Brand: Winsonic
Winsonic NE24004-10833B 4G LTE Gateway with IP30-Rated 9-Port Switch and SFP Uplinks
Description
Overview
Winsonic NE24004-10833B is a high-port-count 4G LTE gateway combining an 8-port Gigabit switch with 2 Gigabit SFP fibre uplinks behind a single cellular or wired WAN connection, purpose-built for street-cabinet and lamp-pole style deployments. Built on Winsonic’s industrial networking platform, the NE24004-10833B pairs a cellular or wired WAN uplink with 8x 10/100/1000Mbps Gigabit Ethernet ports plus 2x Gigabit SFP fibre uplink slots and 1 drawer-type SIM/UIM slot (1.8V/3V), giving system integrators a single rugged box that keeps critical field networks online even when a primary link fails.
As the official authorized partner and exclusive regional representative for Winsonic, Seven Star LLC proudly supplies the Winsonic NE24004-10833B to system integrators, utilities and industrial operators throughout Oman, Muscat and the wider GCC, with local technical support for every unit supplied.
Operating Principle
The Winsonic NE24004-10833B establishes its wide-area connection over 1 WAN port (configurable as LAN), negotiating with the mobile network or upstream fixed line and then routing, NATing and firewalling traffic between the WAN interface and its local 8x 10/100/1000Mbps Gigabit Ethernet ports plus 2x Gigabit SFP fibre uplink slots. 1 drawer-type SIM/UIM slot (1.8V/3V) lets the gateway automatically fail over to a backup operator or SIM the moment the connection manager detects a data-limited, denied or lost network condition, so field devices behind the router keep reporting without manual intervention.
All routing, VPN tunnelling and protocol handling run on the router’s embedded Linux platform (Linux OpenWrt), which supports IPsec, OpenVPN, L2TP, PPTP, GRE, GRETAP and VxLAN tunnels to carry field traffic securely back to a central SCADA host, cloud platform or VPN concentrator. The practical result for the operator is a single device that combines cellular WAN redundancy, industrial-grade protocol handling and centralised remote management through Winsonic’s StarCloud platform, with no moving parts and no field maintenance beyond periodic firmware review.
Engineering Design of the Winsonic NE24004-10833B
The Winsonic NE24004-10833B is built around 512MB RAM, 4GB eMMC flash and an industrial-grade cellular module, housed in a 295 x 120 x 70mm full-metal chassis, desktop, rail and wall mountable, -35 to +75°C operating range enclosure with IP30 ingress protection. Power is supplied via 220V AC power input, with built-in reverse-polarity, overvoltage and overcurrent protection, and every Ethernet, serial and SIM interface carries dedicated isolation or ESD protection (1.5KV electromagnetic isolation on Ethernet, up to 15KV ESD on serial and SIM interfaces) to survive the electrical transients typical of industrial and outdoor installations.
Interface-wise the Winsonic NE24004-10833B provides 1 WAN port (configurable as LAN) and 8x 10/100/1000Mbps Gigabit Ethernet ports plus 2x Gigabit SFP fibre uplink slots, 2x Gigabit SFP fibre ports and hand-in-hand ring/STP support for redundant fibre-ring topologies, and ring-network (hand-in-hand) and STP support for redundant topologies, giving installers the flexibility to connect field controllers, cameras, meters or vehicle buses directly to the gateway. 802.11b/g/n Wi-Fi extends connectivity to local wireless clients where fitted, and the unit is rated for ≥100,000 hours MTBF with a net weight of 0.82kg net / 1.02kg gross, reflecting Winsonic’s fully industrial, fanless design philosophy.
Key Features
The Winsonic NE24004-10833B bundles cellular redundancy, industrial protocol support and remote manageability into a single DIN-rail-ready device. Key characteristics include:
- 1 WAN port (configurable as LAN) combined with 8x 10/100/1000Mbps Gigabit Ethernet ports plus 2x Gigabit SFP fibre uplink slots for flexible WAN/LAN network architecture.
