Brand: Danfoss
Danfoss 034G7501 ETS 12C Colibri Electric Expansion Valve
Description
ETS 12C Colibri: a compact stainless-steel stepper expansion valve with ATEX marking
Danfoss 034G7501 is an ETS 12C from the Colibri line. It is a stainless-steel electric expansion valve with 16 mm (5/8 in) ODF connections, a Kv value of 0.8 m3/h, a stroke of 600 full steps and an M12 four-pin connector. The motor is bipolar, with 600 mA RMS and 800 mA peak phase current, and it can be driven with full steps, half steps or microsteps; Danfoss recommends microstepping.
Full travel takes only 3 to 6 s, much faster than the ETS 12.5. Rated capacity at the standard conditions is 60.7 kW on R404A/R507A and 98.1 kW on R410A, and the valve is approved for oil-free applications with R1234ze(E), R134a, R513A, R515A, R515B and R516A. The maximum working pressure is 50 bar and MaxOPD 40 bar.
Technical specifications
| Parameter | Specification |
|---|---|
| Danfoss code number | 034G7501 |
| Type | ETS 12C |
| Ambient temperature range | -40 C to 70 C |
| Approvals as listed | ATEX; CCC; CE; CMIM; EAC; UKCA; UR; UA |
| Balanced port | Yes |
| Body material | Stainless steel |
| Compatible Danfoss controllers | EKE 1A; EKE 1B; EKE 1C; MCX 061V; MCX 152V |
| Electrical connection | M12 |
| Electrical connection size | 4 pin |
| Enclosure rating IP | IP67 |
| EX Sales text | II 3G Ex ec IIB T4 Gc |
| Full travel time speed | 3 s to 6 s |
| Inlet connection type | Solder ODF |
| Inlet size | 5/8 in / 16 mm |
| Kv value | 0.8 m3/h |
| Manual operation option | AST-G service driver |
| Max. power consumption, current drive | 7.2 W |
| Max. power consumption, voltage drive | 7.2 W |
| Maximum working pressure | 50 bar |
| Maximum operating pressure differential (MaxOPD) | 40 bar |
| MaxOPD, reverse flow | 40 bar |
| Oil free refrigerants | R1234ze(E); R134a; R513A; R515A; R515B; R516A |
| Operating current max. | 0.8 A |
| Outlet connection type | Solder ODF |
| Outlet size | 5/8 in / 16 mm |
| Phase current (peak) | 800 mA |
| Phase current (RMS) | 600 mA |
| Rated capacity note | Full stroke open, normal flow |
| Rated cap. conditions | tcond=32 C; tevap=5 C; tliq=28 C |
| Rated capacity R404A/R507A | 60.7 kW |
| Rated capacity R134a | 50.3 kW |
| Rated capacity R22 | 86.6 kW |
| Rated capacity R407C | 89.1 kW |
| Rated capacity R410A | 98.1 kW |
| Net weight | 0.308 kg |
| EAN | 5702428887502 |
Colibri features and use
Colibri valves are made for chillers, heat pumps and air-handling units where compact size and fast response matter. The body is stainless steel; the page lists approvals ATEX, CCC, CE, CMIM, EAC, UKCA and UR, and an Ex marking of II 3G Ex ec IIB T4 Gc. The ambient range is -40 to 70 C and the refrigerant temperature up to 95 C.
Compatible Danfoss controllers listed are EKE 1A, EKE 1B, EKE 1C, MCX 061V and MCX 152V. The valve is balanced-port and bi-flow with a laser-engraved two-way arrow. It is not serviceable, and has no sight glass.
Electrical data and ordering notes
Power consumption is up to 7.2 W with either current or voltage drive, notably higher than the ETS 12.5, so check the output of the controller. The step mode, the full-step count of 600 and the 0.8 A maximum operating current appear in the data table above.
Confirm the refrigerant, the Ex requirement of your installation and the connection size against the Colibri data sheet before ordering. Different Colibri sizes (ETS 24C, 25C, 50C, 100C) share the data sheet but have different code numbers and flow ratings.
Other types and sizes from the same Danfoss family that appear in the Danfoss store listing include ETS 500L (034G0138), ETS 5M20L (034G0174), ETS 5M24L (034G0175), ETS 100 (034G0501), ETS 50 (034G1704), ETS 25B (034G1721), ETS 250 (034G2602), ETS 400 (034G3501). These are listed for orientation only; each has its own datasheet values, so check size, connection and version before ordering.
Documents and quotation
The attached file is the Danfoss Colibri® Electric expansion valves Type ETS 12C, ETS 24C, ETS 25C, ETS 50C, ETS 100C AI246886497271en-000803 (manufacturer, unaltered). It is the manufacturer’s own PDF, hosted here unaltered. Related items sit under control valves. Seven Star LLC is an independent supplier in Muscat; send the code 034G7501 with the quantity and we will quote.
