Brand: Finder
Finder 22.32.0.230.1340 25 A 2 NO Modular Contactor
Description
A 17.5 mm modular contactor with a manual Auto-On-Off selector
The Finder 22.32.0.230.1340 is a two-pole, 25 A modular contactor for 35 mm rail in a body only 17.5 mm wide. This variant has two normally open silver-nickel contacts, a 230 V AC/DC coil and a front selector with ON, AUTO and OFF positions plus a mechanical indicator and an LED. In the ordering code, the digits after the coil voltage mean AgNi contacts (1), all contacts normally open (3), the selector version (4) and a standard version (0).
Finder lists continuous duty for both coil and contacts, a silent AC/DC coil with varistor protection, a contact gap of at least 3 mm with double break on the NO contacts, and reinforced insulation between coil and contacts. The contactor is compliant with EN 61095:2009, and the series materials meet the fire and smoke characteristics of EN 45545-2 for railway applications.
Technical specifications
| Parameter | Specification |
|---|---|
| Manufacturer / series | Finder, 22 series (modular contactors) |
| Ordering code | 22.32.0.230.1340 |
| Contact configuration | 2 NO, 3 mm contact gap, double break |
| Contact material | AgNi |
| Rated current / maximum peak current | 25 A / 80 A |
| Rated voltage | 250 / 440 V AC |
| Rated load AC1 / AC-7a (per pole, 250 V) | 6250 VA |
| Rated current AC3 / AC-7b | 10 A |
| Rated load AC15 (per pole, 230 V) | 1800 VA |
| Single-phase motor rating (230 V AC) | 1 kW |
| Rated current AC-5a (per pole, 250 V) | 15 A |
| Lamp rating at 230 V | 800 W incandescent/halogen; 100 W LED; 100 W CFL; 300 W fluorescent with electronic ballast |
| Breaking capacity DC1 at 24 / 110 / 220 V | 25 / 5 / 1 A |
| Minimum switching load | 1000 mW (10 V / 10 mA) |
| Coil voltage of this version | 230 V AC/DC (series range 12, 24, 48, 60, 120, 230 V) |
| Rated coil power AC/DC | 2 VA / 2.2 W |
| Operating range | 0.8 to 1.1 UN |
| Holding voltage / must drop-out voltage | 0.4 UN / 0.1 UN |
| Mechanical life | 2 million cycles |
| Electrical life at rated load AC-7a | 70 000 cycles |
| Operate / release time | 30 ms / 20 ms |
| Insulation, coil to contacts (1.2/50 us) | 6 kV |
| Ambient temperature range | -25 to +50 C |
| Protection category | IP 20 |
| Standard | EN 61095:2009 |
| Width | 17.5 mm; box clamp terminals; 35 mm rail (EN 60715) |
The 22 series at a glance
| Type | Rating |
|---|---|
| 22.32 | 25 A, 2 pole (this page) |
| 22.34 | 25 A, 4 pole |
| 22.44 | 40 A, 4 pole |
| 22.64 | 63 A, 4 pole |
| 22.72 | 32 A, 2 pole |
| 22.74 | 32 A, 4 pole |
Using the selector and choosing contacts
In the ON position the contacts are latched in the operated state regardless of the coil; in AUTO they follow the coil; in OFF they stay released even when the coil is energised. This lets an electrician force a lighting, heating or pump circuit on or off from the front of the board without touching the control wiring. AgNi contacts, as in this version, suit resistive and slightly inductive loads and motors, while the AgSnO2 variants of the series are meant for lamp loads and high-inrush loads. An auxiliary contact module can be clipped on, except on the two-NC versions.
Documents and quotation
The attached Finder datasheet covers the 22 series with ordering information, derating curves, outline drawings and accessories. For a quotation on 22.32.0.230.1340, send the quantity, the load type and current, the coil voltage and the cabinet temperature. Always check the coil voltage letter code on the label against the order code before wiring, because a 230 V coil on a 24 V control line will not operate. Related items are listed under Contactors & Overload Relays.
Datasheets & Documents
- Datasheet Finder 22 series datasheet (EN) Download
Reviews (0)
About brand
Finder is an Italian manufacturer of relays, timers, power supplies and other electromechanical and electronic devices, founded in 1954 and headquartered in Almese, in the Susa Valley of Piedmont. Seven Star LLC, an independent supplier in Muscat, lists Finder modular contactors, safety relays and DIN rail power supplies for control panels, building services and machine automation.
Relay, contactor and power supply families
The range runs from step relays and modular contactors to safety relays with forcibly guided contacts and switch mode power supplies for 35 mm rail. Each series has a datasheet with ordering codes, coil data, contact ratings, derating curves and approvals, so a part can be specified or replaced by its full type code rather than by series name alone.
Ordering Finder products: what we need
Quote the complete ordering code, including coil voltage and contact variant, together with the quantity, the supply voltage and frequency of the installation and any approvals the project requires. With that information the matching Finder version can be confirmed against the datasheet before a quotation is issued.
Related products
Frequently Asked Questions
What does the 22.32.0.230.1340 switch?
It has two normally open AgNi contacts rated 25 A at 250/440 V AC.
What coil does this version use?
A 230 V AC/DC coil, consuming about 2 VA or 2.2 W.
What does the selector do?
ON latches the contacts closed, AUTO follows the coil and OFF keeps them open; a mechanical indicator and LED show the state.
How wide is the contactor?
It is 17.5 mm wide and mounts on a 35 mm rail.
Can an auxiliary contact be added?
Yes, an auxiliary module clips on, except on the two-NC versions of the 22.32.
