Sungrow SG3.0RS 3 kW Single-Phase String Inverter

A 3 kW single-phase string inverter that one person can mount by hand

The Sungrow SG3.0RS is a 3000 W single-phase string inverter with two independent MPPT inputs, part of the SG3.0/3.6/4.0RS series on one datasheet. At 10 kg and 410 x 270 x 150 mm it is light enough for hand installation without lifting machinery, and it is suitable for 50 Hz and 60 Hz grids.

It offers a wide MPPT range from 40 V to 560 V, startup at 50 V, compatibility with high-power and bifacial modules, built-in smart PID Zero function, integrated AFCI, Type II DC and AC SPD, C5 corrosion protection, and one-click access to iSolarCloud monitoring.

SG3.0RS features

• 2 MPPTs with one string each by default; 16 A per input
• 97.9 percent maximum efficiency; 97.0 percent European efficiency
• Lower startup voltage and wide MPPT range, 40 V to 560 V
• Integrated AFCI; built-in Type II DC and AC SPD; smart PID Zero function
• C5 corrosion protection rating, IP65, natural cooling with no fan
• Plug-and-play AC connector and MC4 DC connectors; online IV curve scan and diagnosis
• Ethernet, WLAN, RS485 and DI (ripple control and DRM) communication

SG3.0RS technical specifications

Rating comparison (shared datasheet)

Common data

SG3.0RS, SG3.6RS or SG4.0RS?

The three models have the same enclosure and electronics, differing in AC power (3000, 3680 or 4000 W) and in recommended array size (4.5, 5.4 or 6 kWp). Choose the rating from the roof area, utility export limit and the 220/230/240 V single-phase supply. The 5 kW and 6 kW models in the SG5.0/6.0RS series have a separate datasheet; we also quote the SG5.0RS. If you plan to add module-level optimizers, the datasheet asks you to consult Sungrow before ordering.

Installation and operation notes

The 10 kg unit mounts on a wall bracket and does not need lifting machinery. Natural cooling means no fan noise or filters, but the enclosure still needs shaded, ventilated wall space within the -25 C to 60 C range. DC uses MC4 connectors up to 6 mm2 and AC uses a plug-and-play connector up to 6 mm2. The ripple control and DRM interface (DI) is used where the grid operator requires remote power limitation.

Where the SG3.0RS is used

It is a residential and small-commercial inverter for villas, small shops, farms and site cabins where a single-phase supply is used. The datasheet states the unit is suited to Asia, Africa, South America, Australia and Europe grids, and its 220 to 240 V single-phase rating matches typical 230 V single-phase supplies; check local utility rules for registered inverter models before purchase.

Selection and use notes

Design the string layout from the module data so that the voltage and current stay inside the inverter window over the temperature range at the site, mount the unit with the clear space the manual requires for cooling and check the AC cable, the protection devices and the local grid connection rules before ordering. Keep the commissioning record for the warranty file.

Information needed for a quotation

Send the full model code, the quantity, the delivery location in Oman or the GCC, the intended use and any accessories needed, so that the complete package can be quoted together.

Documents and supply information

The manufacturer data sheet is attached to this page and should be read together with the project specification and the site risk assessment before a purchase is confirmed. Ratings, standards and dimensions are quoted as printed on that sheet. Lead time, stock position and certificates available with the shipment are confirmed in the quotation, and we supply to Oman and the wider GCC region for industrial, utility and building services projects.

Related Sungrow items

Related items include the SG5.0RS and SG6.0RS single-phase inverters, the three-phase SG10RT-P2, and the AC22E-01 EV charger, which Sungrow documents as compatible with its hybrid solutions.

Frequently asked questions

What is the SG3.0RS output?

3000 W single phase at 220, 230 or 240 V, 50 or 60 Hz.

How heavy is it?

10 kg, suitable for hand installation without lifting machinery.

How many MPPTs?

Two independent MPPT inputs, each up to 16 A.

Is it cooled by a fan?

No. Cooling is natural.

Is Seven Star LLC a distributor of Sungrow?

No. We are an independent supplier based in Muscat, and we source genuine Sungrow products for customers in Oman and the GCC when requested.

Documents and quotation

Manufacturer document: the SG3.0/3.6/4.0RS datasheet (Version 12), hosted on this page. Compare it with the instruction manual before you confirm the exact style or order code. Seven Star LLC supplies Sungrow items from Muscat to buyers in Oman and the wider GCC; send the model, option code and quantity through the quotation form for availability. Pricing is on request, and every rating or approval should be re-checked against the current maker documents. More: Solar Power and the Sungrow brand page.
