JUMO hydroTRANS H50 Industrial Humidity and Temperature Sensor

Name: JUMO hydroTRANS H50 Industrial Humidity Sensor | Seven Star LLC
Brand: JUMO
SKU: hydroTRANS H50

Description

Heated humidity and temperature transmitter for harsh industrial conditions

The JUMO hydroTRANS H50 (type 907055) is built for stable, accurate measurement of relative humidity and temperature in demanding conditions: wide temperature range from -80 to +180 °C, pressures up to 300 bar and chemically polluted or continuously humid environments. A heated, monolithic sensing element with a proprietary protective coating recovers quickly after condensation or chemical contamination.

Four probe families cover high temperature (type 10), medium pressure to 20 bar (20), high pressure to 300 bar (30) and high humidity with an extra temperature probe (40). The enclosure is polycarbonate or stainless steel, IP65 / NEMA 4X, and an optional 3.5 inch color display with push-buttons shows up to four measurands and graphs from a data logger holding 20,000 values per measurand.

Technical specifications

Parameter	Specification
Type	907055; probe types 10, 20, 30, 40; PC or stainless-steel enclosure
RH range / accuracy	0 to 100 % RH; for example +/-(0.95 + 0.0013 x reading) % RH at -15 to +40 °C up to 90 % RH; factory calibration uncertainty +/-(0.7 + 0.003 x reading) % RH to 90 % RH
Temperature range	Probes 10/20/30: -70 to +180 °C; probe 40: -80 to +180 °C; calibration uncertainty +/-0.05 °C at 23 °C
Response	t90 below 15 s with metal grid filter at 20 °C
Calculated values	Dew point -80 to +100 °C, frost point, wet-bulb, vapor pressure, mixing ratio, absolute humidity, specific enthalpy
Analog outputs	Two freely scalable: 0 to 1/5/10 V or 0 to 20 / 4 to 20 mA (3-wire); +/-0.05 % full scale; NAMUR error indication
Alarm outputs	Two changeover relays, 250 V AC / 6 A or 28 V DC / 6 A (alarm option 2)
Digital	RS485 Modbus RTU (9600 to 76800 baud); or Ethernet-PoE Modbus TCP, M12 X-coded
Supply	8 to 35 V DC or 12 to 30 V AC; optional integrated 100 to 240 V AC power supply (Class 2 supply required in USA and Canada); PoE with option 4
Pressure-tight probes	Types 20 and 40: 0.01 to 20 bar; type 30: 0.01 to 300 bar
Electronics ambient	-40 to +60 °C without display; -20 to +50 °C with display
Materials	Probe body stainless steel 1.4404 / AISI 316L; enclosure UL 94 V-0 polycarbonate or stainless steel 1.4404
Operating modes	Condensation Guard (types 10/20/30); High Humidity Guard (type 40); Automatic ReCovery (ARC)
Documents	Inspection certificate per DIN EN 10204-3.1 listed; PCS Configuration Software, USB-C service interface

Probe selection and options

The order code selects the basic type extension (10, 20, 30 or 40), enclosure (0 plastic, 2 stainless steel) and the filter, which can be stainless steel sintered, PTFE, stainless steel grid or PTFE membrane. Probe lengths, cable lengths, heating modes and interface options such as relay outputs, an ARC module or the Smart Probe connection are also coded in the data sheet.

The Smart Probe (connection option 7) is a pluggable probe that uploads its own parameters, so a damaged probe can be replaced even during operation without configuration, adjustment or calibration. The Automatic ReCovery function heats the sensing element intensely to remove chemical pollution and the resulting drift. It can be triggered manually, at set intervals, by Modbus commands or by the ARC module.

The data sheet shows the output set-up in detail: output 1 can carry relative humidity, dew point, mixing ratio, absolute humidity, wet-bulb temperature, vapor pressure or enthalpy, and output 2 can carry temperature in one of three ranges or the same calculated values. Both outputs share the same electrical type, voltage or current.

Probe bodies are made of stainless steel 1.4404 (AISI 316L), and the pressure-tight probes are rated 0.01 to 20 bar for types 20 and 40 and 0.01 to 300 bar for type 30. Make sure the process fitting you choose is rated for the same pressure.

Where it is worth the effort

Choose the H50 where cheaper sensors drift or fail: process dryers, climate chambers, pressurized pipelines, compressed-air dryers, offshore and coastal installations with salt contamination, and plants with oil, dust or corrosive vapors. The sensor coating is described as extending lifetime in salt and offshore applications.

Fit the pressure-tight probe types 20, 30 or 40 with the proper cut-in or sliding fitting for pressurized lines, and use the stainless-steel enclosure outdoors in harsh areas. Configure and adjust with the free PCS software, then document the final settings before commissioning.

