Scinor SMT600-P40 Pressurized Ultrafiltration Module
Overview
The Scinor SMT600-P40 Pressurized Ultrafiltration Module utilizes state-of-the-art Thermally Induced Phase Separation (TIPS) PVDF hollow fiber membrane technology to deliver the highest permeability, mechanical strength, and chemical tolerance available in the ultrafiltration market. Certified to NSF/ANSI 61, the SMT600-P40 is engineered as a retrofit module compatible with major membrane vendor installations, giving water treatment operators a genuine choice when replacing aging or underperforming membrane elements without redesigning the surrounding skid.
Seven Star LLC supplies the Scinor SMT600-P40 as an experienced supply partner to municipal water treatment plants, desalination facilities, and industrial water reuse operators across Oman and the GCC. Every module supplied through Seven Star LLC comes with local technical support for installations in Muscat, Sohar, and Salalah.
Measurement and Operating Principle
The SMT600-P40 operates in an outside-in configuration, allowing dead-end or cross-flow operation depending on the specific requirements of the application, with feed water passing from outside the hollow fiber membranes to the interior lumen where filtrate is collected. A tight 0.1 µm nominal pore size distribution delivers excellent filtered water quality, achieving turbidity of 0.1 NTU or lower, silt density index below 3, and non-detect E. coli removal performance suitable for potable water and reuse applications.
Cleaning processes include simple backwash, maintenance clean, and Clean-in-Place (CIP) procedures, with the membrane tolerating sodium hypochlorite concentrations up to 5,000 ppm and a CIP pH range of 1-13, supporting aggressive fouling recovery without compromising membrane integrity or shortening operational life.
Engineering Design of the Scinor SMT600-P40
Constructed with PVDF hollow fibers measuring 0.7mm ID / 1.3mm OD within a U-PVC/ABS housing sealed with EPDM O-rings, the SMT600-P40 module measures 160mm x 1804mm and provides 431 ft2 (40 m2) of effective filtration area per module. Operating temperature range spans 33°F to 104°F (1°C to 40°C) with a pH operating range of 1-11, while typical flux rates of 20-120 gfd (34-200 lmh) and trans-membrane pressure of 3-22 psi provide flexibility across a wide range of source water qualities.
Maximum feed pressure is rated at 58 psi (0.4 MPa) with maximum trans-membrane pressure of 44 psi (0.3 MPa), and typical filtered water capacity reaches 5.9-35.2 gpm per module. Each module weighs 97 lb (44 kg) filled with water or 42 lb (19 kg) empty, with a packing weight of 82 lb (37 kg) for shipping and handling planning.
Key Features
- TIPS PVDF hollow fiber membrane, NSF/ANSI 61 certified
- Retrofit compatible with major membrane vendor installations
- Tight 0.1 µm nominal pore size for excellent filtered water quality
- High NaClO tolerance up to 5,000 ppm for aggressive cleaning
- Outside-in configuration, dead-end or cross-flow operation
- 431 ft2 (40 m2) effective filtration area per module
- Non-detect E. coli removal and turbidity ≤0.1 NTU performance
- Automatic operation with low energy and chemical consumption
Industrial Applications
The SMT600-P40 is deployed across Oman’s potable water treatment, municipal wastewater reuse, desalination pretreatment, and industrial process water applications, where its high flux, low fouling tendency, and long operational life reduce total cost of ownership compared to lower-grade membrane technologies. Its retrofit compatibility makes it a practical membrane replacement option for existing ultrafiltration skids across Sohar and Salalah water treatment infrastructure without requiring capital-intensive skid modifications.
As a trusted supplier of Scinor products, Seven Star LLC supports water treatment plant operators and EPC contractors across Muscat, Sohar, and Salalah with genuine SMT600-P40 membrane modules correctly specified for the target feed water quality and system configuration. Responsive local technical support helps project teams select the right module for their filtered water quality targets.
Technical Specifications
| Model | Scinor SMT600-P40 |
|---|---|
| Membrane Material | PVDF (TIPS process) |
| Nominal Pore Size | 0.1 µm |
| Effective Area | 431 ft² (40 m²) |
| Configuration | Outside-in, dead-end or cross-flow |
| Max NaClO Tolerance | 5,000 ppm |
| Max Feed Pressure | 58 psi (0.4 MPa) |
| Typical Flux | 20–120 gfd (34–200 lmh) |
| Filtered Water Turbidity | ≤ 0.1 NTU |
| Certification | NSF/ANSI 61 |
Why Choose Seven Star LLC for Scinor Ultrafiltration Membrane Systems
An ultrafiltration module’s real performance depends on matching membrane pore size, flow capacity, and pressure rating to your actual feed water quality and treatment throughput requirements, since an undersized module fouls prematurely while an oversized one adds unnecessary capital cost to a treatment train. Seven Star LLC works with your water treatment engineers to confirm the correct SMT600-P40 configuration against your feed water characteristics and required permeate flow before order confirmation, drawing on our regional membrane systems partnership across Oman and the wider GCC. We also support municipal and industrial water treatment operators across Muscat, Sohar, and Salalah with membrane replacement scheduling and cleaning-in-place program planning, keeping treatment capacity stable as membranes age through their service life, and our technical team can advise on backwash and chemical cleaning protocols suited to your specific feed water fouling characteristics, and coordinate regional delivery so membrane replacement modules arrive before scheduled maintenance windows rather than after treatment capacity has already dropped. For desalination-adjacent and industrial reuse projects across the region, we also assist with sizing multiple ultrafiltration trains in parallel to meet growing throughput demand without a full treatment plant redesign or the extended construction downtime that a complete plant expansion would otherwise require, giving utilities and industrial operators a practical path to scale treatment capacity in step with actual demand growth.
Contact Seven Star LLC today to request a quotation for the Scinor SMT600-P40 Pressurized Ultrafiltration Module with technical support for water treatment membrane projects across Oman and the GCC.
Related Products
- Brochure Scinor SMT600-P40 Pressurized Ultrafiltration Module Catalog Download
Scinor SMT600 modules listed here
Three module types are on this page. The SMT600-P40 and SMT600-P80 are pressurized ultrafiltration modules that sit in a rack and are fed by a pump. The SMT600-S60 is a submerged module that hangs in an open tank and works under suction. The letter after SMT600 tells you the configuration, so P and S modules are not interchangeable on the same skid.Where Scinor membranes are used
The manufacturer references projects in power generation, petrochemical and chemical plants, coal, steel and municipal water supply. Typical duties are pretreatment ahead of reverse osmosis, surface water clarification and wastewater reuse, which are common needs across the GCC.Ordering Scinor modules: what we need
Send the full module code from the label, the number of modules per rack or cassette, the feed water type and whether the request is a like-for-like replacement or a new train. A photo of the existing end caps and connections helps us confirm the fit.Browse Scinor products by category: Filtration Elements.
