Johnson Controls VFC-060HB-722D Butterfly Valve
Overview
The Johnson Controls VFC-060HB-722D is a 6-inch (150mm), two-way, ANSI Class 125 flanged butterfly valve from the VF Series – one of the most widely specified control valve platforms in commercial HVAC and building automation worldwide. Paired with a Johnson Controls VA-9072 series non-spring-return electric actuator, it provides reliable two-position or modulating on/off control of hot water, chilled water, condenser water, and 50/50 glycol solutions in large-diameter hydronic distribution mains. The valve’s 416 stainless steel disc and EPDM seat combination is rated for 175 psig shutoff, and its Cv of approximately 1850 makes it suitable for the high-flow trunk lines found in chiller plants, cooling towers, and district cooling energy transfer stations.
With fast quotation turnaround and technical support, Seven Star LLC proudly supplies genuine Johnson Controls VFC-060HB-722D valve and actuator assemblies to consulting engineers, MEP contractors, and facility operators across Oman and the wider GCC. The Johnson Controls VFC-060HB-722D is supplied as a complete, factory-matched valve and actuator package. Seven Star LLC supplies each unit on request with access to the manufacturer’s technical documentation – important on large-diameter valves, where the disc and seat combination affects an entire chilled water loop.
Operating Principle
The Johnson Controls VFC-060HB-722D butterfly valve regulates flow through a quarter-turn rotating disc mounted on a through-shaft, centered in the pipe bore. When the electric actuator drives the shaft from 0° (closed) to 90° (open), the disc rotates from a position flush across the flow path to one parallel with it, progressively opening the flow area. Because the disc remains in the flow stream at all positions, the valve inherently provides tight shutoff against its EPDM seat while requiring a comparatively compact valve body and actuator torque relative to a globe or gate valve of equivalent line size – one reason the Johnson Controls VFC-060HB-722D is so frequently specified over legacy alternatives – a major advantage on 6-inch and larger hydronic mains where full-diameter globe valves become physically unwieldy and expensive to actuate.
The VA-9072 series non-spring-return electric actuator directly couples to the valve shaft and drives it between end stops on command from the building automation system, typically via a two-position or floating control signal. Because the disc geometry produces a roughly linear flow characteristic across the mid-travel range, the valve gives predictable, repeatable flow response to BAS commands without the non-linear “quick-opening” behavior that plagues undersized ball valves on large lines. For the Johnson Controls VFC-060HB-722D, the practical result for the facility engineer is stable loop control, low actuator torque demand, a compact footprint that simplifies retrofit into existing mechanical rooms, and minimal permanent pressure drop across the valve when fully open.
Engineering Design of the Johnson Controls VFC-060HB-722D
On the Johnson Controls VFC-060HB-722D, the valve body is constructed for direct installation between ANSI Class 125 flanges, with a wafer-style lug or flangeless body depending on configuration, allowing bidirectional flow and dead-end service without a downstream flange when specified. The 416 stainless steel disc is polished and precisely machined to seat concentrically against the reinforced EPDM liner, which also functions as the flange gasket – eliminating separate gasket material and simplifying field installation for contractors working on tight commissioning schedules. The stem is supported by upper and lower bushings to minimize shaft deflection under high differential pressure, a detail that matters directly on 175 psig-rated large-diameter service.
Above the valve on the Johnson Controls VFC-060HB-722D, the VA-9072-02 actuator is factory- or field-mounted via a standard ISO5211-pattern bracket and coupled directly to the valve stem, removing the linkage wear points found on older pneumatic butterfly valve packages. The actuator housing is rated for indoor mechanical-room service and includes a manual override for commissioning and emergency positioning without power. Wiring terminates at a captive screw terminal block inside the actuator enclosure, and an optional thermostat/heater kit is available for the valve when installed in unconditioned plant rooms or outdoor enclosures across Oman’s hot, humid coastal climate, protecting the actuator electronics from condensation-related failure.
Key Features
The Johnson Controls VFC-060HB-722D combines a proven mechanical platform with the reliability engineers expect from a Metasys-compatible BAS ecosystem. Key features of the Johnson Controls VFC-060HB-722D include:
- Two-way, 6-inch (150mm) ANSI Class 125 flanged butterfly valve body engineered for direct in-line installation on hydronic mains.
- 416 stainless steel disc paired with an EPDM liner rated for 175 psig bubble-tight shutoff.
- High flow coefficient (Cv ≈ 1850) suited to large-diameter chilled water, hot water, and condenser water distribution lines.
