Brand: Pfannenberg
Pfannenberg DTS 6301C Green Series Cooling Unit, 1500 W
Description
Green Series cooling units for 1500 W and high efficiency
The Pfannenberg DTS 6301C and its partially recessed sibling the DTI 6301C are Green Series cooling units of 1500 W cooling capacity. The DTS mounts on the outside of the door or side, the DTI sits partly recessed, and both are built for highest energy efficiency, a reduced refrigerant charge, UL 60335 listing and easy service.
The Green Series upgrade lowers the carbon footprint through a smaller R513A charge of 400 g, and a toolless filter integration with an accessory adapter allows fitting a filter in seconds. An optional controller version offers a Modbus RTU connection, and a variant for the IT industry has a Type F plug and a 20 °C set point.
Technical specifications
| Parameter | 400/460 V | 230 V | 115 V |
|---|---|---|---|
| Rated voltage | 400 / 460 V 2~, 50/60 Hz | 230 V, 50/60 Hz | 115 V, 60 Hz |
| Cooling capacity A35/A35 (50 / 60 Hz) | 1500 / 1580 W | 1500 / 1580 W | 1500 / 1580 W |
| Cooling capacity A35/A50 | 1200 / 1250 W | 1200 / 1250 W | 1200 / 1250 W |
| Cooling capacity A35/A25 | 1640 / 1700 W | 1640 / 1700 W | 1640 / 1700 W |
| Power consumption A35/A35 | 630 / 730 W | 610 / 705 W | 730 W |
| Starting current | 6.3 / 5.6 A | 10.7 A | 22 A |
| EER A35/A35 | 2.4 / 2.2 | 2.5 / 2.4 | 2.2 |
| Weight | 39 kg | 34 kg | 39 kg |
| Parameter | Specification |
|---|---|
| Air flow internal / external | 885 / 920 m³/h |
| Ambient temperature / control range | +15 to +60 °C; +25 to +45 °C, factory setting +35 °C |
| Refrigerant | R513A, 400 g (GWP 631) |
| Condensate management | Integrated condensate evaporation system with safety overflow |
| Protection | UL 50 Type 12 and IP 55 towards the electrical enclosure; IP 24 towards the surroundings |
| Dimensions DTI (X x Y x Z) | 418 x 962 x 244 mm, partially recessed by 60 mm |
| Dimensions DTS (X x Y x Z) | 399 x 966 x 244 mm |
| Construction | Galvanised sheet steel housing; powder-coated cover (stainless steel on request); RAL 7035 |
Article numbers and accessories
The article numbers are given per voltage in the order 400/460 V, 230 V and 115 V. DISPLAY and LED refer to the controller version.
| Version | 400/460 V | 230 V | 115 V |
|---|---|---|---|
| DTI, display | 13898359055 | 13898351055 | 13898354055 |
| DTI, LED | 13898349055 | 13898341055 | 13898344055 |
| DTS, display | 13888359055 | 13888351055 | 13888354055 |
| DTS, LED | 13888349055 | 13888341055 | 13888344055 |
Accessories: filter adapter 18310000151, aluminium filter 18300000149, fleece filter (5 pieces) 18300000147 and fluted filter (5 pieces) 18300000148.
Selection and what to confirm before ordering
Choose the DTS where the unit can be mounted on the outside of the door and the DTI where recessed mounting is preferred; both are available with the display or the LED controller. The three capacity values describe the same unit at different ambient temperatures: A35/A35 means 35 °C ambient with 35 °C inside, A35/A50 means 50 °C ambient and A35/A25 means 25 °C ambient, so capacity falls as the surroundings get hotter. Compare the heat load with the A35/A50 value of 1200 W for hot sites, and consider the A35/A25 value of 1640 W for cooler locations. The ambient range of +15 to +60 °C suits hot plant rooms, but no low-ambient package is listed for this series, so use the DTI 8000P or DTS 3000 series for cold outdoor sites. Confirm voltage, controller version and filter option before ordering. See also the Rittal Blue e+ wall-mounted cooling units.
