Brand: Kidde
Kidde NATURA-Micro LHS Cabinet Fire Suppression System
Description
Detection and suppression in one cabinet-level unit
The Kidde NATURA-Micro LHS is a self-contained object and cabinet fire protection unit that combines linear heat detection with IG-100 (nitrogen) gas suppression in one box. It is intended for small enclosures up to 132 cubic feet (3.75 m3), and up to eight units can be connected for a total protected volume of 1,059 cubic feet (30 m3). Because it suppresses a fire directly at the source, an incident in a switchgear, server or control cabinet is stopped in its incipient stage.
Technical specifications
| Parameter | Specification |
|---|---|
| System | NATURA-Micro LHS: linear heat detection bundled with IG-100 gas suppression |
| Model LHS750 | Protected volume (Class C) 44.1 ft3 (1.25 m3); weight 41 lb (18.6 kg) |
| Model LHS1500 | Protected volume (Class C) 88.3 ft3 (2.5 m3); weight 60 lb (27.2 kg) |
| Model LHS2250 | Protected volume (Class C) 132.4 ft3 (3.75 m3); weight 79 lb (35.8 kg) |
| Maximum connection | Up to 8 units, total protected volume 1,059 ft3 (30 m3) |
| Detection cable | Mounting kit with 154 degrees F (68 degrees C) or 219 degrees F (104 degrees C) linear heat detection cable |
| Gas generator | Patented aluminum vessel with squib, booster and filter; cool low-pressure nitrogen at ambient temperature; 10-year manufacturer warranty on the cool gas generator |
| Activation module | Internal power supply and backup; 24/7 monitoring; alarm and fault relays; door switch, manual activation and 2 dry contacts |
| System components | Integrated LHS and suppression system, mounting kit, piping, fittings and one standard nozzle, status relays; use with 1, 2 or 3 cool gas generators |
| Mounting | Cabinet top or nearby wall |
| Approvals as printed | CE |
How the unit works
The activation module monitors the heat-sensing cable and its own power, and reports faults and alarms through relays. When the cable reaches its alarm temperature, the module fires the cool gas generator, which produces nitrogen at ambient temperature. The gas fills the cabinet and suppresses the fire without particulates, which keeps electronics clean. The sell sheet says no special software or commissioning tools are needed, and the unit includes LED indicators.
The manufacturer lists benefits such as risk containment, business continuity, asset protection, reduced collateral damage because no water, corrosion or residue is left, better insurability, and a modular, retrofit-friendly design. Typical candidates are electrical cabinets, control panels and enclosed equipment where a room-level system is not justified.
What to confirm before ordering
Send the internal volume of the cabinet or object, the ventilation openings, the choice of cable temperature rating and the number of generators required. Replacement modules are sold separately. The sheet lists approval as CE only, so confirm whether the project needs any other certification. Installation is straightforward in principle, but the final design must follow the manufacturer’s instructions and local rules, and the exact order codes (for example SSK-NMASP, mentioned in the sheet) must be requested with the quotation.
Documents and quotation
Use the download on this page to open the manufacturer’s sell sheet SSK-NMLHS (2 pages). Seven Star LLC, an independent supplier in Muscat, handles the quotation. Please include the exact designation, quantity and site in your request so the quotation matches your order. Other fire protection items are in Fire Fighting.
Datasheets & Documents
- Brochure Kidde NATURA-Micro LHS sell sheet SSK-NMLHS (2026) Download
Reviews (0)
About brand
Engineered fire suppression hardware, cylinders, valves and the control heads that release them, is the side of Kidde that industrial sites deal with. The name goes back to 1917. Seven Star LLC lists Kidde clean agent cylinders, control heads and pilot cylinders, and supplies Kidde fire systems parts to operators and fire contractors in Oman as an independent supplier. Household smoke alarms and aircraft systems sold under the same name are outside our scope.
Kidde fire suppression parts listed here
The listed items are release-train components: the WK-890181-000 electric control head, a 24 V DC unit used on Kidde FM-200 systems, an FM-200 (HFC-227ea) clean agent cylinder in the 200 lb size, and the K62462 pilot gas cylinder. Kidde also builds high-pressure CO2 systems with their own control heads and nitrogen pilot cylinders. Typical sites in the GCC are turbine enclosures, switchgear and control rooms, data halls and marine machinery spaces.
Ordering Kidde parts: what we need
Kidde components are ordered by part number, so send it exactly as printed on the label or in the system drawings. For an agent cylinder we also need the fill weight, valve type and the transport documents required. Send the nameplate photo and the system design reference whenever possible.
Browse Kidde products by category: Fire Fighting.
Related products
Frequently Asked Questions
What volume can one NATURA-Micro LHS protect?
Up to 132.4 cubic feet or 3.75 m3 for the LHS2250. Up to eight units can be connected for 1,059 cubic feet or 30 m3.
Which gas does it use?
IG-100, which is pure nitrogen, generated by a cool gas generator at ambient temperature.
How does the unit detect a fire?
With a linear heat detection cable, supplied with a mounting kit in 154 degrees F (68 degrees C) or 219 degrees F (104 degrees C).
Does it need special software?
The sell sheet states that no special software or commissioning tools are needed.
What outputs does it provide?
Alarm and fault relays, with a door switch input, manual activation and two dry contacts on the activation module.
