Brand: Yaskawa
Yaskawa GA800 Industrial AC Drive, 1 to 1000 HP
Description
The Yaskawa GA800 is the high-power, high-flexibility member of the Yaskawa industrial AC drive range. It covers 1 to 1000 HP, drives induction, surface and interior permanent magnet and synchronous reluctance motors, and brings embedded Safe Torque Off, function blocks, a removable control terminal board and Bluetooth-based PC and mobile commissioning to everything from fans and pumps to test dynamometers.
Seven Star LLC, an independent supplier in Muscat, quotes GA800 drives by full catalog code. The attached document is the unaltered Yaskawa selection guide, including the catalog code tables used below.
Technical specifications
| Parameter | Specification |
|---|---|
| Series | GA800 AC drive for industrial applications (Yaskawa selection guide SL.GA800.01) |
| 240 V class (3-phase) | 1 to 150 HP Normal Duty; example catalog codes 2004 (4.2 A ND) to 2415 (415 A) |
| 480 V class (3-phase) | 1 to 1000 HP Normal Duty; example codes 4002 (2.1 A ND) to 4H12 (1200 A); models 4810 to 4H12 configurable for 6-pulse or 12-pulse input |
| 600 V class (3-phase) | 1 to 500 HP Normal Duty; example codes 5002 (1.7 A ND) to 5472 (472 A) |
| Overload capacity | 150 % for 60 s (Heavy Duty), 110 % for 60 s (Normal Duty) |
| Output frequency | 0 to 590 Hz |
| Control methods | Open and closed loop vector, open and closed loop V/f |
| Motor types | Induction, surface permanent magnet, interior permanent magnet, synchronous reluctance |
| Speed control range | 1500:1 closed loop vector; 200:1 open loop vector (induction); 100:1 open loop vector (PM) |
| Speed accuracy | 0.02 % or less closed loop vector; 0.2 % or less open loop vector |
| Functional safety | Safe Torque Off, SIL3 per IEC 62061, PLe per ISO 13849-1 (600 V models pending, consult factory); two STO inputs |
| Standard I/O | 8 digital inputs (24 Vdc), 3 analog inputs, 1 pulse input; 4 relay outputs (1 fault form C, 3 form A), 2 analog outputs, 1 pulse output |
| Expansion I/O | 16 digital inputs, 3 analog inputs, 2 analog outputs, 8 digital outputs (6 transistor, 2 relay) |
| Feedback options | Incremental and absolute encoders (Stegmann, Heidenhain, resolver) |
| Communications | Modbus RTU RS-485 (115 kbps) standard; optional EtherNet/IP, DeviceNet, Modbus TCP/IP, PROFINET, PROFIBUS-DP |
| Protective design | IP20 (Type 1 kit available), flange type with Type 12 backside, IP00/20 on the largest models |
| Ambient temperature | -10 to +50 C (IP20 and flange); -10 to +40 C with Type 1 kit; up to +60 C with derating; 95 % RH non-condensing |
| Altitude | Up to 1000 m without derating, up to 4000 m with derating |
| Certifications listed | UL, CSA, CE, RCM, RoHS, SEMI-F47, IEEE1668 |
Catalog code and how to size the drive
The selection guide builds the code as GA80 + region code (U = Americas) + input voltage digit (2 for 240 V, 4 for 480 V, 5 for 600 V) + a three-digit output current that follows the Normal Duty rating + A + enclosure letter (B for IP20, W for flange with Type 12 backside) + M for humidity and dust resistance. For example GA80U4005ABM is a 480 V, IP20 drive rated 5.4 A ND (3 HP ND, 2 HP HD, 4.8 A HD). Pair ND with variable-torque loads such as fans and centrifugal pumps, and HD with conveyors, crushers and other high-overload machines. The same tables list 12-pulse 480 V drives from 75 to 1000 HP (codes T103 to T720, then 4810 to 4H12), and special-firmware 1000/2000 Hz high frequency versions with the -056 suffix.
