Brand: Beamex
Beamex PGC Pressure and Vacuum Calibration Hand Pump
Description
One field pump for both gauge pressure and vacuum
The Beamex PGC is a hand-operated calibration pump that generates either pressure or vacuum with air as the medium, covering -0.95 to 35 bar (-13.7 to 510 psi). A selector on the pump head switches between pressure and vacuum, so a technician can check a transmitter, gauge or switch on both sides of atmospheric with one tool. A fine adjustment valve trims the generated pressure to the exact test point, and a release valve vents the system when the test is done.
The PGC is used together with a pressure calibrator or reference gauge, such as the Beamex MC6 or MC2 with an internal or external pressure module; the pump creates the pressure and the calibrator measures it.
Technical specifications
Values from the Beamex PG calibration pumps brochure (2025).
| Parameter | Specification |
|---|---|
| Model | Beamex PGC |
| Output pressure | -0.95 to 35 bar / -13.7 to 510 psi |
| Pressure medium | Air |
| Output connector | G1/8 in. female; pre-installed Bx G1/8 in. male fitting for Beamex 40 bar (600 psi) hoses |
| Controls | Pressure/vacuum selector, fine adjustment valve, release valve, stroke length setting |
| Dimensions | 220 x 120 x 65 mm (8.7 x 4.7 x 2.6 in.) |
| Weight | 820 g (1.81 lb) |
| Standard delivery | 40 bar T-hose set, pressure fitting set for 40 bar hoses, hard carrying case |
Using the stroke length setting
The PGC has an adjustable stroke length. A long stroke moves more air per squeeze and reaches the target quickly in larger test volumes; a short stroke makes it easier to reach the upper end of the range by hand. In practice, keep the test volume small with short hoses, check fittings for leaks before recording readings, and allow a short settling time after pumping, since air heats when compressed and the pressure drifts slightly as it cools.
Where it sits in the Beamex PG pump range
Beamex lists five PG calibration pumps in the current brochure, so the right one follows from the range and medium needed:
| Model | Type | Pressure range |
|---|---|---|
| PGM | Hand pump, air | 0 to 20 bar / 0 to 300 psi |
| PGC | Hand pump, air, pressure and vacuum | -0.95 to 35 bar / -13.7 to 510 psi |
| PGHH | Hydraulic hand pump | 0 to 700 bar / 0 to 10,000 psi |
| PGPH | Pneumatic table pump | -0.95 to 140 bar / -13.7 to 2000 psi |
| PGL | Low-pressure screw pump, air | -400 to +400 mbar / -160 to 160 iwc |
Documents and quotation
The attached Beamex PG pump brochure (April 2025) gives the specifications of all five models. When requesting a quotation, state the pump model, the pressure fittings or hoses needed for your instruments and whether a hard carrying case is required. Other field calibration equipment is listed under Portable Test and Measurement.
Datasheets & Documents
- Brochure Beamex PG calibration pumps brochure: PGM, PGC, PGHH, PGPH, PGL (EN, 2025) Download
Reviews (0)
About brand
Calibration equipment and software are the only things Beamex makes. Founded in 1975 in Pietarsaari, Finland, the company supplies the field calibrators that instrument technicians carry to check transmitters, switches and temperature sensors. Seven Star LLC, an independent supplier in Oman, lists Beamex MC6, MC6-Ex, MC4 and MC2 calibrators, the MB metrology temperature block and the ePG electric pressure pump and controller.
Beamex calibrators and accessories listed here
The handheld calibrators differ mainly in scope:- MC6: advanced field calibrator and communicator, the current model
- MC6-Ex: the intrinsically safe version for hazardous areas
- MC4: documenting process calibrator, discontinued by Beamex in May 2023
- MC2: hand-held process calibrator, discontinued in May 2023
Where Beamex calibrators are used
Any plant with a calibration program is a user: oil and gas facilities, power stations, water utilities, pharmaceutical and food plants across the GCC. A documenting calibrator stores the as-found and as-left results of each test, so they can be transferred to calibration software instead of being written down by hand. In classified areas the MC6-Ex, certified to ATEX and IECEx, is the model to ask for.Ordering Beamex calibrators: what we need
A Beamex calibrator is configured to order. Tell us the model, the internal pressure module ranges, any external pressure modules, the communicator protocols you need (for example HART), and the accessories: pumps, hoses, cases and test leads. For the MB state the model or the temperature range. If you need accredited calibration certificates from the manufacturer, say so at the start because it is an order option.Browse Beamex products by category: Portable Test & Measurement.
Related products
Frequently Asked Questions
What pressure range does the Beamex PGC cover?
From -0.95 bar vacuum up to 35 bar (-13.7 to 510 psi), using air as the pressure medium.
How do I switch between pressure and vacuum on the PGC?
A pressure/vacuum selector on the pump body sets which one the strokes generate.
What connection does the PGC have?
A G1/8 in. female output, with a pre-installed Beamex Bx G1/8 in. male fitting for Beamex 40 bar (600 psi) hoses.
What comes with the PGC?
Beamex lists a 40 bar T-hose set, a pressure fitting set for 40 bar hoses and a hard carrying case.
Can the PGC calibrate a 100 bar transmitter?
No. Its maximum is 35 bar. For pneumatic ranges up to 140 bar Beamex offers the PGPH table pump, and the PGHH for hydraulic work.
