Brand: KSB
KSB RPHb Two-Stage BB2 Process Pump to API 610
Description
Two-stage between-bearings pump for high-head refinery duties
The KSB RPHb is a single-suction, two-stage heavy-duty BB2 process pump to API 610 / ISO 13709. BB2 is the API class for a radially split, between-bearings pump, so the rotor sits between two bearings and the casing is split at right angles to the shaft. KSB lists refineries, petrochemical and chemical industries, and onshore and offshore processes as applications.
Compared with OH2 pumps, KSB states that the RPHb achieves better efficiencies and NPSH values, and its diffuser design with impellers in a back-to-back arrangement balances axial thrust.
Technical specifications
| Parameter | Specification |
|---|---|
| Manufacturer | KSB SE and Co. KGaA, Frankenthal, Germany |
| Type | RPHb, single-suction, two-stage, heavy-duty BB2 process pump |
| Standard | API 610 / ISO 13709 |
| Flow rate, 50 Hz | Up to 2100 m3/h (9246 US gpm) |
| Flow rate, 60 Hz | Up to 1900 m3/h (8365 US gpm) |
| Head, 50 Hz | Up to 680 m (2231 ft) |
| Head, 60 Hz | Up to 800 m (2625 ft) |
| Temperature | -80 to +450 C (-112 to 842 F) |
| Pressure | Up to 100 bar (1450 psi) |
| Nominal diameter | 80 to 300 mm (3 to 12 in) |
| Materials | S5, S6, S8, C6, A8, D1, D2 and special materials |
| Bearings | Heavy-duty paired 40 degree angular contact ball bearings; oil ring lubrication with labyrinth seals as standard; hydrodynamic bearings optional |
| Seal | Mechanical seals to API 682, cartridge design; coolable or heatable seal housing |
| Other values | On request |
Design features
The top-top flange arrangement makes the pump easy to monitor and service, and the suction-side casing cover simplifies rotor removal. Casing and impeller wear rings are replaceable, and the modular design system reduces spare parts stock. The shaft is reinforced and optimised for longer service life. Integrated cooling fins and an optional fan impeller cool the bearing brackets without a separate cooling circuit, and a version with hydrodynamic bearings is available for higher energy density.
Selecting an RPHb pump
KSB provides a comprehensive hydraulic selection chart, and the leaflet notes a wide range of variants, numerous flange designs and a large choice of materials. For a quotation provide flow, differential head, NPSH available, fluid, temperature, material class, seal plan and bearing variant required.
Documents and quotation
Check that the pump size and the 50 or 60 Hz data match your duty, and confirm the leaflet edition (03.24) with current documentation. Maximum values apply to the series, not to every size.
The attached KSB leaflet is the manufacturer document for the RPHb and lists the technical data used above. Seven Star LLC, an independent supplier in Muscat, quotes KSB pumps against your duty data. Browse Pumps for related equipment, or compare with the KSB Omega axially split volute casing pump.
Datasheets & Documents
- Brochure KSB RPHb two-stage BB2 process pump leaflet (EN, KSB, 03.24) Download
Reviews (0)
About brand
Pumps and valves have been the whole business of KSB since 1871, and the Frankenthal company's type series names are a fixture on nameplates in water, building services, energy and process plants. Seven Star LLC lists KSB pump families including Etanorm, Movitec, Multitec and Omega, and supplies KSB pumps and spare parts to operators and contractors in Oman and the GCC, matching each request to the manufacturer's documentation.
KSB pump series we list
- Etanorm: horizontal single-stage volute casing pump with ratings and main dimensions to EN 733, back pull-out design, replaceable casing wear rings.
- Movitec: vertical multistage high-pressure pump in ring-section design, with suction and discharge nozzles of the same diameter in line.
- Multitec: multistage ring-section pump for horizontal or vertical mounting, built in materials from cast iron to duplex stainless steel.
Ordering KSB pumps and parts: what we need
For a spare part, send the type series and size, the KSB order number and serial number from the nameplate, and the part number from the sectional drawing. For a new pump, give flow, head, liquid, temperature, suction conditions, material preference, and motor voltage and frequency. Mechanical seal code and impeller diameter matter on replacements, because one pump size is built in many variants.
Browse KSB products by category: Pumps.
Related products
Frequently Asked Questions
What does BB2 mean?
An API 610 between-bearings, radially split casing pump.
How many stages does the RPHb have?
Two stages, with a single-suction first impeller and impellers in back-to-back arrangement.
What is the maximum head?
Up to 680 m at 50 Hz and 800 m at 60 Hz.
Which bearings are standard?
Paired 40 degree angular contact ball bearings with oil ring lubrication; hydrodynamic bearings are optional.
What temperature range is listed?
-80 C to +450 C.
