Brand: Lovato Electric
Lovato SM1P3200 24-32 A Motor Protection Circuit Breaker
Description
SM1 breaker with a 24-32 A thermal range
Where a motor feeder needs a switch, overload protection and short-circuit protection in one place, the three-pole SM1P3200 from the Lovato Electric SM1 range does all three; the overload dial adjusts over 24-32 A.
Rated current In is 32 A; the thermal release adjusts 24-32 A and the magnetic release trips at 13 x In. Breaking capacity values are listed as 10 kA at 400 V, 10 kA at 440 V and 2 kA at 690 V. The tripping class is 10A.
Technical specifications
| Parameter | Specification |
|---|---|
| Order code | SM1P3200 |
| Product designation | Motor protection circuit breaker |
| Product type designation | SM1P |
| Number of poles | 3 |
| Magnetic protection | yes |
| Thermal protection | yes |
| Phase failure detection | yes |
| Rated insulation voltage Ui IEC/EN | 690 V |
| Rated impulse withstand voltage Uimp | 6 kV |
| Rated frequency | 50/60 Hz |
| Thermal trip adjustment range | 24-32 |
| Rated current (In) | 32 A |
| Magnetic tripping | 13 x In |
| Power dissipation per pole (min) | 2.49 W |
| Power dissipation per pole (max) | 4.42 W |
| Operational short-circuit current breaking capacity (Ics) at AC, 230V | 50 kA |
| Operational short-circuit current breaking capacity (Ics) at AC, 400V | 5 kA |
| Operational short-circuit current breaking capacity (Ics) at AC, 440V | 5 kA |
| Operational short-circuit current breaking capacity (Ics) at AC, 500V | 5 kA |
| Operational short-circuit current breaking capacity (Ics) at AC, 690V | 2 kA |
| Maximum short-circuit current breaking capacity (Icu) at AC, 230V | 50 kA |
| Maximum short-circuit current breaking capacity (Icu) at AC, 400V | 10 kA |
| Maximum short-circuit current breaking capacity (Icu) at AC, 440V | 10 kA |
| Maximum short-circuit current breaking capacity (Icu) at AC, 500V | 10 kA |
| Maximum short-circuit current breaking capacity (Icu) at AC, 690V | 2 kA |
| Tripping class | 10A |
| Mechanical life | 100000 cycles |
| Electrical life | 100000 cycles |
| Operating temperature (min) | -20 °C |
| Operating temperature (max) | +60 °C |
| Storage temperature (min) | -50 °C |
| Storage temperature (max) | +80 °C |
| Compensation temperature (min) | -20 °C |
| Compensation temperature (max) | +50 °C |
| Max altitude | 3000 m |
| Operating position, normal | Vertical plan |
| Fixing | Screw / DIN rail 35mm |
| Weight | 350 g |
| Motor Disconnect, at 240V | 5 kA |
| Motor Disconnect, at 480V | 5 kA |
| protection | Fuse or CB |
| Group Motor Installation, at 240V | 5 kA |
| Group Motor Installation, at 480V | 5 kA |
| Maximum UL/CSA horsepower ratings single-phase, 110V-120V | 2 HP |
| Maximum UL/CSA horsepower ratings single-phase, 220V-240V | 5 HP |
| Maximum UL/CSA horsepower ratings three-phase, 3-pole, 200V-208V | 10 HP |
| Maximum UL/CSA horsepower ratings three-phase, 3-pole, 220V-240V | 10 HP |
| Maximum UL/CSA horsepower ratings three-phase, 3-pole, 440V-480V | 20 HP |
Matching the breaker to the motor
Because the thermal release adjusts only within 24-32 A, selection is simple: find the code whose window holds the motor current, then confirm the breaking capacity (10 kA Icu at 400 V) exceeds the fault level on the board.
At 400 V the breaking capacity is 10 kA (Icu) and 5 kA (Ics). Compare that with the fault level at your board, and look at the 440 V to 690 V columns where the figures can drop sharply.
Where it is used
The breaker also works as a manual motor switch: the front handle switches the motor on and off and indicates a trip. That makes it useful for local isolation at pumps, fans and machine tools.
It mounts by screws or on a 35 mm DIN rail, weighs 350 g and operates between the temperature limits listed in the table above. Power dissipation per pole is 2.49 W to 4.42 W, which matters for enclosure heat calculations.
