Brand: Elkhart Brass
Elkhart Brass Spit-Fire 8394-02 2000 gpm Dual Handwheel Monitor
Description
A 2000 gpm brass monitor for large flows
The Elkhart Brass Spit-Fire 8394-02 is the high-flow manual monitor in the Elkhart industrial range. It is rated for 2000 gpm (7550 LPM) at 200 psi (14 bar) and has a 4 in fully vaned waterway to keep stream reach and performance high at large flows. Elkhart states it is FM Approved to FM 1421 and suitable for corrosive and non-corrosive environments, and the data sheet lists the CE mark.
The 8394-02 uses a dual handwheel control, with the lower handwheel staying stationary while the monitor turns a full 360 degrees. A tiller bar version is sold as the 8394-121. The nozzle is supplied separately.
Technical specifications
| Parameter | Specification |
|---|---|
| Manufacturer / model | Elkhart Brass, Spit-Fire 8394-02 dual hand wheel monitor |
| Rated flow | 2000 gpm (7550 LPM) |
| Operating pressure | 200 psi (14 bar) |
| Inlet size | 4 in 150 lb ANSI flange |
| Outlet size | 3.5 in NHT |
| Travel | -45 to +90 degrees vertical (135 degrees); 360 degrees continuous horizontal |
| Controls | Dual hand wheel |
| Stops | 10 vertical and 7 horizontal adjustable stop positions |
| Material | Corrosion resistant brass; steel worm gears; 316 stainless steel balls in swivel joints with grease fittings |
| Weight | 110 lb (50 kg) |
| Ambient temperature | -35 °F to 232 °F (-37 °C to 111 °C) |
| Certification | FM Approved 1421, CE mark |
| Option | Liquid-filled pressure gauge |
The data sheet also lists a fully enclosed gearcase and low maintenance requirements.
Pairing nozzles and oscillators
Elkhart recommends the SM-2000B X-Stream, CJ-K, a model 84 butterfly valve, the 181-3 deluge tip and the 284-B stream shaper with the Spit-Fire. The monitor is FM Approved for use with the WPO-2000 water powered oscillator, giving automatic horizontal sweep without electric controls, and a Spit-Fire model (8394-053) is the monitor shown in the catalog for the Elkhart GEN-II ERCM electric remote-controlled system.
At 2000 gpm the reaction force on the riser is substantial, so the support, flange and anchoring need to be checked by the designer with the chosen nozzle. The data sheet includes a pressure loss curve for the 4 in inlet and 3.5 in outlet.
Elkhart instruction sheet 98071010 for the 8394-02 calls for a 4 in 150 lb ANSI companion flange on the supply pipe (Elkhart recommends the 81317001 companion flange kit), eight 5/8-11 UNC grade 5 bolts 2-1/2 in long, or 4-1/2 in with a wafer butterfly valve, with Loctite 242 and torque of 60 to 70 ft-lb in increments of about 20 ft-lb. The up and down handwheel turns with the monitor while the left and right handwheel stays fixed, and grease fittings on both rotation joints should be greased routinely with Mobilux EP2 or equivalent. After emergency use, inspect the monitor and nozzle for damage and check the swivel joints for leaks during a nozzle flow test.
Related Elkhart industrial monitors
| Elkhart industrial monitor | Rating and control |
|---|---|
| Copperhead 8593-02 / -03 / -IV | 1250 gpm, 3 in waterway, tiller bar, dual handwheel or built-in valve |
| Stingray 8393 | 1250 gpm, low profile, handwheel elevation, optional built-in ball valve (8393-IV) |
| Sidewinder 8392 | 500 gpm, 2 in waterway, compact tiller bar monitor |
| Hydrant mount 8393-H | 1250 gpm, mounts on a 2.5 in hydrant outlet |
| WPO-2000 | Water powered oscillator for monitors up to 2000 gpm |
Confirm before ordering
Confirm the flange standard, nozzle, hazard flow, ambient range and the control style (handwheel or tiller bar). The attached Elkhart data sheet contains pressure loss and dimensions. For a quotation, send the project details and quantity. More equipment is in our Fire Fighting equipment range.
Datasheets & Documents
- Datasheet Elkhart Brass 8394-02 Spit-Fire dual hand wheel monitor data sheet Download
Reviews (0)
About brand
Elkhart Brass is a fire fighting equipment manufacturer based in Elkhart, in the United States, and part of Clarience Technologies. It specialises in industrial fire fighting monitors and nozzles, including manual and remote controlled water and foam monitors, master stream nozzles and self-educting foam nozzles. Seven Star LLC lists selected Elkhart Brass products together with the technical data published by the manufacturer.
Elkhart Brass product ranges
The industrial range covers fixed and portable monitors such as the Copperhead, Stingray and Spit-Fire, water powered oscillating monitors, and nozzle families including X-Stream, Select-O-Stream and Hydro-Foam. Nozzles are offered in fixed and selectable flow versions, mostly in brass, for water or premixed foam solution.
Documents and quotation
Each Elkhart Brass product page links the manufacturer data sheet or manual, which lists flow, pressure, inlet size, materials and reach. Send the Elkhart Brass model number, quantity and delivery location with your request, and Seven Star LLC will prepare a quotation from its base in Muscat, Oman.
Related products
Frequently Asked Questions
What flow is the Spit-Fire 8394-02 rated for?
2000 gpm (7550 LPM) at 200 psi (14 bar).
What inlet does the 8394-02 have?
A 4 in 150 lb ANSI flange, with a 3.5 in NHT outlet.
How heavy is the 8394-02?
The data sheet lists 110 lb (50 kg).
What is the difference between 8394-02 and 8394-121?
The 8394-02 uses dual handwheels; the 8394-121 uses a tiller bar.
Can the Spit-Fire be used with the WPO-2000 oscillator?
Yes. Elkhart states it is FM Approved for use with the WPO-2000.
