JUMO Wtrans E01 Wireless Humidity, Temperature and CO2 Probe

Name: JUMO Wtrans E01 Wireless Humidity CO2 Probe | Seven Star LLC
Brand: JUMO
SKU: Wtrans E01

Description

Wireless measuring probe for humidity, temperature and CO2

The JUMO Wtrans E01 (type 902928) is a measuring probe with wireless data transmission. It works together with a Wtrans receiver and records values from digital sensors for humidity, temperature and CO2. Two M12 x 1 plug connectors accept the sensors in any combination, and the probe detects them automatically (plug and play).

Up to four measured values are recorded, derived values included, and transmitted at a radio frequency of 868.4 MHz to the receiver of the Wtrans measuring system, where they are displayed and made available as digital or analog output variables. Open-air range is 300 m, and the wiring effort is largely eliminated.

The electronics and a backlit LCD with operating keys sit in a wall-mounted case with IP65 protection. The probe is powered from four lithium batteries of size AA or from an external DC 18 to 30 V supply, and it is configured via the keys or the USB interface.

Other measurands can be derived from the measured values, such as dew point or absolute humidity, when the corresponding extra code or accessory is activated on the device. Measuring probe breaks and short circuits are detected and shown as an error message (Err) on the LCD display.

Technical specifications

Parameter	Specification
Type	902928, Wtrans E01 measuring probe with plug-in sensors
Sensor inputs	Two M12 x 1 connectors; humidity/temperature, CO2 or Pt1000 RTD in any combination
Humidity sensor	0 to 100 % RH, +/-2 % RH (0 to 90 % RH); temperature -40 to +80 °C, +/-0.2 K at 20 °C
CO2 sensor	0 to 2000, 5000 or 10000 ppm; for example +/-(50 ppm + 2 % of range) at 2000 ppm
Pt1000 probe	-200 to +600 °C via the input, +/-0.2 K; class A probe -50 to +150 °C, four-wire
Measuring interval	5 to 3600 s for humidity (default 90 s); 30 to 3600 s for CO2 (1200 s); 1 to 3600 s for Pt1000 (15 s)
Radio	868.4 MHz (Europe), transmission power below +10 dBm, open-air range 300 m
Transmission interval	1 to 3600 s; default 15 s; five-digit transmitter ID
Supply	4 x 1.5 V AA lithium (about one year with one sensor at default settings) or DC 18 to 30 V, 2.4 W
Display	Transflective LCD 52 x 30 mm with switchable backlight
Ambient temperature	-30 to +80 °C with external supply; -20 to +60 °C with recommended lithium batteries
Case	PC-ABS, signal white; 133.6 x 210.0 x 60.5 mm; IP65; approx. 550 g with batteries
Standards	EMC DIN EN 61326-1; radio ETSI EN 300 220-1 and -2; climate class 3K8H

Pairing with a receiver and sensors

The probe sends to the universal Wtrans receiver described in data sheet 902931, which provides up to 16 receiver channels per receiver, an RS485 interface with Modbus protocol and analog or relay outputs. Select the sensor set from the accessory list: a combined humidity and temperature sensor, a CO2 sensor, or a Pt1000 RTD probe.

Sensors can be mounted away from the housing with extension cables and an antenna, which helps in places where the case cannot sit at the measuring point. The data sheet recommends Energizer Ultimate Lithium AA batteries, and the stated battery life applies only to those.

Setup uses the setup program, available as an accessory, over the USB interface. Configurable parameters are the transmitter detection ID, transmission interval, measurands, offset, measuring interval and display.

Measuring and transmission intervals are independent. A long measuring interval saves battery life, and the transmission interval of 1 to 3600 s decides how often the receiver gets fresh data, with all measured values sent together at a default of 15 s. Fast intervals, a second sensor, and very high or low ambient temperatures all reduce the battery life stated in the data sheet.

The Pt1000 input allows a class A probe in four-wire circuit with a protection tube of 4 mm. Its response time in water at 0.4 m/s is about 3 s to reach 50 percent and about 7 s to reach 90 percent, and in air at 3.0 m/s about 25 s and 80 s.

Applications

Wireless sensing is useful where cabling is costly or impossible: warehouses, climate chambers, storage rooms, production halls, and buildings where air quality has to be recorded in several places. The CO2 option supports ventilation checks, and the humidity and temperature sensor covers storage conditions.

Plan the radio path in advance. Open-air range is 300 m, but walls, metal racks and machinery reduce the usable distance, so test the link with the receiver at the planned location before fixing the housing.

The wall-mounted case can be used inside and outside buildings with a DIN rail piece, in a vertical installation position. It can be cleaned with conventional washing, rinsing and cleaning agents, and it tolerates dripping water according to class 3Z7.

Documents and quotation

The manufacturer data sheet (JUMO Wtrans E01 data sheet 902928 (EN, 14 pages)) is attached to this page as a PDF. Send the full type code you need through the quotation form and we will reply with availability and delivery terms; please confirm the options against your plant specification before ordering. Related items are listed under Temperature Instrumentation.

Datasheets & Documents

Datasheet JUMO Wtrans E01 data sheet 902928 (EN, 14 pages) Download