- VA-9072-02 non-spring-return electric actuator delivering reliable two-position or modulating control from the BAS.
- Direct shaft coupling with no external linkage, reducing mechanical wear points versus legacy pneumatic packages.
- Compact valve and actuator footprint that simplifies retrofit into space-constrained plant rooms.
- Manual override on the actuator for commissioning and fail-safe positioning without control power.
- Optional thermostat/heater kit for actuator protection in humid or unconditioned installations typical of Gulf coastal climates.
Industrial Applications
The VFC-060HB-722D is specified across large commercial and institutional HVAC systems where 6-inch and larger pipe diameters carry the bulk cooling or heating load: central chiller plants where the Johnson Controls VFC-060HB-722D is commonly specified, cooling tower isolation and balancing lines, district cooling energy transfer stations, and primary/secondary hydronic loops in hospitals, hotels, airports, and shopping malls. Its combination of tight shutoff, moderate actuator torque, and Metasys-native control compatibility makes it a standard specification on new-build commercial towers and retrofit chiller plant upgrades alike, where facility teams need dependable isolation and modulating control without introducing a new control protocol into an existing BAS architecture.
With engineering support in Muscat, Seven Star LLC supplies Johnson Controls VFC-060HB-722D and other VF Series valve and actuator assemblies to MEP contractors and district cooling operators throughout Oman, including large chilled water networks in Muscat and the industrial and free-zone developments around Sohar and Salalah. Facility engineers across the GCC increasingly favor system-matched valve and actuator packages from a single trusted source, since it removes compatibility risk between third-party actuators and the valve body, and ensures the warranty remains intact on projects where uptime of the central plant is mission-critical.
Technical Specifications
The table below summarizes the core specifications of the Johnson Controls VFC-060HB-722D valve and actuator assembly, as published in official Johnson Controls documentation for the VFC-060HB-722D model line.
| Parameter | Specification |
|---|---|
| Model | VFC-060HB-722D |
| Series | Johnson Controls VF Series Butterfly Valve |
| Valve Type | Two-way, quarter-turn butterfly valve |
| Nominal Size | 6 in. (150 mm) |
| Flange Rating | ANSI Class 125 |
| Disc Material | 416 stainless steel |
| Seat / Liner Material | EPDM |
| Shutoff Rating | 175 psig (12.1 bar) |
| Flow Coefficient (Cv) | ≈ 1850 |
| Actuator | Johnson Controls VA-9072-02, non-spring-return electric |
| Actuator Power Supply | 120 VAC |
| Control Signal | Two-position / floating |
| Media | Hot water, chilled water, condenser water, 50/50 glycol |
| Optional Accessory | Thermostat/heater kit for humid environments |
Request a Quote for Johnson Controls VFC-060HB-722D Butterfly Valve
Backed by genuine manufacturer documentation, Seven Star LLC invites consulting engineers, MEP contractors, and facility managers to submit a formal RFQ for the VFC-060HB-722D valve and actuator assembly. Spare EPDM seat kits and replacement Johnson Controls VFC-060HB-722D actuators are also available on request. Units and compatible VF Series accessories are supplied on request to project sites across Muscat, Sohar, and Salalah, with lead time confirmed at quotation, and the technical datasheet, dimensional drawings, and Cv selection charts can be provided on request. Contact the Seven Star LLC instrumentation and building automation division for project-specific sizing assistance and to confirm genuine, warrantied supply for your chilled water or hot water distribution project.
Related Products
- Datasheet Johnson Controls VFC-060HB-722D Butterfly Valve Datasheet Download
Johnson Controls butterfly valves in HVAC service
The code belongs to the VF Series, the Johnson Controls butterfly valve family for two-position and modulating control of hot, chilled and condenser water. The series is supplied as two-way and three-way assemblies of valve body and electric or pneumatic actuator, and the product code describes that assembly in fields: valve type, size, close-off rating and actuator code. In VFC-060HB, 060 stands for the 6 inch size. Butterfly valves take over from globe and ball valves once pipe sizes grow, which is why these chilled water valves sit on chiller headers, cooling tower lines and air handling unit branches.Ordering Johnson Controls valves: what we need
Send the complete product code from the valve or actuator label, here VFC-060HB-722D. Add the line size and flange standard, the fluid and temperature, the close-off pressure required, the actuator supply voltage and control signal (on-off, floating or proportional), and the fail position if one is needed. We supply across the GCC and check the code against the manufacturer's documentation.Browse Johnson Controls products by category: Control Valves.
