Brand: Allen-Bradley
Allen-Bradley 1756-OW16I ControlLogix Relay Output Module
Description
Sixteen individually isolated N.O. relay outputs
The Allen-Bradley 1756-OW16I provides sixteen normally open relay contacts, each isolated from the next. With a 5 to 125 V DC and 10 to 240 V AC range, it is the module of choice for switching mixed voltages from one card, driving interposing relays, or interfacing with equipment that needs a dry contact, such as a burner management panel or a third-party starter.
The relay contacts are rated C300/R150 pilot duty. Load capability depends on voltage, from 1 A at 5 to 30 V DC up to 1.5 A at 120 V AC, and it is a smaller current than the contactor ratings an electrician may assume.
Technical specifications
| Parameter | Specification |
|---|---|
| Catalog number | 1756-OW16I (1756-OW16IK conformal coated listed separately) |
| Outputs | 16 N.O., individually isolated |
| Operating voltage range | 5 to 125 V DC; 10 to 240 V AC |
| Load rating | 1 A at 5-30 V DC; 0.5 A at 48 V DC; 0.22 A at 125 V DC; 1.5 A at 120 V AC; 0.75 A at 240 V AC |
| Pilot duty | C300 / R150 |
| Output delay | 10 ms max, off to on and on to off |
| Contact resistance, initial max | 100 mOhm at 6 V, 1 A |
| Switching frequency, max | 1 operation per 3 s (0.3 Hz at rated load) |
| Bounce time, mean | 1.2 ms |
| Expected contact life | 300,000 cycles resistive; 100,000 cycles inductive |
| Off-state leakage / min load | 1.5 mA per point / 10 mA per point |
| Backplane current | 150 mA at 5.1 V DC; 150 mA at 24 V DC (4.4 W) |
| Power dissipation, max | 4.5 W at 60 C (15.35 BTU/hr) |
| Isolation | 250 V continuous basic, output to backplane and output to output |
| Output protection | None on the module; a fused interface module is suggested by the manufacturer |
| Temperature code | T4A |
| Operating temperature | 0 to +60 C |
| Non-operating temperature | -40 to +85 C |
| Vibration / shock | 2 g at 10-500 Hz / 30 g operating, 50 g non-operating |
| Slot width / keying | 1 slot; electronic keying, software configurable |
| Enclosure / wire category | Open-style; wire category 1 |
Relay life and protection
The 300,000 resistive and 100,000 inductive cycle ratings are electrical contact life; the switching frequency limit of one operation per three seconds at rated load means relay outputs are not suited to fast cycling. The outputs are not protected by the module, and the technical data points to a fused interface module (1492 series) to protect them, with approval caveats for other wiring methods.
Selection notes
Choose OW16I when several different voltages or isolated contacts are needed on one card. For fast or silent switching a solid-state module is better. Check that load current at the actual voltage is inside the table above, particularly on DC inductive loads, where the 0.22 A rating at 125 V DC is easy to exceed. Terminal block and series should be confirmed before ordering.
Documents and quotation
The linked Rockwell Automation technical data covers the full 1756 I/O range (file size about 15 MB, hosted by Rockwell Automation). Related PLC hardware sits in the PLC & I/O Cards category. To request a quotation send the catalog number and quantity to Seven Star LLC, an independent supplier in Muscat.
Datasheets & Documents
- Technical data Rockwell Automation 1756 ControlLogix I/O Specifications, publication 1756-TD002U (September 2026) Download
Reviews (0)
About brand
Allen-Bradley is the brand of Rockwell Automation for industrial control: ControlLogix and CompactLogix controllers, I/O systems, PanelView operator terminals, PowerFlex drives, motor control and industrial network equipment. The company began in Milwaukee in 1903, when Lynde Bradley and Dr. Stanton Allen formed the Compression Rheostat Company to make the motor speed controller Bradley had invented in 1901. It took the name Allen-Bradley in 1909 and was bought by Rockwell International in 1985. Since 2001 its owner has been Rockwell Automation, which is still headquartered in Milwaukee, Wisconsin.