Documents and quotation
The Pfannenberg DTI/DTS 6301C Green Series product sheet is attached to this page and is the manufacturer’s own document, not a Seven Star summary. The product page also lists a separate sheet for the IT-industry version.
Give voltage, DTI or DTS, and display or LED version. Seven Star LLC, an independent supplier in Muscat, quotes the DTI 6301C and DTS 6301C against your application data; send the enclosure size, ambient temperature, supply voltage and quantity so the correct variant and article number can be confirmed before an offer is issued.
Datasheets & Documents
- Datasheet Pfannenberg DTI/DTS 6301C Green Series product sheet (manufacturer PDF) Download
Reviews (0)
About brand
Pfannenberg is the German maker of thermal management and signalling products for electrical enclosures and industry: filter fans, cooling units, air-to-water heat exchangers, chillers, heaters, sirens and beacons. Otto Pfannenberg, an electrical engineer, founded the company in Hamburg in 1954, and in 1958 he invented the filter fan to stop components in control cabinets from overheating. Pfannenberg is still family-owned and headquartered in Hamburg.
Seven Star LLC is an independent supplier in Muscat. We list Pfannenberg signalling devices and enclosure climate products for panel builders and plant engineers in Oman and the GCC.
Pfannenberg company profile
| Founded | 1954, Hamburg, Germany |
|---|---|
| Founder | Otto Pfannenberg, electrical engineer |
| Headquarters | Hamburg, Germany; North American headquarters in Lancaster, New York |
| Ownership | Family-owned |
| Product families | PF Filterfans, DTS and DTI cooling units, air-to-water heat exchangers, process chillers, enclosure heaters and thermostats, PA and DS sirens, beacons and combined signalling devices |
Milestones
- 1954: Otto Pfannenberg founds the company in Hamburg.
- 1958: Pfannenberg invents the filter fan for control cabinets.
- 1962: The company introduces an industrial flashing light that does not need a bulb change after activation.
Pfannenberg product series
Signalling devices include the PATROL PA X combined flashing sounders from 105 to 122 dB(A), the PYRA flashing light sounder, the PRO 10-Ex sounder for zone 2 and zone 22, and the INTENSE BR 50 modular LED signal tower.
Thermal management covers FLZ enclosure thermostats, twin thermostats, hygrostats and Peltier thermostats, FLH radiant heaters and PFH and FLH-T fan heaters, PF filter fans in several installation sizes up to 785 m3/h and the PTF roof-mounted filter fan, and DTS and DTI cooling units, including the DTI outdoor version.
Where Pfannenberg products are used
Control and drive cabinets on machines and in plant rooms, outdoor enclosures in hot and humid climates, and alarm and evacuation signalling in industrial buildings and process areas. In the Gulf, cabinet cooling and condensation control are the main reasons for specifying Pfannenberg thermal products.
Pfannenberg products we list
Ordering Pfannenberg products: what we need
Send the article number or full designation, such as PA X 1-05 or DTI 8401P. For signalling devices add the supply voltage, lens and housing colour and any required approval such as EN 54-3 or an Ex certificate. For cooling units give the cooling capacity, voltage and frequency, mounting (side or roof, internal or external) and the ambient temperature. For fans and heaters give the installation size, voltage and airflow or heating power.
Facts checked against Pfannenberg's published company history, October 2026.
Browse Pfannenberg products by category: Enclosure Climate Control, Fire & Gas Detectors, Cooling.
Related products
Frequently Asked Questions
What is the cooling capacity?
1500 W at 50 Hz and 1580 W at 60 Hz at A35/A35 per EN 14511.
How do DTS and DTI differ?
DTS mounts on the outside of the door or side; DTI is partially recessed by 60 mm.
What refrigerant does it use?
R513A with a 400 g charge.
Is Modbus available?
An optional controller version with Modbus RTU connection is offered.
What is the ambient temperature range?
+15 to +60 °C according to the product sheet.
