Tregaskiss MA1 Fixed Automatic MIG Gun

Name: Tregaskiss MA1 Fixed Automatic MIG Gun – Datasheet & Quote
Brand: Tregaskiss
SKU: MA1

A simple 385 A air-cooled torch for hard tooling automation

The Tregaskiss MA1 is a fixed automatic air-cooled MIG gun with a duty cycle rating of 100 % at 385 A with CO2 and mixed gases, based on tests that comply with IEC 60974-7. Tregaskiss engineered it for hard tooling automation that needs a simple, durable and repeatable MIG gun, in heavy equipment and general manufacturing. Typical applications named in the sheet are fixed or hard automation, long repeatable seams and fixed orbital welding.

Tregaskiss positions it as an alternative to fabricating your own fixed automatic gun, which it says can cause downtime and rework. The MA1 is compatible with TOUGH GUN I.C.E. technology.

Technical specifications

Parameter	Specification
Manufacturer	Tregaskiss (ITW Welding)
Model	MA1 fixed automatic air-cooled MIG gun
Process	MIG (GMAW)
Duty cycle	100 % at 385 A with CO2 and mixed gases (IEC 60974-7)
Cable lengths	3 ft to 15 ft
Liner system	QUICK LOAD liners, standard unless aluminium is selected; 0.035 to 1/16 in wire, up to 15 ft
QUICK LOAD liners	415-35-6Q, 415-35-10Q, 415-35-15Q (0.035 to 0.045 in); 415-116-6Q, 415-116-10Q, 415-116-15Q (0.045 to 1/16 in); retainer 415-26
Rear load liners	Solid wire: 415-30 (0.030 in), 415-564 (1/16 to 5/64 in), 415-332 (0.078 to 3/32 in); aluminium liners with jump liner
Consumable series	AccuLock R and TOUGH LOCK; AccuLock HD copper contact tips 0.030 to 3/32 in (T-A030CH to T-A094CH)
Nozzles	Slip-on nozzles such as 401-6-62 (5/8 in bore, 1/8 in recess) and 401-5-62 (5/8 in bore, 1/4 in recess) and others listed in the sheet
TOUGH GUN I.C.E. necks	22, 45, 60 and 180 degree air-cooled necks (591 series)
Power pins	Miller (414-110) and Tweco #4 (414-10) power pins, each including control plug; other pins per ordering table
Ordering wire sizes shown	0.030, 0.035 and 0.052 in
Spec sheet	Index No. MA1/2.4, issued July 2025

QUICK LOAD liners and I.C.E. technology

Two features from the sheet shape the gun. QUICK LOAD liners load from the front of the gun and, Tregaskiss says, need less than half the time and effort of rear-load liners to replace; they interface with a liner retainer seated within the power pin on first use. TOUGH GUN I.C.E. technology (Integrated Cooling Enhancer) boosts the duty cycle of the air-cooled gun by circulating water at the nozzle, which keeps consumables cooler so they last longer.

Choosing options

Select the cable length from 3 to 15 ft, the neck style and length, the nozzle and contact tip, the wire size and the power pin. For aluminium wire, the sheet lists dedicated liners that need a jump liner. AccuLock R consumables are designed for increased tip life and replacement accuracy, and AccuLock HDP tips can increase tip life by an additional 10 times or more in pulse welding. Check the actual duty cycle needed at the weld: 385 A is the rated maximum, not a recommended setting for every wire and gas combination.

Documents and quotation

The attached Tregaskiss MA1 spec sheet gives the ordering information and parts listed on this page. For a quotation please send the model, amperage, cable length, neck and consumable options, wire type and diameter, and the feeder or fixture connection you need. An owner manual for the MA1 is also published by Tregaskiss. Related products are listed under TIG torches and MIG guns.

Tregaskiss product groups

The range covers robotic air-cooled and water-cooled MIG torches such as the Atlas, TA3 and CA3, the TOUGH GUN line, fixed automatic MIG torches including the MA1 and AW2, nozzle cleaning stations and reamers, and the AccuLock, TOUGH LOCK and Centerfire consumables, liners and necks that go with them. The torches are used in automotive, heavy equipment, ship and general fabrication work.
