GESTRA NRR 2-60 Level Controller, CAN Bus, 24 V DC
Description
A CAN bus level controller for steam boilers, hot-water plants and feedwater tanks
The GESTRA NRR 2-60 is a level controller that works with NRG 26-60 or NRG 26-61 capacitance level electrodes as a level control system and limit switch in steam boilers, hot water installations, and condensate and feedwater tanks. It is a three-position stepping controller: it cyclically reads data telegrams from the level electrode over a CAN bus (ISO 11898, CANopen protocol), compares the actual value with the setpoint, forms a corrective signal for the feedwater valve, and switches MIN and MAX alarm contacts when defined switchpoints are reached.
The controller can also be used with a URW 60 universal converter, which turns the 4-20 mA signal of an external level electrode into CAN bus signals. Configuration, operation and diagnostics run through the URB 60 visual display and operating unit.
Technical specifications
| Parameter | Specification |
|---|---|
| Function | Three-position stepping controller with proportional plus integral (PI) action for an electrically operated control valve; MIN/MAX water level alarm |
| Supply voltage | 24 V DC +/-20 % |
| Power consumption; current | Max. 5 W; max. 0.3 A; external fuse M0.5A |
| Bus interface | CAN bus to ISO 11898, CANopen, insulated; 4-pole code switch sets controller group and baud rate |
| Analogue inputs | 1 x 0-1000 ohm potentiometer (valve position); IN 2, 4-20 mA feedwater flow (optional); IN 3, 4-20 mA steam flow (optional) |
| MIN/MAX outputs | 2 volt-free changeover relays, AgNi0.15, AgSnO2; 8 A at 250 V AC / 30 V DC, cos phi = 1; off-delay 3 s and on-delay 0 s (defaults) |
| Valve OPEN/CLOSED outputs | 2 volt-free changeover relays; 8 A at 250 V AC / 30 V DC, cos phi = 1 |
| Analogue output | 1 x actual value 4-20 mA, max. load 500 ohm |
| Indication | 1 multicolour LED: orange power-up, green running, red malfunction |
| Protection class; IP rating | II double insulated; terminal box IP 40, terminal strip IP 20; pollution degree 2 for a control cabinet rated IP 54 |
| Ambient conditions | Service -10 to 55 C (0 to 55 C at power-on); storage -20 to 70 C; humidity max. 95 % non-condensing |
| Housing; mounting | Glass-fibre reinforced polycarbonate; two removable 15-pole terminal strips; clip for TH 35 rail (EN 60715) |
| Weight; cable | Approx. 0.5 kg; shielded twisted-pair control cable, min. 0.5 mm2, max. 100 m |
| Order codes | NRR 2-60 three-position with actual value: 3246041; with 3 components and actual value: 3246030 |
Three-component control adds feedwater and steam flow inputs to the level signal, which helps on boilers with fast load swings. If two or more devices share a CAN bus, a 120 ohm terminating resistor must be fitted at the first and last devices; the NRR 2-60 has an internal terminating resistor that is activated with a jumper.
Selecting and wiring the controller
Match the controller to the electrode: NRG 26-60 or NRG 26-61 on the CAN bus, or an external 4-20 mA level electrode through the URW 60 converter. Order the URB 60 if you want a visual display and operating unit for configuration and diagnostics. Run bus lines in shielded twisted-pair cable such as UNITRONIC BUS CAN, connect shields along the whole line to the central earthing point, and protect the switching contacts with a T2.5A fuse. Inductive loads need an RC suppressor.
For the electrode side of a boiler level system see the GESTRA NRGT 26-2 capacitive level transmitter and other items under level instrumentation.
Documents and quotation
The attached GESTRA data sheet 819921 lists inputs, outputs, ordering codes and wiring. Send the boiler type, electrode type, valve actuator and whether three-component control is needed for a quotation, and confirm the controller variant and approvals required for your boiler code before ordering.
