Brand: Pfannenberg
Pfannenberg DTT 6301 Top-Mounted Cooling Unit, 1500 W
Description
Top-mounted cooling units with patented condensate protection
The Pfannenberg DTT 6301 is a roof-mounted eCool cooling unit of 1500 to 1620 W, and its larger sibling the DTT 6401 delivers 2000 to 2100 W. Top-mounted units free up the side and door area and are chosen for tall cabinets and where wall space is limited. The sheet lists three installation sizes and six performance classes in the DTT range, a four-fold protection against condensate through a patented management system, and toolless mounting through a quick installation frame.
The complete cover is removable towards the front, so filter mats and controls are accessible from the front, and the sheet claims around 20 % energy saving through more efficient and lighter components, with an optional multi-controller with an energy-saving mode. Stainless steel versions are available.
Technical specifications
| Parameter | DTT 6401 | DTT 6301 |
|---|---|---|
| Cooling capacity A35/A35 (50 / 60 Hz) | 2000 / 2100 W | 1500 / 1620 W |
| Cooling capacity A35/A50 (50 / 60 Hz) | 1540 / 1600 W | 1000 / 1160 W |
| Refrigerant | R134a, 750 g | R134a, 725 g |
| Weight (by voltage version) | 51 kg (400 V) and 46 kg (230 V) | 50.5 kg (400 V), 45 kg (230 V), 40 kg (115 V) |
| Voltage versions | 400 / 460 V 3~, 230 V | 400 / 460 V 2~, 230 V, 115 V |
| Parameter | Specification |
|---|---|
| Air flow internal / external (free flow) | 885 / 990 m³/h and 1820 / 1970 m³/h |
| Noise level | Below 62 dB(A) (EN ISO 3741) |
| Ambient temperature | +15 to +55 °C |
| Control range | Standard controller +25 to +45 °C; multi-controller +25 to +50 °C; factory setting +35 °C |
| Condensate | Integrated condensate evaporation system with safety overflow |
| Protection | IP 54 towards the electrical enclosure; IP 34 towards the surroundings |
| Construction | Galvanised sheet steel housing; cover galvanised and powder-coated or stainless steel; RAL 7035 |
| Connection | Spring-type terminal with plug |
Ordering codes
Article numbers from the product sheet; SC is the standard controller, MC the multi-controller and V2A the stainless steel version.
| Version | 400 V | 230 V | 115 V |
|---|---|---|---|
| DTT 6301, SC | 13256349055 (400 V) | 13256341055 (230 V) | 13256344055 (115 V) |
| DTT 6301, MC | 13256379055 (400 V) | 13256371055 (230 V) | on request |
| DTT 6301, V2A SC | 13256349015 (400 V) | 13256341015 (230 V) | on request |
| DTT 6401, SC | 13256432055 (400 V 3~) | 13256441055 (230 V) | – |
| DTT 6401, MC / V2A | 13256462055 / 13256432015 (400 V 3~) | 13256471055 / 13256441015 (230 V) | – |
Accessories: condensate bottle 18314000100, quick installation frame 18300000145, and pre-filters in fleece (18300000147), fluted (18300000148) and aluminium (18300000149) with filter adapter 18310000151.
Selection and what to confirm before ordering
Select the size from the heat load at the maximum site ambient, using the A35/A50 column for hot rooms. The roof opening must be free and the roof area must carry the weight of 40 to 51 kg; check the structure. A top-mounted unit needs a free air path around its condenser. The external air flow of 1820 to 1970 m³/h is about twice the internal flow of 885 to 990 m³/h, and the noise level below 62 dB(A) should be considered for cabinets standing in operator areas. Confirm the voltage version, the controller (standard or multi-controller), the cover (powder-coated or stainless) and the filter accessories. Compare wall-mounted alternatives such as the Rittal Blue e+ wall-mounted cooling units, and see the Cooling category.
