MP Filtri LMP 210-211 Low Pressure In-Line Filter

A low pressure in-line filter for transmission and coolant lines

The MP Filtri LMP 210-211 is a range of low pressure in-line filters for transmission and protection of sensitive components in low pressure hydraulic systems, and for filtering coolant in machine tools. It also works for off-line filtration of small reservoirs. MP Filtri gives a maximum working pressure of 6 MPa (60 bar) and a flow rate up to 365 l/min. LMP210 has flanged connections up to 1 1/2 inch, and LMP211 has female threaded connections up to 1 1/2 inch.

The housing has an aluminium head and a cataphoretic painted steel bowl, which makes it a robust, low-cost choice for delivery lines in industrial equipment and mobile machines.

Technical specifications

Water removal and element choice

For machines that run with water in the oil, MP Filtri offers a water absorber element (WA025) that removes free water from the hydraulic fluid; the datasheet points to its contamination management document for details. For a normal particle duty, choose the media from the cleanliness class your components need: microfiber gives the finest ratings (3 to 25 micron), wire mesh is cleanable, and paper is the economical option.

The LMP is supplied for vertical mounting. It is meant for delivery lines rather than return lines; for a return line see the MPFX or MPLX series, and for suction protection see the SFEX or MPS.

Mount the filter vertically with the bowl downward and leave enough clearance beneath it to withdraw the element. The flanged LMP210 suits pipework that is already flanged, while the LMP211 threads directly into the line. A differential clogging indicator shows when the element needs changing, and an electrical or electronic indicator can signal the machine control. Before opening the bowl, isolate and depressurize the line, drain the oil and inspect the seal before refitting; replace any damaged seal.

What to confirm before ordering

State the flow, pressure, fluid and viscosity, media and rating, port style (flanged LMP210 or threaded LMP211), length, bypass setting, seal material and the indicator. More housings are listed under filter housings.

Documents and quotation

The attached MP Filtri catalogue chapter for LMP 210-211 (low and medium pressure filters, from the MP Filtri website) holds the dimensions, pressure-drop curves, element tables, ordering code and indicators. Send the model, media, connection and quantity for a quotation.