Control, safety and connectivity
Open loop vector handles most applications without feedback, while closed loop vector with an encoder card gives 1500:1 speed range and 0.02 % accuracy for dynamometers and winders. A built-in brake transistor is fitted up to 125 HP ND / 100 HP HD. Two Safe Torque Off inputs with a programmable EDM output remove torque without opening the main supply, so machines restart faster after a guard is opened. The control board accepts a 24 Vdc auxiliary supply so control power stays alive with main power removed, and up to five drives can be added as slaves over the embedded RS-485 port.
Enclosure and installation choices
Protected-chassis IP20 drives mount in a separate enclosure with heatsink inside or outside, and with the Type 1 kit they can stand alone. Flange-type drives put the heatsink outside a Type 12 cabinet when the surrounding air is dusty. The data section also covers fuse selection, with semiconductor fuses mandatory on larger sizes, plus EMC filters, AC and DC reactors, dynamic braking and R1000 regenerative units sold as options. See the GA700 and GA500 pages for smaller Yaskawa drives, or the AC drives category.
Documents and quotation
Before ordering please confirm: supply voltage and frequency, motor kW or HP and nameplate current, ND or HD duty, enclosure type, fieldbus option card, encoder type if closed loop, and regional model code. Catalog codes in the guide are printed for the Americas (GA80U); the code for other regions can differ, so confirm the exact order number with us before purchase.
Datasheets & Documents
- Selection Guide Yaskawa GA800 Selection Guide SL.GA800.01 (catalog codes and technical data) Download
Reviews (0)
About brand
Variable speed drives are the Yaskawa products most plant electricians meet first, usually on a pump, fan or conveyor. The company dates from 1915 and is based in Kitakyushu, Japan, and it also makes servo systems, robots and PLCs. Seven Star LLC supplies Yaskawa AC drives and control hardware in Oman. Listed here are the GA500 and GA700 drives and two 300S CPUs that many users still know under the VIPA name.
Yaskawa drives and VIPA controllers listed here
The GA500 is the compact microdrive for small motors and machine applications, and the GA700 is the general-purpose drive for larger motors and more demanding control. The GA500 is the follow-on to the V1000, and Yaskawa publishes a transition guide between the two. On the control side, the 315-2AG23 (CPU 315SB/DPM) and 315-4NE23 (CPU 315SN/NET) are SPEED7 processors of the 300S system, programmed with Siemens STEP 7 tools.
Ordering Yaskawa drives and CPUs: what we need
For a drive, send the full catalog code from the nameplate (it starts with CIPR-GA50 or CIPR-GA70), which fixes the voltage class, current rating and enclosure. Add the motor power and current, supply voltage, duty (normal or heavy) and any fieldbus option card. For a VIPA CPU, send the order number and the hardware and firmware version on the front label. We supply across the GCC and check each code against Yaskawa documentation.
Browse Yaskawa products by category: PLC & I/O Cards, AC Drives.
Related products
Frequently Asked Questions
What power range does the Yaskawa GA800 cover?
The selection guide lists three-phase drives from 1 HP to 150 HP at 240 V, 1 HP to 1000 HP at 480 V and 1 HP to 500 HP at 600 V (Normal Duty).
Which motors can the GA800 control?
Induction, surface permanent magnet, interior permanent magnet and synchronous reluctance motors, with open loop and closed loop vector or V/f control.
What safety function is built in?
Safe Torque Off with two inputs and EDM output, listed as SIL3 per IEC 62061 and PLe per ISO 13849-1. The guide notes 600 V models are pending and to consult the factory.
Which fieldbus options are available?
Modbus RTU RS-485 is standard. Optional modules cover EtherNet/IP, DeviceNet, Modbus TCP/IP, PROFINET and PROFIBUS-DP.
How do I read a GA800 catalog code?
GA80 plus region code, voltage digit, three-digit ND output current, A, enclosure letter (B IP20 or W flange) and M. For example GA80U4005ABM is a 480 V 5.4 A ND drive.
