Mitropower PM13TA1-3 Diesel Generator

Overview:

The Mitropower PM13TA1-3 is an industrial-grade diesel generator engineered to provide a dependable source of electrical power during critical grid outages. Delivering a maximum output of 12 kVA at 400V (3-phase) and 10 kVA at 230V (1-phase), this unit is designed to bridge the gap between heavy-duty industrial power demands and the need for clean, stable voltage. In the fast-paced industrial and commercial sectors of Oman and the broader Middle East, unexpected power failures can lead to severe data loss and production halts. Seven Star LLC supplies the PM13TA1-3 as a highly versatile backup power asset for facilities requiring uninterrupted electricity. Its compact, enclosed design makes it an ideal solution for deployment in diverse locations, from remote construction sites to urban telecommunication hubs.

Operational Logic and Sinewave Alternator

The operational excellence of the Mitropower PM13TA1-3 is rooted in its advanced electrical generation logic. Unlike conventional generators that produce fluctuating power, this model is equipped with a high-quality sinewave alternator combined with an Automatic Voltage Regulator (AVR). This combination ensures that the electrical output precisely mimics the clean sine wave provided by the primary utility grid. This clean power is absolutely essential for operating sensitive microprocessors, PLCs, IT server racks, and medical diagnostic machinery without the risk of harmonic distortion or voltage spikes. The system continuously monitors the load demands and instantaneously adjusts the excitation current, maintaining a stable voltage profile even when heavy inductive loads, such as industrial motors, are initiated.

Engineering Design and Water-Cooled Engine

Mechanical durability defines the engineering design of the Mitropower PM13TA1-3. At its core lies the formidable 2V80 engine—a V-twin, 4-stroke diesel powerplant with a 749 cc displacement. Crucially, this engine utilizes a water-cooling system, which is significantly more effective at dissipating heat than standard air-cooled designs. This ensures the generator can run continuously at 3000 rpm without thermal degradation, a critical factor in the high ambient temperatures of the GCC region. The entire generating set is housed within an acoustic canopy that reduces the operational noise level to a mere 69 dB at 7 meters, making it suitable for noise-sensitive environments. Furthermore, the unit features a heavy-duty wheeled chassis, allowing site engineers to easily mobilize the 320 kg unit across factory floors.

Key Features and Technical Advantages

The Mitropower PM13TA1-3 offers a suite of strategic features designed for B2B industrial deployment. It integrates a 25-liter fuel tank, which, combined with the engine’s high fuel efficiency (consuming only 2.4 liters per hour at 75% load), allows for extended continuous runtime during prolonged outages. The unit features a comprehensive digital control panel that provides operators with real-time diagnostics, including voltage, frequency, and running hours. For automated infrastructure, the generator is compatible with an Automatic Transfer Switch (ATS). When integrated with an ATS, the PM13TA1-3 will automatically detect a grid failure, start the engine, and transfer the load without requiring human intervention. Additionally, integrated fail-safes, such as a low-oil pressure alarm and automatic shutdown, protect the engine from catastrophic damage.

Industrial Applications across the Middle East

Seven Star LLC supplies the Mitropower PM13TA1-3 for various critical applications where power continuity is non-negotiable:

• Telecommunications Infrastructure: Providing clean, stable backup power for remote cellular towers and data routing stations in Oman.

• Medical and Healthcare Facilities: Operating sensitive diagnostic equipment and emergency lighting in mobile clinics or small medical centers.

• Automated Manufacturing: Protecting logic controllers (PLCs) and robotic assembly lines from voltage sags and sudden grid failures.

• Construction and Civil Engineering: Powering heavy-duty power tools, site lighting, and field offices in remote locations lacking grid access.

• Commercial and Retail Operations: Ensuring continuous operation of security systems, refrigeration units, and server networks during blackouts.

Technical Specifications Table

Call To Action

Seven Star LLC is a trusted supplier of industrial emergency power solutions across Oman and the GCC. For a formal B2B quotation, ATS integration consulting, or to request the technical datasheet for the Mitropower PM13TA1-3 Diesel Generator, contact our engineering sales department today.