Documents and quotation
All data on this page for SM1P3200 is taken from the Lovato Electric catalogue datasheet (English), which you can download from the attachment list. What to confirm before ordering: the motor full-load current, the supply voltage and the prospective short-circuit current at the panel. The manufacturer can revise published data at any time. See circuit breakers for similar items. Quote request: give the exact code SM1P3200, the quantity and where it must be delivered, and Seven Star LLC (independent supplier, Muscat) will respond.
Datasheets & Documents
- Datasheet Lovato Electric SM1P3200 datasheet (EN, catalogue export) Download
Reviews (0)
About brand
Lovato Electric is the Italian manufacturer of low-voltage electrical components for industrial automation and power distribution: contactors, motor protection circuit breakers, soft starters, variable speed drives, power factor controllers, transfer switch and generator controllers, and energy meters. It was founded in Bergamo in 1922 and has been run by the same family for four generations. Its headquarters is in Gorle, near Bergamo, and it celebrated its centenary in 2022.
Seven Star LLC is an independent supplier in Muscat. We list Lovato motor control, drives and power management products, and supply them to panel builders, contractors and maintenance teams in Oman and the GCC by order code.
Lovato Electric at a glance
| Established | 1922, Bergamo, Italy |
|---|---|
| Headquarters | Gorle (Bergamo), Italy |
| Ownership | Private, family-run for four generations |
| Product families | Contactors and relays, motor protection circuit breakers, motor starters, soft starters, variable speed drives, power factor controllers, ATS and gen-set controllers, multimeters and energy meters, micro PLCs |
Lovato products we list
| Family | Models | Typical use |
|---|---|---|
| Contactors | BF0910A230, BF1810A230, BF2510A230, BF2600A230, BF09T4A230 4-pole, BFS0923A024, 11BG0910A230 mini, 11BGR0901A048 reversing | Switching motors, heaters, lighting and capacitor banks |
| Motor protection and starters | SM1P0650, SM1P1000, SM1P3200, M1P enclosed DOL starter, ME024FD024, ME070RSD024, 31L48 time relay | Short-circuit and overload protection and direct starting of motors |
| Soft starters | ADXL0030600, ADXL0085600, ADXL0135600, ADXT0034, ADXT0084, ADXT0139 | Reducing starting current and mechanical shock on pumps, fans and compressors |
| Variable speed drives | VLA1, VLB1, VLB3 0.75 kW, VLB3 2.2 kW, VLB3 5.5 kW, VLB3 22 kW, VT1 | Speed control of pumps, fans and conveyors to save energy |
| Power management and control | DCRG8, DCRL8 PF controllers, ATL600 ATS controller, RGK600 gen-set controller, DMG200 multimeter, DMED300T2 energy meter, LRD20 micro PLC | Power factor correction, mains/generator changeover and energy monitoring |
Lovato order codes describe the product. On a contactor such as BF0910A230, "BF09" is the frame and rated current (9 A in AC-3), "10" is the built-in auxiliary contact (one normally open), "A" means an AC coil and "230" is the coil voltage. The coil voltage must match the control circuit exactly, so it is the most common detail to check when replacing one. For motors, a soft starter limits the inrush current at start and stop, while a variable speed drive controls the speed continuously and saves energy on pumps and fans that do not need full flow all the time.
Where Lovato products are used
In Oman and the GCC, Lovato components are built into motor control centres, pump and HVAC panels, capacitor banks for power factor correction, generator and ATS panels, and machine control panels for industry, water and buildings.
Ordering Lovato products: what we need
Send the full Lovato order code. For contactors and starters, confirm the coil or control voltage. For drives and soft starters, send the motor power, current and supply voltage. For power factor controllers, send the number of steps and the CT ratio.
Facts checked against Lovato Electric company profile brochures, October 2026.
Browse Lovato Electric products by category: Motor Soft Starters, Automation Accessories, Controllers & Data Acquisition, PLC & I/O Cards, Circuit Breakers, Diesel Generator Spare Parts.
Related products
Frequently Asked Questions
What current range does the SM1P3200 cover?
The thermal release is adjustable 24-32 A, with rated current 32 A and magnetic tripping at 13 x In.
What is the breaking capacity at 400 V?
Icu is 10 kA at 400 V AC and Ics is 5 kA.
Does it detect phase failure?
Yes, phase failure detection is listed, with tripping class 10A.
How is the SM1P3200 mounted?
On a 35 mm DIN rail or with screws.
Can it be combined with a contactor?
Lovato lists connection kits and accessories in the same series for assembling a compact starter; confirm the exact kit code for your contactor before ordering.
