Thermal Care TSE Series Central Chiller 10 to 240 Ton

Name: Thermal Care TSE Series Chiller | Seven Star LLC
Brand: Thermal Care

Description

Overview

The Thermal Care TSE Series Chiller is a scroll-compressor industrial chiller platform built to scale from a single 10-ton unit up to large multi-circuit systems delivering over 1,000 tons (3,517 kW) of total cooling capacity, by combining multiple direct-drive scroll refrigeration circuits into one coordinated system. Each individual TSE frame is rated from 10 to 240 tons, and Thermal Care’s modular design allows up to twelve refrigeration circuits to be combined into a single installation for total capacity beyond 1,000 tons – giving facilities a cooling platform that scales with process demand rather than forcing an oversized single chiller from day one.

With fast quotation turnaround and technical support, Seven Star LLC proudly supplies the TSE Series Chiller to industrial process cooling, commercial HVAC, and data center operators across the Sultanate of Oman and the wider Gulf region. Every unit is supplied with manufacturer documentation and regional technical support.

Operating Principle

The TSE Series uses hermetically sealed, direct-drive scroll compressors in each refrigeration circuit – a compressor technology chosen for its combination of high efficiency, reliability, and minimal maintenance requirement compared to reciprocating or screw compressor alternatives at this capacity range. Each circuit operates independently within the chiller, so a single-circuit fault does not take the entire system offline; a multi-circuit dual or higher configuration continues delivering partial cooling capacity while the affected circuit is serviced, an important resilience feature for process cooling applications that cannot tolerate a complete loss of chilled water.

Refrigerant options include R-454B, a low global-warming-potential refrigerant aligned with current environmental regulation trends, or R-410A as an energy-efficient alternative where R-454B is not yet the regional standard. Water-cooled condenser models are built with cleanable frames and removable heads for straightforward tube-side maintenance, and the system is designed to deliver precise chilled water temperatures across a 20°F to 80°F (roughly –7°C to 27°C) range depending on process requirement.

Engineering Design of the Thermal Care TSE Series

Each TSE chiller frame is engineered to fit through a standard 36-inch man door, a deliberate design choice that keeps installation and equipment room retrofit practical even in facilities with limited rigging access – a common constraint in existing plant buildings across the region. Single and dual circuit configurations are available per frame, with larger dual-circuit units such as the 240-ton TSEW model built with three compressors per circuit for further internal redundancy within a single chiller frame.

Control is handled through a PLC-based control system with a high-resolution color touchscreen operator interface, giving plant staff direct visibility into compressor runtime tracking, alarm history, and operating parameters without needing a separate building management system just to monitor the chiller itself. This same PLC platform integrates cleanly with a plant’s existing BMS where one is present, supporting remote monitoring, fault diagnostics, and coordinated load management across multiple combined circuits in a large installation.

Key Features

The TSE Series Chiller combines scalable modular design with field-serviceable construction, including:

Modular scroll-compressor architecture, scaling from a single 10-ton frame up to combined systems beyond 1,000 tons.
Hermetically sealed, direct-drive scroll compressors for high efficiency and minimal maintenance.
Independent refrigeration circuits, so a single-circuit fault does not take the whole system offline.
Choice of low-GWP R-454B or energy-efficient R-410A refrigerant.
Water-cooled condenser models with cleanable frames and removable heads for straightforward maintenance.
PLC control with high-resolution color touchscreen interface, compressor runtime tracking, and alarm history.
Sized to fit through a standard 36-inch man door for practical installation and retrofit access.
Chilled water delivery across a wide 20°F to 80°F process temperature range.

Industrial Applications

Reliable process cooling is a foundational utility across Oman and the GCC’s manufacturing, chemical processing, and data center sectors, and the TSE Series’ modular scalability is particularly well suited to facilities whose cooling demand grows over time. In chemical and industrial process plants, the TSE Series provides chilled water for reactor cooling, process heat removal, and utility cooling loops, with the multi-circuit design allowing a facility to add refrigeration capacity in stages as production expands rather than committing to a single oversized chiller upfront. In data centers and manufacturing facilities across Muscat, Sohar, and Salalah, the same platform delivers the continuous, redundant cooling capacity that mission-critical equipment and clean room environments require.