Datasheets & Documents
- Datasheet Danfoss Colibri® Electric expansion valves Type ETS 12C, ETS 24C, ETS 25C, ETS 50C, ETS 100C AI246886497271en-000803 (manufacturer, unaltered) Download
Reviews (0)
About brand
Danfoss is the Danish engineering group that makes refrigeration and air-conditioning controls, heating components, variable speed drives and mobile hydraulics. Mads Clausen founded it on 1 September 1933 at his parents' farm in Nordborg on the island of Als, after making his first refrigeration expansion valve in 1932. Nordborg is still the group's headquarters, and Danfoss remains controlled by the Clausen family through the Bitten & Mads Clausen Foundation.
Danfoss company profile
| Founded | 1 September 1933, Nordborg, Denmark, by Mads Clausen (1905–1966) |
|---|---|
| First product | Thermostatic expansion valve for refrigeration |
| Headquarters | Nordborg, Denmark |
| Ownership | Private; majority controlled by the Bitten & Mads Clausen Foundation and the Clausen family |
| Size | About 42,000 employees (2023) |
| Business segments | Danfoss Climate Solutions (refrigeration, air conditioning and heating), Danfoss Drives (VLT and VACON frequency converters, soft starters), Danfoss Power Solutions (mobile and industrial hydraulics) |
| Brands in the group | VLT, VACON, Eaton Hydraulics (bought 2021), Ikusi radio remote controls |
Milestones
- 1932–1933: First expansion valve; the company is founded in Nordborg.
- 1939: 26 employees. By the 10th anniversary in 1943 the company has 179.
- 1950s: Rapid growth turns Nordborg into a Danfoss town with housing and schools for its workforce.
- 1968: Danfoss launches its VLT frequency converter, one of the first mass-produced AC drives.
- 2014: Acquisition of the Finnish drives maker Vacon, now the VACON brand.
- 2021: Acquisition of Eaton's hydraulics business.
Choosing Danfoss products
For solenoid valves, check the operating principle. A direct-operated valve such as EV210B opens even at 0 bar differential pressure. A servo-operated valve such as EV220B needs a minimum differential (typically about 0.3 bar) to open, while an assisted-lift valve such as EV250B works from 0 bar. Coils are ordered separately, so the voltage on the coil (for example 230 V AC or 24 V DC) must match the control circuit. For drives, the VLT family is split by application: FC 51 Micro Drive for small machines, FC 102 HVAC Drive for fans and pumps in buildings, FC 202 AQUA Drive for water, and FC 302 AutomationDrive for demanding industrial duty.
Where Danfoss products are used
In Oman and the GCC, Danfoss drives run pumps, fans and compressors in district cooling plants, water and wastewater stations, desalination and building HVAC. Danfoss pressure switches, transmitters and solenoid valves are built into chillers, refrigeration plants, boilers and hydraulic systems, and AB-QM valves balance chilled-water circuits in large buildings.
Danfoss products we list
| Family | Examples |
|---|---|
| Variable speed drives and soft starters | VLT Micro Drive FC 51, VLT HVAC Drive FC 102, VLT AQUA Drive FC 202, VLT AutomationDrive FC 302, FC 280, iC2-Micro, VACON NXP, MCD 600 soft starter |
| Solenoid valves and coils | EV220B, EV210B, EV250B, EV225B steam, EVR 25, AM230C coil |
| Pressure switches and thermostats | KP 37, KP 44, RT 200, CS, MBC 5000, KPS 77, RT 101 |
| Pressure transmitters | MBS 3000, MBS 5100, MBS 3250, MBS 4251 Ex, AKS 33, DST P92S SIL 2 |
| HVAC and refrigeration valves | AB-QM PICV, NovoCon S, AB-PM, AVTA, ICV, TE 5 element |
Ordering Danfoss products: what we need
Send the Danfoss code number from the label (for example 032U7115 or 131B0149) or the full drive type code (FC-302P3K0T5...). For drives, add the motor power, supply voltage and any fieldbus option. For valves, add the size, connection, medium and coil voltage. For pressure switches and transmitters, add the range, output and pressure connection.
Facts checked against Danfoss's company history pages and published company data, October 2026.
Browse Danfoss products by category: AC Drives, Pressure Instrumentation, Control Valves, Solenoid Valve.
Related products
Frequently Asked Questions
What is Danfoss 034G7501?
An ETS 12C Colibri stepper-motor electric expansion valve in stainless steel with 16 mm ODF connections.
How fast does it open?
Full travel takes 3 to 6 s over 600 full steps.
What explosive-atmosphere marking is listed?
II 3G Ex ec IIB T4 Gc, as shown on the product page.
Which controllers are listed?
EKE 1A, EKE 1B, EKE 1C, MCX 061V and MCX 152V.
Which document is attached?
The Danfoss Colibri ETS 12C - ETS 100C data sheet (manufacturer PDF, unaltered).