- 1 drawer-type SIM/UIM slot (1.8V/3V), ensuring continuity of service if a primary carrier fails.
- Comprehensive VPN suite: IPsec, OpenVPN, L2TP, PPTP, GRE, GRETAP and VxLAN.
- ring-network (hand-in-hand) and STP support for redundant topologies for direct connection of legacy and modern field instruments.
- 220V AC power input with reverse-polarity, overvoltage and overcurrent protection.
- IP30 rated enclosure built for 295 x 120 x 70mm full-metal chassis, desktop, rail and wall mountable, -35 to +75°C operating range.
- Centralised remote management and firmware updates via Winsonic’s StarCloud / Star Device Manager platform.
- SNMP v1/v2/v3 support with traps, traffic statistics and alert thresholds for proactive network monitoring.
Industrial Applications
The Winsonic NE24004-10833B is specified wherever a site needs cellular WAN redundancy alongside 8x 10/100/1000mbps gigabit ethernet ports plus 2x gigabit sfp fibre uplink slots, particularly smart street lighting and lamp-pole networks, traffic-junction camera aggregation, and any site needing a high port-count switch with 4G LTE backup on the same chassis. Its combination of industrial protocol support, wide power input and extended operating temperature range makes it equally suited to unmanned outdoor cabinets and indoor control rooms across district cooling plants, RO desalination sites, and oilfield and utility telemetry networks.
As the officially authorized partner for Winsonic, Seven Star LLC distributes the NE24004-10833B to system integrators and utilities delivering resilient industrial networks throughout Oman and the GCC, including projects in the Sohar and Salalah economic zones and Muscat-area municipal and utility infrastructure that depend on continuous cellular backhaul.
Technical Specifications
The table below summarises the principal hardware and networking specifications of the Winsonic NE24004-10833B:
| Parameter | Specification |
|---|---|
| Model | NE24004-10833B |
| Description | 4G LTE Gateway with IP30-Rated 9-Port Switch and SFP Uplinks |
| WAN Interface | 1 WAN port (configurable as LAN) |
| LAN / Ethernet | 8x 10/100/1000Mbps Gigabit Ethernet ports plus 2x Gigabit SFP fibre uplink slots |
| SIM / Cellular | 1 drawer-type SIM/UIM slot (1.8V/3V) |
| Wi-Fi | 802.11b/g/n Wi-Fi |
| Serial / Extra Interfaces | ring-network (hand-in-hand) and STP support for redundant topologies; 2x Gigabit SFP fibre ports and hand-in-hand ring/STP support for redundant fibre-ring topologies |
| Memory / Storage | 512MB RAM, 4GB eMMC flash |
| Power Input | 220V AC power input |
| Protection Rating | IP30 |
| Operating System | Linux OpenWrt |
| Enclosure | 295 x 120 x 70mm full-metal chassis, desktop, rail and wall mountable, -35 to +75°C operating range |
| Weight | 0.82kg net / 1.02kg gross |
| Reliability | ≥100,000 hours |
| VPN Support | PPTP, L2TP, IPsec, OpenVPN, GRE, GRETAP, VxLAN |
| Management | SNMP v1/v2/v3, Web GUI, SSH/Telnet, StarCloud platform |
Request a Quote for Winsonic NE24004-10833B
Seven Star LLC invites system integrators, utilities and industrial end users across Oman and the GCC to submit a formal RFQ for the Winsonic NE24004-10833B. We supply on request with lead time confirmed at quotation, provide the official Winsonic technical datasheet on request, and our instrumentation and networking division can help confirm SIM, antenna and power requirements before you order. As the authorized partner for Winsonic in Oman and the GCC, we supply every NE24004-10833B with manufacturer documentation and technical support. Contact Seven Star LLC today to request pricing and lead time for the Winsonic NE24004-10833B.
