Lovato RF826500 46-65 A Thermal Overload Relay

Name: Lovato RF826500 Overload Relay | Seven Star LLC
Brand: Lovato Electric
SKU: RF826500

Description

Thermal overload protection for motors drawing 46-65 A

The RF826500 is a three-pole thermal motor protection relay of the Lovato Electric RF82 family with an adjustment range of 46-65 A. It watches the motor current in all three phases, trips on overload and on phase failure, and reports the state with a trip indicator and a test button.

Tripping class is 10A, the reset mode is manual, and the auxiliary contact block provides 1 NO and 1 NC for the control circuit. Insulation voltage is 690 V.

Technical specifications

Parameter	Specification
Order code	RF826500
Product type designation	RF82
Product designation	Motor protection relay
Number of poles	3
Pollution degree	3
Frontal IP degree	IP20
Type of release	Thermal
gG (IEC)	125 A
aM (IEC)	80 A
K5 (UL)	200 A
Functions and protections provided	Phase failure detection
Rated insulation voltage Ui IEC/EN	690 V
Rated impulse withstand voltage Uimp	8 kV
Rated operational voltage	690 V
Operational frequency (min)	0 Hz
Operational frequency (max)	400 Hz
Operational current min	46 A
Operational current max	65 A
Tripping class	10A
Test Button	Yes
Trip indicator	yes
Terminals type	Yoke clamp
Terminals screw	M5
Terminals width	9 mm
Terminals tool	Phillips 2
Auxiliary contacts, NO	1
Auxiliary contacts, NC	1
Auxiliary Rated insulation voltage Ui IEC/EN	690 V
Auxiliary Rated impulse withstand voltage Uimp	6 kV
Auxiliary Rated operational voltage	690 V
Auxiliary circuit type	screw and washer
Auxiliary circuit screw	M3,5
Auxiliary circuit width	8 mm
Auxiliary circuit tool	Phillips 1
Operating temperature (min)	-20 °C
Operating temperature (max)	55 °C
Storage temperature (min)	-55 °C
Storage temperature (max)	80 °C
Compensation temperature (min)	-15 °C
Compensation temperature (max)	55 °C
Max altitude	3000 m
Operating position, normal	Vertical plan
Operating position, allowable	±30°
Fixing	Direct mounting on BF40- BF94-
Weight	365 g

Choosing the setting range

Pick the range so the nameplate current is not at the extreme of the dial; the 46-65 A window here is meant for motors in that band, and the class 10A characteristic applies.

Short-circuit protection is separate: the datasheet quotes 125 A gG and 80 A aM as maximum fuse sizes for this relay.

Mounting and use

Typical use is the overload protection leg of a direct-on-line starter for pumps, fans and conveyors. The NC auxiliary contact opens the contactor coil circuit on a trip and the NO contact can drive an alarm.

Terminals are Yoke clamp. Operating and storage temperature limits are in the table; if the relay sits in a hotter place than the motor, set the dial with that in mind.

For panel design and commissioning, the practical figures to keep at hand are: terminals type Yoke clamp; terminals screw M5; terminals width 9 mm; terminals tool Phillips 2; auxiliary circuit type screw and washer; auxiliary circuit screw M3,5; auxiliary circuit width 8 mm; auxiliary circuit tool Phillips 1; operating temperature (min) -20 °C; operating temperature (max) 55 °C; storage temperature (min) -55 °C; storage temperature (max) 80 °C; max altitude 3000 m; operating position, normal Vertical plan. These come straight from the datasheet and are repeated here so that the key installation limits are visible without opening the PDF.

Documents and quotation

All data on this page for RF826500 is taken from the Lovato Electric catalogue datasheet (English), which you can download from the attachment list. Check the motor full-load current, the matching contactor and whether a manual or automatic reset is wanted against your own drawings first; the manufacturer may update datasheet figures without notice. More products of this type are under contactors & overload relays. Use the quotation form with the code RF826500 and your quantity; availability is confirmed by Seven Star LLC, an independent supplier in Muscat.
