PCB Piezotronics EX600B13 Very High Temperature ICP Accelerometer
Overview
The PCB Piezotronics EX600B13 is a very high temperature industrial ICP® accelerometer from the IMI Sensors range of PCB Piezotronics. It is designed for machine surfaces that are far too hot for conventional vibration sensors: the accelerometer head is rated from -54 to +482 °C (-65 to +900 °F), while the in-line charge amplifier that produces the ICP® output is rated from -51 to +121 °C. Sensitivity is 100 mV/g with a ±50 g peak range, so the signal can be read by the same data collectors and monitoring systems that handle standard 100 mV/g sensors.
Seven Star LLC supplies the PCB Piezotronics EX600B13 to power generation, refining and petrochemical customers in Oman and the GCC who must monitor steam turbines, gas turbine casings, hot gas fans and other high-temperature equipment. Our Muscat team provides engineering support, including guidance on routing the hardline cable and placing the charge amplifier in a cooler zone.
Measurement Principle
In the PCB Piezotronics EX600B13 the sensing element is UHT-12™, a piezoelectric material used by PCB for high-temperature service, arranged in shear geometry inside an Inconel housing. Vibration of the mounting surface stresses the element and produces a charge proportional to acceleration. Because ordinary IEPE microelectronics cannot survive at several hundred degrees, the head contains no electronics; instead, the charge travels along an integral hardline cable to a separate charge amplifier which converts it into a standard low-impedance ICP® voltage signal.
This split design is the general approach used for high-temperature vibration measurement. The sensor head can sit directly on a hot casing while the electronics are kept within their own temperature limits. The amplifier is powered with 2.2 to 20 mA constant current from a 22 to 28 VDC source, and the output bias is 12 to 16 VDC, values that should be checked against the input specifications of the receiving monitor.
Engineering Design of the PCB Piezotronics EX600B13
The accelerometer head is a low-profile Inconel body measuring 1.5 in diameter by 0.75 in high (38.1 mm x 19.1 mm), fastened through three mounting holes using the three Model 081A99 cap screws that are supplied. The side-exit integral hardline cable is 10 ft (3 m) long and terminates at a 2-pin MIL-C-5015 connection, and the total weight with cable is 10.5 oz (300 g). Housing and sealing are welded hermetic, which protects the element from moisture and contaminants at elevated temperature.
The datasheet also gives a base strain sensitivity of no more than 0.006 g/µε and electrical isolation above 108 ohm. The EX prefix of the model denotes the hazardous-area version of this sensor family; the specific certification is described in the PCB declaration of conformance and instructions for use, which should be reviewed against the area classification of each installation.
In general, the hardline cable of a high-temperature sensor should be routed along the casing with gentle bends, clamped at intervals so it cannot vibrate, and kept clear of sharp edges and insulation cladding joints. The charge amplifier of the PCB Piezotronics EX600B13 should be mounted where ambient temperature stays within its rating, for example on a bracket outside the turbine enclosure or behind a heat shield, and connected to the monitoring system with standard two-wire cable. Recording the sensor serial numbers, cable routes and amplifier locations during installation also makes later maintenance and calibration checks much simpler.
Key Features
Key characteristics of the PCB Piezotronics EX600B13 are:
- Accelerometer head rated for continuous use from -54 to +482 °C.
- Sensitivity of 100 mV/g (±5%) and a measurement range of ±50 g peak.
- Flat response within ±5% from 4.7 to 3,500 Hz and within ±10% from 3.4 to 5,000 Hz.
- Resonant frequency of 20 kHz and broadband resolution of 450 µg.
- Shear-mode UHT-12™ element in a welded hermetic Inconel housing.
- Integral 3 m hardline cable with in-line charge amplifier providing a standard ICP® output.
- Three-hole flange mounting with supplied cap screws for secure attachment to hot casings.
- Shipped with an NIST-traceable calibration from 10 Hz to the upper 5% frequency.
Industrial Applications
Applications for the PCB Piezotronics EX600B13 include steam turbine bearing pedestals and casings, gas turbine combustion and exhaust sections, hot induced-draft fans, superheated steam valves, kilns and reactors. In combined cycle power stations and refineries around Sohar, Duqm and Salalah, many machines run at surface temperatures well above the +121 °C limit of standard industrial accelerometers, and the PCB Piezotronics EX600B13 allows vibration to be measured at the source instead of at a cooler spot that reflects the machine condition less accurately.
Seven Star LLC supplies the PCB Piezotronics EX600B13 and can advise on complementary components. For proximity probe based shaft vibration monitoring on turbines, see the Bently Nevada 3300 XL 8 mm proximity transducer system; for monitoring racks on aeroderivative gas turbines, see the Bently Nevada 3500/44M aeroderivative GT vibration monitor; and for charge-output signal conditioning in other protection systems, the Vibro-Meter IQS900 signal conditioner is also listed.
Technical Specifications
Values for the PCB Piezotronics EX600B13 below are from the PCB Piezotronics datasheet, revision E:
| Parameter | Specification |
|---|---|
| Model | EX600B13 |
| Type | Very high temperature industrial ICP® accelerometer with in-line charge amplifier |
| Sensitivity (±5%) | 100.0 mV/g (10.2 mV/(m/s²)) |
| Measurement range (peak) | ±50 g (±490 m/s²) |
| Frequency range (±5%) | 4.7 to 3,500 Hz |
| Frequency range (±10%) | 3.4 to 5,000 Hz |
| Resonant frequency | 20 kHz |
| Broadband resolution (1 to 10,000 Hz) | 450 µg |
| Non-linearity | ±1% |
| Transverse sensitivity | below 5% |
| Overload limit (shock) | 1,000 g pk |
| Temperature range (accelerometer) | -54 to +482 °C |
| Temperature range (charge amplifier) | -51 to +121 °C |
| Base strain sensitivity | ≤0.006 g/µε |
| Excitation voltage / current | 22 to 28 VDC / 2.2 to 20 mA |
| Output impedance | below 1,000 ohm |
| Output bias voltage | 12 to 16 VDC |
| Settling time | ≤1.0 s |
| Sensing element / geometry | UHT-12™ / shear |
| Housing / sealing | Inconel / welded hermetic |
| Size (diameter x height) | 38.1 mm x 19.1 mm |
| Weight (with cable) | 300 g |
| Mounting | Three through holes, Model 081A99 cap screws supplied |
| Cable | Integral hardline cable, 3 m, side exit |
| Connector | 2-pin MIL-C-5015 |
How to Order
Send Seven Star LLC your request for the PCB Piezotronics EX600B13 with the number of measurement points, the surface temperatures involved and the monitoring system it will connect to. The PCB Piezotronics EX600B13 datasheet is available for download on this page. Our Muscat instrumentation specialists will confirm availability and lead time, review hazardous area documentation with you and support installation across Oman and the GCC.
- Datasheet PCB Piezotronics EX600B13 Datasheet (Rev. E) Download
