VEGA PS64.AEGGQIHXVDAXM VEGABAR 64 Pressure Transmitter
Overview
The VEGA PS64.AEGGQIHXVDAXM is a VEGABAR 64 process pressure transmitter, an industrial-grade instrument for measuring the relative or absolute pressure of liquids, gases, and vapours in pipelines and closed vessels. Built around VEGA’s ceramic-capacitive measuring cell technology, the VEGABAR 64 delivers stable, drift-resistant pressure readings even in applications with condensation, rapid temperature swings, or aggressive process media, and it outputs a standard 4-20 mA HART signal for direct integration into plant control systems. The PS64.AEGGQIHXVDAXM order code specifies the exact process connection, wetted material, electrical output, and approvals configured for a particular installation.
Seven Star LLC supplies the VEGA PS64.AEGGQIHXVDAXM as a genuine VEGA distributor to process plants, refineries, and utilities across Oman and the GCC standardizing on VEGA pressure instrumentation. Our engineering team can decode a full VEGA order code or cross-reference the nameplate of an existing VEGABAR transmitter to confirm the correct PS64.AEGGQIHXVDAXM replacement configuration before you order, so process connection and range match your installation exactly.
Measurement and Operating Principle
Process pressure acting on the VEGABAR 64’s dry ceramic-capacitive measuring cell causes a minute deflection of the ceramic diaphragm relative to a fixed ceramic counter-electrode. This deflection changes the capacitance between the two elements, and the transmitter’s electronics convert that capacitance change into a linear 4-20 mA current signal proportional to the applied pressure, with HART digital communication overlaid on the same two-wire loop for configuration, diagnostics, and secondary variable access without additional wiring.
Because the ceramic measuring cell is inherently overload-resistant and free from the hysteresis and long-term drift associated with metallic diaphragm designs, the VEGABAR 64 maintains measurement accuracy through repeated pressure cycling and thermal shock – conditions common in batch process vessels and pipelines subject to steam cleaning or rapid product changeovers. Integrated self-monitoring diagnostics continuously check sensor and electronics health, flagging a fault condition to the control system before a bad reading can propagate into the process.
Engineering Design
The VEGABAR 64 platform is engineered for gauge, absolute, and vacuum pressure measurement across a wide span range, with the specific PS64.AEGGQIHXVDAXM configuration typically built with an IP66/IP67-rated transmitter housing, M20x1.5 cable entry, and a threaded or flanged process fitting selected to match the vessel or pipe connection. Standard process temperature capability spans roughly -20 °C to +120 °C, and the instrument accepts a two-wire, loop-powered 12-36 V DC supply, minimizing cabling and power infrastructure at the installation point.
A front-flush diaphragm variant is available for viscous or sticky media, and a non-front-flush version suits clean gases and vapours, letting the same VEGABAR 64 platform be specified precisely against the process medium. High overload resistance and long-term stability make the ceramic-capacitive cell well suited to demanding process pressure duty, and the modular plics® electronics housing shared across the VEGA product range simplifies spare parts stocking for plants running multiple VEGA instrument types.
VEGA PS64.AEGGQIHXVDAXM Key Features
- VEGA PS64.AEGGQIHXVDAXM delivers stable process pressure measurement via a dry ceramic-capacitive measuring cell
- 4-20 mA HART output for direct integration into DCS and PLC control systems
- High overload resistance and long-term stability with thermal shock compensation
- Integrated self-monitoring diagnostics for early fault detection
- IP66/IP67-rated housing suited to harsh industrial and outdoor environments
- Front-flush and non-front-flush diaphragm variants for liquids, sticky media, gases and vapours
- Process temperature range of approximately -20 °C to +120 °C
- Two-wire, loop-powered design (12-36 V DC) minimizes installation wiring
Industrial Applications for the VEGA PS64.AEGGQIHXVDAXM
The VEGA PS64.AEGGQIHXVDAXM is used for process pressure measurement in refinery pipelines, gas processing pressure vessels, water treatment distribution systems, and general utility pressure monitoring wherever a robust, drift-resistant 4-20 mA HART transmitter is needed. Its resistance to condensation and thermal shock makes it particularly suited to steam-cleaned vessels and batch processes with rapid temperature swings.
