Danfoss 068U4281 TCAE Thermostatic Expansion Valve R22/R407C
Description
TCAE: a stainless-steel straight-through expansion valve for R22 and R407C
The 068U4281 is a Danfoss TCAE thermostatic expansion valve for R22/R407C. Unlike the angled TUBE, this valve is a straightway design with a 1/2 in ODF solder inlet, a 5/8 in ODF outlet and a 1/4 in ODF equalization connection, so it drops straight into a liquid line without an elbow. The body is stainless steel and the bimetal connections are steel/copper.
The store entry lists a 1.5 m capillary, an evaporating range of -40 to 10 C, a maximum working pressure of 45.5 bar (660 psig) and a factory static superheat of 4 C with adjustable superheat setting. The flow direction is shown as bi-flow with orifice 1-2, and UL lists the valve for R22 and R407C.
Technical specifications
| Parameter | Specification |
|---|---|
| Danfoss code number | 068U4281 |
| Type | TCAE |
| Approvals as listed | EAC; UL; UA |
| Body material | Stainless steel |
| Capillary tube length | 59 in / 1500 mm |
| Equalization connection type | Solder, ODF |
| Equalization size | 1/4 in |
| Inlet connection type | Solder, ODF |
| Inlet size | 1/2 in |
| Maximum working pressure | 45.5 bar |
| Outlet connection type | Solder, ODF |
| Outlet size | 5/8 in |
| Pressure equalization | Externally equalized |
| Rated capacity conditions | OS=4K; tcond=38 C; tevap=4.4 C; tliq=37 C |
| Refrigerants | R22/R407C |
| Static Superheat (SS) | 4 C |
| Superheat setting | Adjustable |
| Temperature range | -40 C to 10 C |
| UL approved refrigerants | R22; R407C |
| Net weight | 0.205 kg |
| EAN | 5702428052108 |
Selecting a TCAE orifice and charge
This TCAE family is the larger-capacity sibling of the TUA/TCBE style valves: capacity is chosen by the orifice assembly, which is a replaceable part in this version (the page shows spare parts available for the TXV). That makes a TCAE a sensible choice for a fleet of packaged chillers or condensing units where several capacities share one body.
Select the orifice number from the capacity table in the data sheet for your refrigerant, evaporating temperature and liquid temperature, then keep the evaporator pressure drop in mind because the valve has an external equalizer. This code is the R22/R407C charge; an R410A or R134a unit needs a different charge and code.
Installation checks before you order
Fit the bulb on the horizontal suction line at 12 o’clock or 4 and 8 o’clock positions depending on pipe size, insulate it and keep it clear of oil traps. Connect the 1/4 in equalizer line downstream of the bulb. Protect the body from heat while brazing so that the diaphragm and seats are not damaged.
Confirm orifice number, refrigerant, connection sizes and approval needs against the attached data sheet. The Danfoss installation guide for TCBE / TCCE / TCAE and the TUA / TUAE / TCAE orifice guide cover the exchange procedure.
After brazing and before the bulb is insulated, check that the capillary has not been kinked or crushed by pipe clips, since a damaged capillary loses charge slowly and the valve then starves the evaporator.
Documents and quotation
Attached for download: Danfoss Thermostatic expansion valve, TU / TC AI561224665278en-000102 (manufacturer, unaltered), the manufacturer’s unaltered PDF. Browse comparable products in control valves. To order, send us 068U4281 and the required quantity; Seven Star LLC is an independent supplier based in Muscat.
