup points on site, reducing both commissioning time and the risk of incorrect field settings.
This fixed-setting approach makes the Schneider Electric EasyPact EZC particularly well suited to standardized, repeatable panel designs where every breaker in a given rating performs identically out of the box. The arc-quenching chamber and current-limiting contact design still deliver breaking capacities suitable for general building and light industrial fault levels, and the mechanism supports reliable manual operation as well as remote tripping via optional accessories, giving specifiers a dependable, no-fuss protection device for circuits that do not require the selective coordination features of the larger Compact NSX range.
Engineering Design of the Schneider Electric EasyPact EZC
The Schneider Electric EasyPact EZC is housed in a compact, high-impact thermoplastic moulded case available in EZC100 (up to 100A) and EZC250 (up to 250A) frame sizes, with 3-pole and 4-pole configurations to suit both three-phase-only and three-phase-plus-neutral distribution. The breaker can be mounted vertically, horizontally, or flat on its back without any derating of performance characteristics, and it accepts supply from either the top or bottom terminals – reverse feeding is fully supported without a reduction in rated performance, giving panel builders real flexibility in busbar and cable routing.
A rotary handle operating mechanism with clear ON/OFF/tripped position indication is standard, and the padlocking system accepts up to two padlocks on the EZC100 and up to three on the EZC250 for lockout-tagout compliance during maintenance. Terminal shields provide IP20 finger-safe protection with the toggle handle, rising to IP40 when fitted with the direct rotary handle option, and the range accepts a family of accessories including auxiliary and alarm contacts, shunt trips, and undervoltage releases for basic remote monitoring and control where required.
Key Features
The Schneider Electric EasyPact EZC delivers a dependable, economical feature set for engineers specifying commercial and light industrial panel protection:
- Covers the EZC100 and EZC250 frame sizes, spanning rated currents from 15A to 250A in a single economical MCCB family.
- Factory-fixed thermal-magnetic trip settings that simplify installation and eliminate on-site calibration errors.
- Breaking capacities suitable for general building and light industrial fault levels, conforming to IEC 60947-2.
- Vertical, horizontal, or flat mounting supported without any derating of rated performance characteristics.
- Reverse feeding from top or bottom terminals fully supported for flexible busbar and cable routing.
- Padlockable rotary handle mechanism for reliable lockout-tagout compliance during maintenance work.
- 3-pole and 4-pole configurations to suit three-phase-only and three-phase-plus-neutral distribution boards.
- Compatible with auxiliary contacts, alarm switches, shunt trips, and undervoltage releases for basic remote monitoring.
Industrial Applications
The Schneider Electric EasyPact EZC is widely specified in commercial and light industrial distribution boards across the Sultanate of Oman, protecting sub-mains and floor-level panels in retail centers, residential towers, and hospitality developments throughout Muscat, where standardized, repeatable panel designs benefit from the range’s fixed-setting simplicity and fast availability. In light industrial and workshop environments across Oman, the EZC100 and EZC250 protect machine feeders, lighting and small power distribution, and auxiliary equipment circuits that do not require the advanced digital trip-unit features of larger MCCB frames.
With engineering support in Muscat, Seven Star LLC supplies the Schneider Electric EasyPact EZC range to contractors and consulting engineers on projects throughout the Sohar and Salalah economic zones, where warehousing facilities, light manufacturing units, and commercial developments need dependable, cost-effective circuit protection. The range is a practical choice for contractors working to tight project schedules across the GCC, with lead time confirmed at quotation.
Technical Specifications
Key technical parameters for the Schneider Electric EasyPact EZC range are summarized below.
| Parameter | Specification |
|---|---|
| Model | Schneider Electric EasyPact EZC (EZC100 / EZC250) |
| Rated Current (In) | 15A – 250A |
| Poles | 3P, 4P |
| Trip Settings | Fixed thermal-magnetic |
| Rated Insulation Voltage | 690V AC |
| Rated Impulse Withstand Voltage | 6kV |
| Standard | IEC 60947-2 |
| Protection Degree | IP20 (toggle handle), IP40 (rotary handle) |
| Padlocking | 2 x Ø5mm (EZC100), 3 x Ø8mm (EZC250) |
| Auxiliaries | Auxiliary/alarm contacts, shunt trip, undervoltage release |
Also available: Schneider Electric NSYTMR DIN Rail Terminal Block
Request a Quote for Schneider Electric EasyPact EZC MCCB EZC100/EZC250
Contractors and facility managers across Oman and the GCC can request a formal RFQ for the EasyPact EZC range through Seven Star LLC, with lead time and availability for EZC100 and EZC250 units confirmed at quotation. Technical datasheets and installation guidance are available on request from our instrumentation and low-voltage products division. Seven Star LLC provides a formal quotation, manufacturer documentation, and dedicated technical support for every EasyPact EZC order.