Seven Star LLC, as a trusted supplier of VEGA products serving Oman and the wider GCC, supplies the PS64.AEGGQIHXVDAXM to instrumentation teams in Muscat, Sohar, Duqm, and Salalah upgrading or maintaining VEGA-equipped pressure monitoring loops, with full order-code verification to ensure the process connection, range, and approvals match your installation before shipment.
VEGA PS64.AEGGQIHXVDAXM Technical Specifications
| Model | VEGA PS64.AEGGQIHXVDAXM (VEGABAR 64) |
|---|---|
| Measuring Principle | Ceramic-capacitive pressure measuring cell |
| Output Signal | 4-20 mA HART, two-wire loop-powered |
| Power Supply | 12-36 V DC |
| Process Temperature | -20 °C to +120 °C |
| Protection Rating | IP66 / IP67 |
| Cable Entry | M20x1.5 |
| Diaphragm Options | Front-flush and non-front-flush |
| Manufacturer | VEGA Grieshaber KG |
Why Choose Seven Star LLC for VEGA VEGABAR Pressure Transmitters
The VEGABAR 64’s process connection, measuring range, and output configuration exist in dozens of ordering-code combinations, and getting the exact variant right for your process matters more than the base model number alone, since a wrong thread or flange size means the transmitter simply cannot be installed as delivered. Seven Star LLC confirms the correct VEGABAR 64 ordering configuration against your specific process connection and range requirements before shipment, backed by our trusted VEGA suppliership across Oman and the wider GCC. We also support process plants across Sohar and Salalah with spare transmitter planning matched to exact ordering codes, so replacement units install without on-site modification.
Request a Quote
Contact Seven Star LLC to request a quote for the VEGA PS64.AEGGQIHXVDAXM VEGABAR 64 pressure transmitter, including order-code verification and delivery to your site in Oman or the GCC.
Seven Star LLC keeps the VEGA PS64.AEGGQIHXVDAXM available for fast quoting to Oman-based process and utility instrumentation teams needing reliable pressure transmitters.
Related Products
- Brochure VEGA PS64.AEGGQIHXVDAXM VEGABAR 64 Pressure Transmitter Catalog Download
VEGA product families on this page
VEGA product names state the measuring principle:- VEGAPULS: non-contact radar level sensors, including VEGAPULS 6X, VEGAPULS 64, VEGAPULS 69 and the compact VEGAPULS C21
- VEGAFLEX 81 and 86: guided wave radar level sensors, and VEGAPASS 81, a bypass tube that is combined with a VEGAFLEX to measure outside the vessel
- VEGASWING 61 and 63: vibrating fork level switches for liquids
- VEGAPOINT 21: compact capacitive point level switch
- VEGABAR 82: process pressure transmitter with ceramic measuring cell
- VEGADIS 176: external display for 4-20 mA loops
Where VEGA sensors and transmitters are used
VEGA level transmitters are common on crude and product tanks, separators, chemical storage, water and wastewater basins, and cement or aggregate silos across the GCC. Vibrating switches serve as overfill and dry-run protection on pumps and vessels. VEGA pressure transmitters measure process pressure and hydrostatic level in liquids and gases.Ordering VEGA instruments: what we need
A VEGA device is fully described by its order code and serial number. A code such as FX81.ICEAIFAXKMAM starts with the device type (FX81 is a VEGAFLEX 81, PS64 a VEGAPULS 64, B82 a VEGABAR 82) and continues with letters for approval, process fitting, seal, electronics and housing. Send that code, or the serial number from the type label, and we can check the exact build in VEGA documentation. For a new point, add the medium, vessel height, nozzle size, pressure, temperature and area classification.Browse VEGA products by category: Level Transmitter, Pressure Instrumentation.
