Axiomtek eBOX630A Fanless Embedded System

Name: Axiomtek eBOX630A Fanless Embedded System
Brand: Axiomtek
SKU: eBOX630A

Description

A compact 11th Gen Core controller with serial ports for plant networks

The Axiomtek eBOX630A is a fanless embedded computer using the 11th Generation Intel Core (Tiger Lake UP3) quad-core processor, offered in i7, i5 and i3 versions. Its character is the combination of three 2.5 GbE ports and four serial ports in a 250 x 170 x 60 mm case, which suits gateways, data loggers and machine controllers that talk to both Ethernet and legacy RS-232 or RS-485 equipment.

Triple display is possible with two HDMI outputs and one DisplayPort++. Power comes in through a Phoenix connector accepting 9 to 48 VDC, wider than the usual 9 to 36 V, which helps on 48 V telecom-style supplies. Two swappable drive bays on the front allow storage to be changed without opening the chassis.

Technical specifications

Parameter	Specification
Model / ordering codes	eBOX630A-11U-i7 (E360630A00), eBOX630A-11U-i5 (E360630A01), eBOX630A-11U-i3 (E360630A02)
CPU	Intel Core i7-1185G7E / i5-1145G7E / i3-1115G4E, up to 15 W TDP
Memory	2 x DDR4-3200 SO-DIMM, up to 64 GB
Front I/O	2 x USB 2.0, 8-CH TTL DIO (4 in / 4 out), audio, ATX switch, remote switch, reset, AT/ATX quick switch, SIM slot
Rear I/O	2 x RS-232/422/485, 2 x RS-232, 4 x USB 3.2 Gen 1, 2 x HDMI 1.4b, 1 x DisplayPort++ 1.2a, 3 x 2.5GbE (2 x I226-IT, 1 x I226-LM)
Storage	2 x 2.5 inch swappable SSD/HDD bays (9.5 mm, RAID 0/1), M.2 Key M 2280 NVMe
Expansion	Full-size Mini PCIe, M.2 Key E 2230 (Wi-Fi), TPM 2.0
Power input	9 to 48 VDC
Operating temperature	-40 to +60 C with 0.5 m/s airflow (Ethernet version, 15 W, wide-temperature DRAM and SSD); -40 to +50 C with 0.7 m/s airflow (optional PoE version)
Humidity	10 to 95 percent, non-condensing
Shock / vibration	IEC 60068-2-27 50 G; IEC 60068-2-64 3 Grms; package vibration MIL-STD-810G 514.6C-II
Dimensions / weight	250 x 170 x 60 mm; 2.4 kg net
Certifications	CE, FCC Class A, UKCA; IP40

Which eBOX630A version to pick

The three order codes differ only in processor. The i7 and i5 versions carry Intel Iris Xe graphics according to the feature list, which matters when three displays are driven. The i3 version is the lower-cost choice for headless gateways where graphics are irrelevant. Memory, drives and the Wi-Fi or LTE module are ordered separately.

Optional accessories in the datasheet include wall-mount and DIN-rail kits, a 24 V 120 W adapter, and a PoE module kit that needs the 24 V 230 W adapter. Choosing PoE lowers the maximum operating temperature to +50 C.

Points to check before requesting a quote

Confirm the processor level, the number of serial ports required in RS-422 or RS-485 mode (COM1 and COM2 only), whether PoE is needed, and the airflow available in the cabinet, because the temperature rating assumes airflow. Note that the printed dimension line in the datasheet reads 250 x 17 x 60 mm; the drawing on the last page shows a 170 mm depth, which is the value used here.

How the Axiomtek eBOX630A works

The computer runs an operating system on an 11th Generation Intel Core processor. It has no fan, and the case spreads the heat to the air. The serial ports link old equipment, and the three Ethernet ports link the plant networks. The unit can drive up to three displays.

Where the eBOX630A is used

Industrial gateways
Data loggers
Machine controllers
Edge computing in plants
Systems with RS-232 or RS-485 equipment

Selection checklist for the eBOX630A

Processor version i7, i5 or i3
Memory size
Storage in the drive bays
Serial port types
Network ports
Display outputs
Wi-Fi or LTE module
Power source

Installation, commissioning and maintenance notes for the eBOX630A

Mount the unit with airflow around the case. Fit the memory and the drives. Connect the supply to the Phoenix connector. Plug in the network, serial and display cables. Install the operating system and test the ports.

Requesting a quotation for the Axiomtek eBOX630A

Please send the processor version, the memory, the storage and the modules needed. Seven Star LLC serves industrial customers in Oman and the GCC and replies with a quotation based on the information provided.

eBOX630A processors

The versions use the Core i7-1185G7E, i5-1145G7E or i3-1115G4E.

eBOX630A memory

It takes two DDR4-3200 SO-DIMM modules, up to 64 GB.

eBOX630A network ports

It has three 2.5GbE ports.

eBOX630A serial ports

Two ports are RS-232/422/485 and two are RS-232.

eBOX630A USB ports

It has four USB 3.2 Gen 1 ports at the rear and two USB 2.0 ports at the front.

eBOX630A display outputs

The outputs are two HDMI 1.4b and one DisplayPort++ 1.2a.

eBOX630A digital I/O

The front panel has 8-channel TTL digital I/O with four inputs and four outputs.

eBOX630A storage

It has two swappable 2.5 inch bays and an M.2 NVMe slot.

eBOX630A power input

The power input is 9 to 48 VDC.

eBOX630A operating temperature

The range is minus 40 to plus 60 degrees C with airflow.

eBOX630A dimensions

The case measures 250 x 170 x 60 mm and weighs 2.4 kg.

Computer records for the eBOX630A

Record the order code, the serial number and the date of each backup.

Choosing the right eBOX630A version

The three versions differ only in the processor, so choose from the graphics and speed needed.

Documents and quotation

The manufacturer datasheet for the eBOX630A is attached to this page as a PDF (document type: datasheet) so the figures above can be checked against the source. For a quotation, send the full model or ordering code, quantity, any options such as modules or accessories, and the delivery location through the RFQ form. Seven Star LLC is an independent supplier in Muscat; availability and lead time are confirmed per request. More Axiomtek equipment is listed under this category, and the Axiomtek brand page shows the rest of the range on this site.
