Eaton DA1-342D2FB-A20C AC Drive
Application and model selection
The DA1-342D2FB-A20C is an Eaton PowerXL DA1 variable-frequency drive with a 2.2 A output-current rating. The exact model row lists 0.75 kW at 400 V / 50 Hz, or 1 hp at 440–480 V / 60 Hz.
This execution has an IP20 enclosure, frame FS2 and an LED display. The manufacturer identifies a radio-interference filter and brake chopper, with no integral DC choke or additional local controls.
Technical specifications
| Parameter | Specification |
|---|---|
| Model / range | DA1-342D2FB-A20C / PowerXL DA1 |
| Input phases | Three-phase |
| Output-current rating | 2.2 A |
| Motor rating at 400 V / 50 Hz | 0.75 kW |
| Motor rating at 440–480 V / 60 Hz | 1 hp |
| Protection / frame | IP20 / FS2 |
| Display | LED |
| Built-in functions | RFI filter and brake chopper |
| Integral DC choke | Not fitted |
Installation and equipment scope
A brake chopper does not include an external braking resistor. Select the resistor and duty for the application using the exact drive instructions; a recommended resistance is not a universal mandatory value.
Check the motor current, supply, cabinet ventilation, braking duty and required controls. Adjacent IP66 or OLED executions are different models.
Quotation enquiries
Send Seven Star LLC the complete model reference, quantity, supply voltage, motor nameplate and installation details. Identify any required keypad, communication module, reactor or braking accessory separately. A power rating alone does not establish a suitable replacement.
- Manual PowerXL DA1 Installation Manual — August 2018 Download
Eaton circuit protection listed here
The NZMN1-A80 is a frame size 1 molded case circuit breaker rated 80 A with a thermomagnetic release for cable and system protection. The PKZM0-1,6 is a motor-protective circuit breaker whose overload release is adjustable from 1 to 1.6 A, used as a manual motor starter. The LPJ-35SP is a Bussmann series Low-Peak Class J time-delay fuse rated 35 A at 600 V AC. Older NZM and PKZ devices carry the Moeller name on the nameplate, and the type designations are the same.Where Eaton breakers and fuses are used
Motor control centers, feeder panels, machine control cabinets and UL-style fused disconnects.Ordering Eaton parts: what we need
Send the full type and article number, the number of poles, the current rating or setting range, and any accessories such as auxiliary contacts, trip releases or rotary handles.Browse Eaton products by category: Circuit Breaker.