Supply options matter for retrofits: the electronics run from 8 to 35 V DC or 12 to 30 V AC, an integrated 100 to 240 V AC supply can be ordered, and Ethernet-PoE versions can be powered over the network cable. A sample order code in the sheet is 907055/20-2-9-02-200-23-6-3-2-0-0-6-00-00, a stainless-steel, 20 bar probe with RS485, display and 4 to 20 mA outputs.

The data sheet describes Condensation Guard for the probe types 10, 20 and 30, High Humidity Guard for type 40 and Automatic ReCovery, which return the sensor to a dry state after wetting. Choose the probe type from the temperature and pressure of your process before the output options.

Documents and quotation

For engineering details, open the attached PDF (JUMO hydroTRANS H50 data sheet 907055 v1.0 (EN)). When you are ready to buy, submit the order code and project requirements through the request form, and our team will confirm what can be supplied and when. Browse the category Temperature Instrumentation for alternatives.

Datasheets & Documents

Datasheet JUMO hydroTRANS H50 data sheet 907055 v1.0 (EN) Download

Reviews (0)

Reviews

There are no reviews yet.

How would you rate this product?

About brand

JUMO is the German maker of temperature sensors, process controllers, pressure transmitters and liquid analysis instruments. Moritz Kurt Juchheim founded it in Fulda in 1948 as M. K. Juchheim KG, making glass thermometers with six employees. The name JUMO comes from the founder's name. It is still a family company headquartered in Fulda, and the parent company has been called JUMO GmbH & Co. KG since 2003.

Seven Star LLC is an independent supplier in Muscat. We list JUMO RTD and thermocouple probes, thermowells, transmitters, controllers, recorders and water analysis instruments, and supply them to process plants, OEMs, HVAC contractors and water utilities in Oman and the GCC by type number.

JUMO company profile

Established	1948, Fulda, Germany, by Moritz Kurt Juchheim
First products	Glass and contact thermometers; platinum glass sensors from 1966
Ownership	Family-owned; renamed JUMO GmbH & Co. KG in 2003
Product families	RTD and thermocouple probes, thermowells, temperature and pressure transmitters, controllers and thermostats, safety temperature limiters, paperless recorders, liquid analysis and flow and level instruments

Milestones

1948: Moritz Kurt Juchheim founds M. K. Juchheim KG in Fulda, making glass thermometers with six employees.
1966: Platinum glass temperature sensors are added.
2003: The parent company is renamed JUMO GmbH & Co. KG.

JUMO products we list

Family	Models	Typical use
RTD and thermocouple probes	902020, 902030, 902050, 902120, 902006 2xPt100, PROCESStemp, mineral-insulated RTD, 901020 thermocouple, 901210, 902810 hygienic, 902550 surface, 902520 HVAC, MarineTemp	Temperature measurement in pipes, vessels, machines, HVAC and food plants
Thermowells and inserts	909710 thermowells, 909740 measuring inserts	Protecting sensors and replacing them without opening the process
Temperature transmitters	dTRANS T01, T03, T04, T05, T06 SIL, T07 HART, T09, T1000 IO-Link, DELOS T switch	Converting sensor signals to 4-20 mA, HART or IO-Link
Pressure and level	dTRANS p20, p30, p31 hygienic, p33 Ex, p02 DELTA, MIDAS S05, MIDAS DP10, DELOS S02, MAERA S25, NESOS R20	Pressure in process, hydraulic and OEM systems; tank and well level
Controllers, limiters and recorders	DICON touch, IMAGO 500, dTRON 316, iTRON, cTRON, diraTRON 104, eTRON T, safetyM STB/STW, safetyM TB/TW, LOGOSCREEN 601, mTRON T	Furnace, oven and process control, over-temperature protection and recording
Liquid analysis and flow	AQUIS touch S, AQUIS touch P, AQUIS 500 pH, AQUIS 500 CR, dTRANS pH 02, pH electrode, digiLine DO, ecoLine NTU, flowTRANS MAG H20, flowTRANS US W01	pH, conductivity, oxygen and turbidity in water treatment; liquid flow

Choosing a temperature sensor starts with the range and accuracy. A Pt100 RTD is accurate and stable from about -200 to 600 °C and is the usual choice in process plants. A thermocouple (type K or J, for example) covers much higher temperatures and responds faster but is less accurate. The wiring also matters: a 3-wire or 4-wire Pt100 connection cancels the resistance of the cable, while a 2-wire connection adds an error that grows with cable length. That is why a head-mounted transmitter is often fitted close to the sensor.

Where JUMO products are used

In Oman and the GCC, JUMO sensors and controllers are used in oil and gas and chemical plants, food and beverage production, plastics and metal heat treatment, HVAC and district cooling, water and wastewater treatment, swimming pools and marine applications.

Ordering JUMO products: what we need

Send the JUMO type number and the full order code from the label (for example 902020/10-...). For probes, add the sensor type (Pt100, Pt1000, type K or J), the number of wires, the insertion length and diameter, and the process connection. For controllers, add the input, outputs and supply voltage.