Allen-Bradley company profile
| Founded | 1903, Milwaukee, Wisconsin, USA, as the Compression Rheostat Company |
|---|---|
| Founders | Lynde Bradley (inventor of the compression rheostat, 1901) and Dr. Stanton Allen (investor); Harry Bradley joined in 1904 |
| Name | Allen-Bradley Company from 1909 |
| Ownership | Acquired by Rockwell International in 1985 for about USD 1.65 billion; a brand of Rockwell Automation (NYSE: ROK) since 2001 |
| Headquarters | Milwaukee, Wisconsin, USA |
| Product families | Logix programmable automation controllers (ControlLogix, CompactLogix), legacy SLC 500 and MicroLogix PLCs, Micro800 controllers, POINT, FLEX and Compact I/O, PanelView HMIs, PowerFlex AC drives, contactors, motor starters and soft starters, safety components, Stratix Ethernet switches |
Milestones
- 1901: Lynde Bradley invents the compression rheostat to control the speed of electric motors.
- 1903: The Compression Rheostat Company is formed in Milwaukee with an initial investment of USD 1,000.
- 1904: Harry Bradley joins; a crane controller is shown at the St. Louis World's Fair.
- 1909: The company is renamed Allen-Bradley.
- 1985: Rockwell International acquires Allen-Bradley.
- 2001: Rockwell Automation becomes the company's name; the Allen-Bradley brand marks 100 years in 2003.
Reading Allen-Bradley catalogue numbers
The first digits of an Allen-Bradley catalogue number identify the platform, which tells you what is compatible with what. 1756 is ControlLogix (chassis-based, used for large process and plant control), 1769 is CompactLogix 5370 with Compact I/O, 5069 is CompactLogix 5380 with Compact 5000 I/O, 1734 is POINT I/O, 1794 and 5094 are FLEX and FLEX 5000 distributed I/O, 1746 and 1747 belong to the older SLC 500 family, 1766 is MicroLogix 1400 and 2080 is Micro800. For drives, 25B is PowerFlex 525 and 22B is PowerFlex 40; in a code such as 25B-D010N114, "D" means 380–480 V, "010" is the output current rating, and N114 instead of N104 means the drive has an integrated EMC filter. Many plants in the region still run SLC 500 and older MicroLogix systems, which Rockwell has discontinued, so exact spares and migration to CompactLogix are both common requests.
Where Allen-Bradley products are used
In Oman and the GCC, Allen-Bradley controllers and drives run on oil and gas facilities, water treatment and pumping stations, cement, food and beverage and packaging plants, and on machines supplied by American OEMs. ControlLogix is often the platform for plant control systems, while PowerFlex drives are used on pumps, fans and conveyors.
Allen-Bradley products we list
| Family | Examples |
|---|---|
| ControlLogix | 1756-L85E, 1756-EN2T, 1756-EN2TR, 1756-IF16, 1756-IB32, 1756-PA75, 1756-A10 |
| CompactLogix and Micro controllers | 5069-L320ER, 5069-L340ERM, 1769-L33ER, 1769-L16ER, MicroLogix 1400, Micro820, SLC 500 (1746) |
| Distributed I/O | 1734-AENTR, 1734-IB8, 1734-IE2C, 1734-IB8S safety, 1794-AENTR, 5094-AENTR, 5069-IF8 |
| Operator terminals | PanelView Plus 7 10-inch, PanelView Plus 7 15-inch, PanelView 800, PanelView 5310 |
| Drives, motor control and networking | PowerFlex 525, PowerFlex 755, PowerFlex 4, 150-A180NBD SMC, Stratix 2000, 1783-NATR |
Ordering Allen-Bradley products: what we need
Send the full catalogue number and the series letter from the label (for example 1756-EN2T Series D), because firmware and compatibility can change between series. For drives, add the motor power, voltage and filter option. For a discontinued SLC 500 or MicroLogix part, tell us whether you need the exact spare or a migration proposal.
Facts checked against Rockwell Automation's published company history, October 2026.
Browse Allen-Bradley products by category: PLC & I/O Cards, AC Drives.
Related products
Frequently Asked Questions
How many outputs does the 1756-OW16I have?
Sixteen normally open relay contacts, each individually isolated.
What voltages can it switch?
5 to 125 V DC and 10 to 240 V AC.
What is the contact life?
300,000 cycles resistive and 100,000 cycles inductive.
Are the outputs fused?
No. The manufacturer suggests a fused interface module for protection.
How fast can the relays switch?
At most one operation per 3 seconds at rated load.