With engineering support in Muscat, Seven Star LLC supplies the TSE Series Chiller to industrial process operators, data center facilities, hospitals, and manufacturing plants across the region. Its independent-circuit design and PLC-based control make it a strong fit for any facility that needs both scalable capacity and the operational resilience of a multi-circuit system.

Technical Specifications

Key technical specifications for the Thermal Care TSE Series Chiller are summarized below.

Parameter	Specification
Model	Thermal Care TSE Series Chiller
Cooling Capacity (system)	Over 1,000 tons (3,517 kW), via combined circuits
Cooling Capacity (single frame)	10 to 240 tons per frame; up to 12 circuits combinable, 1,000+ tons total
Compressor Type	Hermetically sealed, direct-drive scroll
Refrigerant	R-454B (low GWP) or R-410A
Condenser	Water-cooled, cleanable frame, removable heads
Circuit Configuration	Single or dual circuit per frame
Control System	PLC with color touchscreen interface
Process Temperature Range	20°F to 80°F
Installation Access	Fits through standard 36-inch man door

Request a Quote for Thermal Care TSE Series Central Chiller 10 to 240 Ton

Seven Star LLC welcomes formal RFQs for the Thermal Care TSE Series Chiller from industrial process plants, data centers, and manufacturing facilities across Oman and the GCC. With manufacturer documentation, we confirm availability and lead time at quotation, provide the full technical datasheet on request, and can connect your team directly with our instrumentation and process cooling division for capacity sizing and installation planning. Contact Seven Star LLC today to request a formal quotation or technical consultation for your process cooling requirements.

Related Products

Reviews (0)

Reviews

There are no reviews yet.

How would you rate this product?

About brand

Process chillers and cooling equipment are the business of Thermal Care, a manufacturer founded in 1969 and based in Niles, USA. Its TSE Series is a line of central chillers built around scroll compressors. Seven Star LLC lists the Thermal Care TSE Series and supplies Thermal Care chillers and chiller parts on request to industrial plants in Oman, after checking each selection against the manufacturer's data.

Thermal Care TSE chillers

The manufacturer presents the TSE Series as a central chiller line from 10 to 240 tons per unit, with single-circuit and dual-circuit models and water-cooled TSEW versions. Larger loads are covered by running several chillers together; the maker states that up to six units can be combined to exceed 1,000 tons. Selection depends on the leaving fluid temperature, the condenser arrangement and the electrical supply, so the exact model is confirmed for each inquiry.

Ordering Thermal Care equipment: what we need

For a new chiller, send the cooling load in kW or tons, the entering and leaving fluid temperatures, the flow rate, the fluid type and glycol percentage, the ambient or condenser water temperature, and the voltage and frequency. For parts, send the model and serial number from the chiller nameplate with a photo. We handle inquiries from other GCC countries in the same way.

Browse Thermal Care products by category: Cooling.

Frequently Asked Questions

How does the TSE Series scale to such a wide capacity range?

Each TSE frame is rated 10 to 240 tons, and up to twelve independent refrigeration circuits can be combined into a single coordinated system, allowing total capacity to scale from around 200 kW up past 2,400 kW as facility demand grows.

What happens if one refrigeration circuit fails?

Each circuit operates independently, so a fault in one circuit does not take the whole system offline. A multi-circuit installation continues delivering partial cooling capacity while the affected circuit is serviced.

What refrigerant does the TSE Series use?

The TSE Series is available with low-GWP R-454B refrigerant, aligned with current environmental regulation trends, or R-410A as an energy-efficient alternative.

Can the TSE Series integrate with an existing building management system?

Yes. The PLC-based control system with color touchscreen interface integrates with a plant's existing BMS for remote monitoring, fault diagnostics, and coordinated load management across combined circuits.
