Allen-Bradley 800T-FXP16RA1 Illuminated Push-Pull Button
Description
Illuminated push-pull mushroom with transformer lamp
The Allen-Bradley 800T-FXP16RA1 is a 30 mm push-pull device with a 40 mm red mushroom head, an incandescent lamp supplied through a transformer for 120V AC, 50/60 Hz, and a maintained two-position action. Pull to one state, push to the other.
The product page lists a metal operator with a plastic cap and aluminium spinover, and an 800T-XA1 contact block with one normally-closed late-break contact and one normally-open contact. The late-break contact opens slightly after the others during a pull, which is useful in circuits where the order of operation matters.
Lamp, voltage and ratings
The lamp is incandescent and fed by a built-in transformer module accepting 120V AC. Lamp terminals take two 14 to 18 AWG wires at 0.7 to 0.9 N-m. Contact rating is 10 A thermal at up to 600V, with A600 / Q600 utilization categories and a contact electrical life of one million cycles at maximum load.
The operator is rated for 250,000 mechanical cycles minimum. Mounting hole is 30.5 mm, and NEMA 1, 4, 12 and 13 enclosures are supported. Temperature limits in the series datasheet differ for incandescent and LED lamps, with the incandescent versions rated to a lower maximum.
Replacement and wiring points: the lamp circuit has its own terminals, separate from the contact block, so the 120V AC lamp supply is not mixed with the control circuit. Keep lamp and control conductors segregated if the control voltage differs, and check the transformer module is suitable for your supply frequency (50 or 60 Hz).
Series temperature limits are -40 to +40 C for incandescent versions and -40 to +55 C for LED versions, with storage down to -40 C and up to +85 C; confirm the actual panel temperature in Oman summer conditions before choosing an incandescent lamp.
Technical specifications
| Parameter | Specification |
|---|---|
| Catalog number | 800T-FXP16RA1 |
| Type | 30 mm push-pull device, maintained 2-position |
| Cap | Red, 40 mm mushroom, plastic with aluminium spinover |
| Lamp | Incandescent via transformer, 120V AC 50/60 Hz |
| Contact block | 1 N.C.L.B. + 1 N.O., 800T-XA1 |
| Mounting hole | 30.5 mm |
| Enclosure types | NEMA 1, 4, 12, 13 |
| Contact rating | 10 A thermal, 600V, A600 / Q600 |
| Operator life | 250,000 cycles minimum |
| Illuminated | Yes |
Why push-pull
Push-pull operators suit latching functions such as a process hold or a safe-state request that must stay in position until someone pulls it out. The lamp shows the state at a glance, which supports shift handover in plants.
This is not a certified emergency-stop catalog number. Choose a dedicated safety e-stop device if the circuit needs a safety function, and confirm the 120V AC lamp supply with the panel design.
Ordering and documents
Quote 800T-FXP16RA1 in full. The linked document is 800-TD009L (September 2025), the specification for 800T push buttons; replacement lamps and legend plates are separate catalog numbers.
Seven Star LLC is an independent supplier in Muscat and quotes on request; please confirm every rating against the current Rockwell documents before ordering.
Please send the quantity of 800T-FXP16RA1, the conductor sizes, the control voltage, and the accessories needed with it. Small panel components are easy to under-specify, so we confirm each accessory by catalog number before preparing the quotation (30 mm push-pull red mushroom, illuminated, 120V AC transformer, 1 N.O. + 1 N.C.L.B).
Browse more items in Automation Accessories on our site, or send us the part number for a quotation.
