Axiomtek eBOX100B Fanless Embedded System

Name: Axiomtek eBOX100B Fanless Embedded System
Brand: Axiomtek
SKU: eBOX100B

A Twin Lake N150 box built around serial ports and digital I/O

The Axiomtek eBOX100B uses the Intel N150 quad-core processor (Twin Lake) with 8 GB of LPDDR5 soldered on board, and the same 155 x 110 x 60 mm aluminium case as the eBOX100A. What sets it apart is the I/O mix: four RS-232/422/485 ports on the top, an 8-channel TTL digital I/O connector, two 2.5GbE ports, two HDMI outputs and six USB ports.

That profile fits machine-side data collection, small HMI back ends and protocol gateways. The operating range reaches -40 to +70 C with wide-temperature memory and storage, and the power input of 9 to 36 VDC includes ignition control with intelligent USB power switching.

Technical specifications

Parameter	Specification
Ordering code	eBOX100B-N150-2E (P/N E36K100B00)
CPU	Intel Processor N150 (Twin Lake), up to 3.6 GHz, 6 W
Memory	8 GB LPDDR5 onboard (16 GB by project)
Network	2 x 2.5GbE (Intel I226-V)
USB / display	2 x USB 3.2 Gen 2, 4 x USB 2.0, 2 x HDMI (lockable)
Serial / DIO	4 x RS-232/422/485 with auto flow control; 1 x 8-CH TTL digital I/O
Storage	1 x M.2 Key M 2280 NVMe (PCIe x4 Gen 3), 1 x 2.5 inch SATA HDD/SSD up to 15 mm
Expansion	Full-size Mini PCIe; M.2 Key E 2230 (Wi-Fi); internal SIM slot; TPM 2.0
Power input	9 to 36 VDC with ignition; inrush 1.5 to 13 A
Operating temperature	-40 to +70 C with wide-temperature DRAM and SSD
Shock / vibration	IEC 60068-2-27 50 G and MIL-STD-810G; IEC 60068-2-64 3 Grms
Dimensions / weight	155 x 110 x 60 mm; 1.1 kg net
Certifications	CE, FCC Class A, UKCA; IP40

Where the eBOX100B differs from its sibling

Compared with the eBOX100A, the B model gives up the DisplayPort and the four-port LAN option in exchange for four serial ports, an 8-channel DIO connector and a second HDMI output. Memory is soldered, so the capacity is fixed when the unit is built; the 16 GB variant is a project item. Storage is flexible, with both an NVMe socket and a 2.5 inch bay.

Checks before ordering

Confirm which serial protocol each of the four ports must use, the DIO wiring (the connector is an 8-channel TTL type, so isolation must be added externally if required), the mounting kit, and the 24 V 60 W adapter if wall power is the source. Verify the operating system against the datasheet list of Windows 10 (21H2), Windows 11 IoT and Linux.

How the Axiomtek eBOX100B works

The eBOX100B is a small industrial computer without a fan. Its Intel N150 processor has four cores and runs at up to 3.6 GHz, with 8 GB of LPDDR5 memory soldered on the board. All heat flows through the aluminium case, so there is no fan to wear out or to draw in dust. The box connects to machines through four serial ports that can be set to RS-232, RS-422 or RS-485 with automatic flow control, and through an 8-channel TTL digital I/O connector. It talks to the network through two 2.5GbE ports and shows its screen through two HDMI outputs.

Where the eBOX100B is used

Machine-side data collection.
Back ends for small HMI screens.
Protocol gateways between serial devices and Ethernet.
Edge computing in cabinets and on vehicles, with the wide power input.
Small control and monitoring systems with serial equipment.

Selection checklist for the eBOX100B

Ordering code eBOX100B-N150-2E.
Serial protocol needed on each of the four ports.
Digital I/O wiring, with external isolation if required.
Memory of 8 GB, fixed, or 16 GB by project.
Storage: M.2 NVMe, or a 2.5 inch SATA drive up to 15 mm.
Expansion with a Mini PCIe slot, an M.2 Key E slot for Wi-Fi and an internal SIM slot.
Power input of 9 to 36 V DC, with ignition control.
Operating range of -40 to +70 degrees C, with wide-temperature memory and storage.
Size of 155 x 110 x 60 mm and weight of 1.1 kg.
Operating system and drivers for your software.

Installation, commissioning and maintenance notes

Mount the box with the kit on a wall, a DIN rail or a panel, and leave space around it so that the case can give off heat. Connect the power input with a fuse, and check that the supply stays within 9 to 36 V DC. Fit the storage and the expansion cards before closing the case, then install the operating system. Set each serial port to the right protocol in the BIOS, and test the digital I/O with a simple program. Back up the system image after commissioning and keep the firmware versions in the records.

Requesting a quotation for the Axiomtek eBOX100B

Send the serial and I/O needs, the memory and the storage you want. Seven Star LLC serves industrial customers in Oman and the GCC and replies with a quotation based on the information provided.

Difference from the eBOX100A

Compared with the eBOX100A, this model trades the DisplayPort and the four-port LAN option for four serial ports, an 8-channel digital I/O connector and a second HDMI output.

Shock and vibration

The box is listed with shock and vibration tests to IEC 60068 and MIL-STD-810G.

Ignition control

The power input includes ignition control with intelligent USB power switching for vehicle use.

System records

Record the serial number, the BIOS settings and the installed software versions.

Documents and quotation

The manufacturer datasheet for the eBOX100B is attached to this page as a PDF (document type: datasheet) so the figures above can be checked against the source. For a quotation, send the full model or ordering code, quantity, any options such as modules or accessories, and the delivery location through the RFQ form. Seven Star LLC is an independent supplier in Muscat; availability and lead time are confirmed per request. More Axiomtek equipment is listed under this category, and the Axiomtek brand page shows the rest of the range on this site.

Axiomtek product families

The eBOX line covers compact fanless computers with wide DC input, from small Alder Lake-N units to LGA1700 systems with MXM graphics. The IPC line uses a vertical front-access chassis with optional PCIe slot cages for add-in cards, and one IP67 model with M12 connectors. Operating ranges, power input and I/O differ between models, so the datasheet should be read against the application, for example whether a -40 C rating, ignition control or a given number of serial ports is needed.

Ordering Axiomtek systems

Send the full order code including the suffix, plus the processor, memory, storage and any I/O modules or mounting kits. Most systems in the range are ordered without CPU, memory and drives, so those must be specified separately, and wide-temperature parts are sorted through the manufacturer. The datasheet ordering section also lists mounting kits, adapters and add-on modules for each model.