Documents and quotation
The Pfannenberg DTT 6401/6301 product sheet is attached to this page and is the manufacturer’s own document, not a Seven Star summary. It includes cooling-capacity curves and mounting information.
State voltage, controller and cover version. Seven Star LLC, an independent supplier in Muscat, quotes the DTT 6301 and DTT 6401 against your application data; send the enclosure size, ambient temperature, supply voltage and quantity so the correct variant and article number can be confirmed before an offer is issued.
Datasheets & Documents
- Datasheet Pfannenberg DTT 6401/6301 product sheet (manufacturer PDF) Download
Reviews (0)
About brand
Pfannenberg is the German maker of thermal management and signalling products for electrical enclosures and industry: filter fans, cooling units, air-to-water heat exchangers, chillers, heaters, sirens and beacons. Otto Pfannenberg, an electrical engineer, founded the company in Hamburg in 1954, and in 1958 he invented the filter fan to stop components in control cabinets from overheating. Pfannenberg is still family-owned and headquartered in Hamburg.
Seven Star LLC is an independent supplier in Muscat. We list Pfannenberg signalling devices and enclosure climate products for panel builders and plant engineers in Oman and the GCC.
Pfannenberg company profile
| Founded | 1954, Hamburg, Germany |
|---|---|
| Founder | Otto Pfannenberg, electrical engineer |
| Headquarters | Hamburg, Germany; North American headquarters in Lancaster, New York |
| Ownership | Family-owned |
| Product families | PF Filterfans, DTS and DTI cooling units, air-to-water heat exchangers, process chillers, enclosure heaters and thermostats, PA and DS sirens, beacons and combined signalling devices |
Milestones
- 1954: Otto Pfannenberg founds the company in Hamburg.
- 1958: Pfannenberg invents the filter fan for control cabinets.
- 1962: The company introduces an industrial flashing light that does not need a bulb change after activation.
Pfannenberg product series
Signalling devices include the PATROL PA X combined flashing sounders from 105 to 122 dB(A), the PYRA flashing light sounder, the PRO 10-Ex sounder for zone 2 and zone 22, and the INTENSE BR 50 modular LED signal tower.
Thermal management covers FLZ enclosure thermostats, twin thermostats, hygrostats and Peltier thermostats, FLH radiant heaters and PFH and FLH-T fan heaters, PF filter fans in several installation sizes up to 785 m3/h and the PTF roof-mounted filter fan, and DTS and DTI cooling units, including the DTI outdoor version.
Where Pfannenberg products are used
Control and drive cabinets on machines and in plant rooms, outdoor enclosures in hot and humid climates, and alarm and evacuation signalling in industrial buildings and process areas. In the Gulf, cabinet cooling and condensation control are the main reasons for specifying Pfannenberg thermal products.
Pfannenberg products we list
Ordering Pfannenberg products: what we need
Send the article number or full designation, such as PA X 1-05 or DTI 8401P. For signalling devices add the supply voltage, lens and housing colour and any required approval such as EN 54-3 or an Ex certificate. For cooling units give the cooling capacity, voltage and frequency, mounting (side or roof, internal or external) and the ambient temperature. For fans and heaters give the installation size, voltage and airflow or heating power.
Facts checked against Pfannenberg's published company history, October 2026.
Browse Pfannenberg products by category: Enclosure Climate Control, Fire & Gas Detectors, Cooling.
Related products
Frequently Asked Questions
What is the DTT 6301 cooling capacity?
1500 W at 50 Hz and 1620 W at 60 Hz under A35/A35 conditions per EN 14511.
Which refrigerant does it use?
R134a, 725 g for the DTT 6301 and 750 g for the DTT 6401.
What is special about the condensate management?
The sheet describes a patented system with four-fold protection against condensate.
What controller options exist?
A standard controller (SC) and an optional multi-controller (MC) with energy-saving mode.
Is stainless steel available?
Yes, V2A stainless steel versions are listed in the ordering table.
