C-TEC CFP708-4 8 Zone Conventional Fire Alarm Panel
Overview
The C-TEC CFP708-4 is an eight-zone conventional fire alarm control panel, LPCB certified to EN54 parts 2 and 4, and manufactured by C-TEC in the UK. It provides eight detector zone circuits and four conventional sounder circuits in an attractive flush- or surface-mountable plastic enclosure, with an intuitive user interface using colour-coded buttons and combined keypad/keyswitch entry. The panel is supplied with an integral 1.5 A EN54-4/A2 compliant switch-mode power supply and space for two 12 V VRLA backup batteries.
Engineering and Design
A wide range of engineering functions is built in, including zone test, coincidence, zone delay and non-latching zones, plus comprehensive test and fault-finding facilities. The panel includes two on-board relays (fire and fault), two open-collector outputs (remote and reset), and class change and alert inputs for integration with building management systems. Eight zone circuits support a maximum circuit length of 500 m with up to 25 detectors per zone (32 combined with manual call points), and the quiescent current draw is a low 25 mA.
The CFP708-4 operates from a 230 V 50/60 Hz mains supply with a maximum 350 mA current draw, providing an internal supply of 19-28.5 V DC (nominal 27 V) with total output current limited to 1.5 A. Two 12 V VRLA batteries (max 3.2-3.3 Ah) in series provide standby power, with a minimum battery size of 1.2 Ah. Expansion connections support up to eight two-wire repeaters (one CFP761 network card per system) and optional CFP relay boards, and the panel is fully compatible with C-TEC’s ActiV range of conventional detectors with options for EN54-13 compliant sounder circuit boards.
Key Features
- Eight detector zone circuits and four conventional sounder circuits
- Third-party certified to EN54 parts 2 and 4 by LPCB; EN54-13 compliance option via BSI
- Integral 1.5 A EN54-4/A2 compliant switch-mode PSU
- 230 V 50/60 Hz mains supply with low 25 mA quiescent current
- Two on-board relays (fire and fault) plus two open-collector outputs (remote and reset)
- Class change and alert inputs for BMS integration
- Zone test, coincidence, zone delay and non-latching zone engineering functions
- Up to 25 devices per zone (32 with call points), 500 m max zone circuit length
- Space for two 12 V 3.3 Ah VRLA batteries in series for standby power
- Flush or surface mount plastic enclosure with keypad/keyswitch entry
- Expansion to eight repeaters via CFP761 network card and optional relay boards
- Fully compatible with C-TEC ActiV range of conventional detectors
Applications
Conventional fire detection and alarm systems for offices, retail, schools, hotels, residential buildings, small industrial facilities and public buildings requiring an EN54-certified multi-zone panel.
Specifications
| Zones | 8 detector zone circuits (500 m max per circuit) |
| Sounder circuits | 4 conventional sounder circuits |
| Certification | EN54 parts 2 and 4 (LPCB); EN54-13 compliance option (BSI) |
| Mains supply | 230 V AC, 50/60 Hz, 350 mA max |
| Internal supply | 19-28.5 V DC (nominal 27 V); total output limited to 1.5 A |
| Batteries | 2 x 12 V VRLA in series, max 3.3 Ah (min 1.2 Ah) |
| Quiescent current | 25 mA |
| Alarm voltage | 20 V min / 27 V max |
| Devices per zone | Up to 25 (32 combined with manual call points) |
| Outputs | 2 relays (fire, fault); 2 open-collector (remote, reset) |
| Inputs | Class change, alert |
| Expansion | Up to 8 two-wire repeaters (CFP761 card), CFP relay boards, EN54-13 sounder boards |
| Compatibility | C-TEC ActiV conventional detector range |
| Enclosure | Plastic, flush or surface mount |
| Manufacturer | C-TEC, UK |