Browse the full Winsonic range or see more Industrial Communications products supplied by Seven Star LLC in Oman and the GCC.
Reviews (0)
About brand
Rail-grade Ethernet switches with M12 connectors, industrial cellular routers and panel PCs are the Winsonic products buyers ask us for most. Winsonic is known as a maker of industrial LCD monitors and touch displays, and the products listed here add networking and computing hardware for places where office equipment does not survive: trains and buses, roadside cabinets, pump stations and factory floors.
Seven Star LLC is the Winsonic agency for Oman and the GCC and lists Winsonic EN 50155 switches, 4G and 5G routers and gateways, SFP transceivers, panel PCs and rack mount monitors.
Winsonic product families
The M12 switches on this page are specified to EN 50155, the standard for electronic equipment on rail vehicles. Listed models include the L2 managed NE10002 and the NE10003 in IP68 housings, the unmanaged NE10004 with 10G ports and IP65 sealing, the unmanaged NE10005 and the 5-port IP68 NE10006, with PoE+ or PoE++ ports depending on the model. On the cellular side the listing covers NE24 series industrial 4G routers and edge gateways, the NE20001 vehicle-grade 5G transit gateway and the NE31001 outdoor LTE-A router. WSFP Gigabit SFP transceivers provide the fiber uplinks. Computing and display products include the PZB zero bezel panel PC and the RM rack mount monitor, next to the flush mount and zero bezel LCD monitors Winsonic builds for industrial use.
Where Winsonic equipment is used
Typical uses are on-board networks for trains, metro cars and buses, wayside cabinets, traffic management, remote pump stations and water plants, energy metering at unmanned sites, and machine monitoring and operator stations in factories.
Ordering Winsonic switches and routers: what we need
Send the complete part number, including the digits after the hyphen, because they separate variants of the same base model. Where you are still selecting, give us:
- port count, port speed and connector type (M12 coding or RJ45)
- PoE power needed per port and the supply voltage available
- managed or unmanaged operation, and the IP rating required
- for routers: mobile operator, SIM count, serial or Ethernet interfaces
- for panel PCs: screen size, touch type, processor and mounting
Browse Winsonic products by category: Industrial Communications, Industrial Computer, Human Machine Interface (HMI) Displays.
Related products
Frequently Asked Questions
What makes the Winsonic NE24004-10833B suitable for unattended remote sites?
The NE24004-10833B combines 1 drawer-type SIM/UIM slot (1.8V/3V), IP30 ingress protection and 220V AC power input with built-in surge and reverse-polarity protection, so it keeps operating and automatically fails over to a backup connection at unmanned sites without a technician present.
Does the NE24004-10833B save on installation and cabling costs?
Yes. Because the NE24004-10833B integrates 8x 10/100/1000mbps gigabit ethernet ports plus 2x gigabit sfp fibre uplink slots together with its cellular or wired WAN uplink and VPN engine in one DIN-rail or wall-mount enclosure, integrators avoid separate router, switch and VPN-appliance purchases and the associated cabling and panel space.
What interfaces does the NE24004-10833B support for connecting field instruments?
The NE24004-10833B provides ring-network (hand-in-hand) and STP support for redundant topologies in addition to its Ethernet ports, 2x Gigabit SFP fibre ports and hand-in-hand ring/STP support for redundant fibre-ring topologies, allowing direct connection of legacy serial devices, PLCs and modern IP-based equipment on the same gateway.
Can the NE24004-10833B be centrally managed alongside other Winsonic devices?
Yes. The NE24004-10833B supports SNMP v1/v2/v3 and Winsonic's StarCloud / Star Device Manager platform, letting network administrators monitor status, push firmware updates and manage configuration across large fleets of routers and gateways from a single console.
Is Seven Star LLC an authorized representative for Winsonic products?
Yes. Seven Star LLC is the official authorized partner and exclusive regional representative for Winsonic in Oman and the GCC, supplying genuine products with local technical support.
